Craftmade Moto MOT52 Installation Manual

Hide thumbs

Table of Contents

Quick Links

Download this manual

Moto

Installation Guide

For Model:

MOT52

E192641

APPROVED FOR USE

IN DAMP LOCATIONS

net weight of fan: 13.64 lb. (6.20 kg)

READ THESE INSTRUCTIONS AND

SAVE THEM FOR FUTURE USE

Need help?

Do you have a question about the Moto MOT52 and is the answer not in the manual?

Questions and answers

Summary of Contents for Craftmade Moto MOT52

Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Moto Installation Guide For Model: MOT52 Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 3 Parts Inventory. pg. 3 Installation Preparation. pg. 4 Hanging Bracket Installation. pg. 4 Fan Assembly.
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches that the hanging location allows the blades a (76cm) 7 feet clearance of 7ft. (2.13m) from the floor and 30in. (2.13m) (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft.
Page 5: Fan Assembly. Pgs
5. Fan Assembly. stop pin set screw Remove hanging ball from downrod provided by loosening set screw on hanging ball. Lower hanging ball and remove stop pin and then slide hanging ball hanging ball off of the downrod. [Refer to diagram 1.] Loosen yoke set screws and nuts at top of motor diagram 1 housing.
Page 6 5. Fan Assembly. (cont.) wood ceiling With the hanging bracket secured to the joist outlet box and able to support the fan, you safety cable loop are now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging bracket and let wood screw hanging ball rest on the hanging bracket.
Page 7: Wiring
6. Wiring. WARNING: Turn off circuit breakers to current fixture from breaker panel and be sure switch is turned to the OFF position. white supply wire ground (green or bare) CAUTION: Be sure outlet box is properly black supply wire grounded and that a ground wire (GREEN or Bare) is present.
Page 8: Canopy Assembly
7. Canopy Assembly. hanging bracket Locate 2 screws on underside of hanging bracket and remove screw closest to the open end of the hanging bracket. Partially loosen the other screw. Lift canopy to hanging bracket. Place rounded part of slotted hole in canopy over loosened screw screw in hanging bracket and push up.
Page 9: Switch Housing Assembly
9. Switch Housing Assembly. motor housing Remove 1 screw from motor plate (on underside of motor) and partially loosen the other 2 screws. Align slotted holes in middle motor of switch housing plate with loosened screws plate in motor plate, allowing male plug from motor housing to come through hole in switch middle of switch housing plate.
Page 10: Troubleshooting
Contact Craftmade Customer Service at 1-800-486-4892 to arrange for return of fan. Solutions: Return fan, shipping prepaid, to Craftmade. We will repair 1. Check wall switch to fan. or ship you a replacement fan, and we will pay the return 2.
