This air conditioner uses the new refrigerant R410A.
CEILING-MOUNTED
(1-WAY SLIM)
ST-NPFL 12R
ST-NK1FL 9R
ST-NPFL 16R
ST-NK1FL 12R
ST-NPFL 18R
ST-NK1FL 18R
ST-NPFL 24R
ST-NK1FL 24R
ST-NPFL 36R
ST-NPFL 48R
FLOOR STANDING
ST-NFFL 7R
ST-NFFL 9R
ST-NFFL 12R
ST-NFFL 16R
ST-NFFL 18R
ST-NFFL 24R
WALL-MOUNTED
ST-NWFL 7R
ST-NWFL 9R
ST-NWFL 12R
ST-NWFL 16R
ST-NWFL 18R
ST-NWFL 24R
CONCEALED FLOOR
STANDING
ST-NFMFL 7R
ST-NFMFL 9R
ST-NFMFL 12R
ST-NFMFL 16R
ST-NFMFL 18R
ST-NFMFL 24R
• INSTRUCTION MANUAL
• MODE D'EMPLOI
• BEDIENUNGSANLEITUNG
• ISTRUZIONI PER L'USO
• MANUAL DE INSTRUÇÕES
• ΕΓΧΕΙΡΙ∆ΙΟ Ο∆ΗΓΙΩΝ
• MANUAL DE INSTRUCCIONES
CONCEALED DUCT
(Standard Static Pressure)
ST-NDLP 7R
ST-NDLP 9R
ST-NDLP 12R
ST-NDLP 16R
ST-NDLP 18R
ST-NDLP 24R
ST-NDLP 36R
ST-NDLP 48R
(High Static Pressure)
ST-NDHP 24R
ST-NDHP 36R
ST-NDHP 48R
ST-NDHP 76R
ST-NDHP 96R
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Airwell ST-NFMFL 16R
Summary of Contents for Airwell ST-NFMFL 16R
- Page 1 (High Static Pressure) ST-NFFL 9R ST-NFMFL 9R ST-NK2FL 7R ST-NDHP 24R ST-NFFL 12R ST-NFMFL 12R ST-NK2FL 9R ST-NDHP 36R ST-NFFL 16R ST-NFMFL 16R ST-NK2FL 12R ST-NDHP 48R ST-NFFL 18R ST-NFMFL 18R ST-NK2FL 16R ST-NDHP 76R ST-NFFL 24R ST-NFMFL 24R ST-NK2FL 18R...
-
