MODELS
Floor/Ceiling unit
SXV 007
SXV 009
SXV 012
SXV 015
SXV 018
SXV 021
SXV 024
SAFETY PRECAUTIONS
● Read the following "SAFETY PRECAUTIONS" carefully before installation.
● Carry out test running to confirm that no abnormality occurs after the installation. Then, explain to user the operation, care and maintenance as stated in
instructions. Please remind the customer to keep the operating instructions for future reference.
WARNING
This indication shows the possibility of causing death or serious injury.
CAUTION
This indication shows the possibility of causing harm or damage the equipment.
1) Use qualified installer and follow carefully this instructions. Otherwise it will cause electrical shock, water leakage, or esthetic problem.
2) Install at a strong and firm location which is able to withstand the set's weight. If the strength is not enough or installation is not properly done, the set
will drop and cause injury.
3) For electrical work, follow the local national wiring standard, regulation and this installation instruction. An independent circuit and single outlet must
be used. If electrical circuit capacity is not enough or defect found in electrical work, it will cause electrical shock or fire.
4) Use the specified cable and connect tightly for indoor connection. Connect tightly and clamp the cable so that no external force will be acted on the
terminal. If connection or fixing is not perfect, it will cause heat-up or fire at the connection.
5) Wire routing must be properly arranged so that control board cover is fixed properly. If control board cover is not fixed perfectly, it will cause heat-up
at connection point of terminal, fire or electrical shock.
6) When carrying out piping connection, take care not to let air substances other than the specified refrigerant go into refrigeration cycle. Otherwise, it
will cause lower capacity, abnormal high pressure in the refrigeration cycle, explosion and injury.
7) Do not damage or use unspecified power supply cord. Otherwise, it will cause fire or electrical shock.
8) This equipment must be earthed. It may cause electrical shock if the grounding is not perfect.
9) Do not install the unit at place where leakage of flammable gas may occur. In case gas leaks and accumulates at surrounding of the unit, it may
cause fire.
1) Selection of the installation location.
Select a installation location which is rigid and strong enough to support or hold the unit, and select a location for easy maintenance.
2) Do not release refrigerant.
Do not release refrigerant during piping work for installation, reinstallation and during repairing a refrigeration parts. Take care of the liquid refrigerant.
it may cause frostbite.
3) It may need two people to carry out the installation work.
4) Do not install this appliance in a laundry room or other location where water may drip from the ceiling, etc.
5) Carry out drainage pipes as mentioned in installation instructions. If drainage is not perfect, water may enter the room and damage the furniture.
INSTALLATION MANUAL
WARNING
CAUTION
IM_SXV_1 A 1 _GB
Part NO:468050100/02
Advertisement
Related Manuals for Airwell SXV 009
Summary of Contents for Airwell SXV 009
- Page 1 INSTALLATION MANUAL MODELS Floor/Ceiling unit SXV 007 SXV 009 SXV 012 SXV 015 SXV 018 SXV 021 SXV 024 SAFETY PRECAUTIONS ● Read the following "SAFETY PRECAUTIONS" carefully before installation. ● Carry out test running to confirm that no abnormality occurs after the installation. Then, explain to user the operation, care and maintenance as stated in instructions. Please remind the customer to keep the operating instructions for future reference. WARNING This indication shows the possibility of causing death or serious injury. CAUTION This indication shows the possibility of causing harm or damage the equipment. WARNING 1) Use qualified installer and follow carefully this instructions. Otherwise it will cause electrical shock, water leakage, or esthetic problem. 2) Install at a strong and firm location which is able to withstand the set's weight. If the strength is not enough or installation is not properly done, the set will drop and cause injury. 3) For electrical work, follow the local national wiring standard, regulation and this installation instruction. An independent circuit and single outlet must be used. If electrical circuit capacity is not enough or defect found in electrical work, it will cause electrical shock or fire. 4) Use the specified cable and connect tightly for indoor connection. Connect tightly and clamp the cable so that no external force will be acted on the terminal. If connection or fixing is not perfect, it will cause heat-up or fire at the connection. 5) Wire routing must be properly arranged so that control board cover is fixed properly. If control board cover is not fixed perfectly, it will cause heat-up at connection point of terminal, fire or electrical shock.
-
Page 2: Attached Accessories
Required tools for installation works 1.Screw driver 4.Hexagonal wrench 7. Knife 2.Electric drill, hole core drill ( 60 mm) 5.Pipe cutter 8.Measuring tape 3.Spanner 6.Reamer 9.Torque wrench Attached accessories No . Accessories parts Qty. No . Accessories parts Qty. No . Accessories parts Qty. Mounting plate Tube locating template Unit operation manual Installation manual SELECT THE BEST LOCATION � There should not be any heat source or steam near the unit. � There should not be any obstacles blocking the air circulation. � A place where air circulation in the room is good. � A place where drainage can be easily done. � Do not install the unit near the door way. � Recommended installation height for indoor unit shall be at least 2.3m( for ceiling unit ). INSTALLATION Of uNIT SuppOrT � Install the wall support of the SXV using the installation template supplied with the unit. (Fig 1) � The cut-outs for the unit are shown on this template. � Reminder of MINIMUM clearances to be provided. (Fig 2) � Coolant connections can be made on the LH side, on the RH side or at the rear. (Fig 3) � Condensate evacuation possibilities: right, left, rear and front in the case of a ceiling mounted unit. (2 condensate outputs are available on the recovery tray). -
Page 3: Installation
Location of tubing clamps All 4 must support the part Pressfully home Fig 7-2 Fig 7-3 Fig 7-1 Φ Liquid Pipe Φ Gas Pipe SXV 007 1/4" 1/2" SXV 009 1/4" 1/2" SXV 012 1/4" 1/2" SXV 015 1/4" 1/2" SXV 018 1/4" 1/2" SXV 021 3/8" 5/8" SXV 024 3/8"... -
Page 4: Unit Installation
� Fit the nuts of the (for med) tubing into the recess provided on the template. (Fig 7-2) � Secure the tubing with the clamps provided. (Fig 9) � Remove the tubing template; you can now install your unit on its support. NOTE output from the rear � The slanted hole prevents condensates or rain from entering the unit. � Fit a Dia. 70 mm sleeve into the hole. Fig 10 Remove the template WARNING The piping must be closed to prevent impurities from entering Secure the piping with Insulated gas piping Insulated liquid piping the clamp sprovided Fig 9 uNIT INSTALLATION A Install the unit to wall support FOR THE AIR INLET GRILL: 1 Pull the grill forwards. 2 Remove the two end screws. 3 Unscrew the central screw, but do not remove it completely. 4 Unhook the grid. -
Page 5: Electrical Wiring Connection
drAINAGE pIpE CONNECTION A Connect the drain pipe ● Water condensation must be evacuated directly to the outside; observe an appropriate slope for the evacuation duct, which should slopedownwards the case of a connection to the wastewater system (2.5 cm/m slope). ● An S-bend must be installed on the evacuation duct, below the level of the recovery tray of the unit. ● Provide insulation for the evacuation piping in the case of a risk of freezing or condensation. ● Evacuation with pump kit: (refer to instructions provided with kit). a.The unit is supplied with an evacuation piping. b.The right and left outlets are blocked off by a plug. Do not forget to remove this plug before connecting the evacuation piping. ● In the case of a ceiling mounted installation, run the evacuation piping down along the side panel and secure it with clamps as shown below. Also break the preformed cut-out in the coner of the intake grid. Condensate recovery Fig 16 Fig 15 Fig 14 tray Liquid tube B Drainage test Pour a glass of water into the drain tray-styrofoam,ensure that water flows out from drain hose Evacuation Gas tube of the indoor unit,a long of 1 min is allowed before discharging, according to the length of the tube drain pipe, and check whether water leaks from the joints. Fig 17 CAUTIONS: If there is any malfunction, please resolve it immediately. -
Page 6: Electrical Characteristics
Power supply Main R/C Bus Wiring ELB:Electricity Leakage Breaker. AH : Assistant heater. Electrical characteristics Unit Power supply Fan motor Model Volts SXV007 0.37 0.06 0.18 SXV009 0.37 0.06 0.18 SXV012 0.37 0.06 0.18 SXV015 220~240 0.68 0.13 0.41 MCA : Min. Circuit Amps (A) SXV018 0.68 0.13 0.41 MFA : Max. Fuse Amps(A) SXV021 0.68 0.13 0.41 KW : Fan Motor Rated output(KW) SXV024 0.68...
