Introduction HS 200UTV-2/HS 250UTV-2
INTRODUCTION
Congratulations on your purchase of the HS 200UTV-2/HS 250UTV-2. This Owner's /
Operator's manual will provide you information regarding safe operation, operational
instructions, maintenance and care. Fully understanding this manual and following all of the
instructions herein will provide the knowledge needed to have safe and enjoyable UTV
operation.
For questions regarding this UTV, please call (972) 446-0760.
IMPORTANT SAFETY MESSAGES
● READ THIS MANUAL CAREFULLY AND COMPLETELY BEFORE OPERATING YOUR UTV.
MAKE SURE YOU UNDERSTAND ALL INSTRUCTIONS.
● PAY CLOSE ATTENTION TO THE WARNING AND CAUTION LABELS ON THE UTV.
● NEVER OPERATE THE UTV WITHOUT PROPER TRAINING OR INSTRUCTION.
● THIS UTV SHOULD NOT BE RIDDEN BY ANYONE UNDER
12 YEARS OF AGE.
1-1
