H RESOLUTION
VGA, RGB/HV inputs only
V RESOLUTION
VGA, RGB/HV inputs only
INPUT RESOLUTION
VGA, RGB/HV inputs only
ASPECT
NORMAL
FULL
WIDE
DYNAMIC
1:1
ZOOM
ZOOM
H ZOOM
V ZOOM
H POS
V POS
RESET

AUDIO

VOLUME
BALANCE
TREBLE
BASS
SURROUND
PIP AUDIO
LINE OUT
INTERNAL SPEAKER
(not adjustable)
AUDIO INPUT
AUDIO DELAY
RESET

SCHEDULE

OFF TIMER
SCHEDULE SETTINGS
SCHEDULE LIST
*: The product you purchased may not have this feature.
Adjusts the horizontal size of the image.
Adjusts the vertical size of the image.
If there is a problem with signal detection, this function forces the monitor to display the signal at
the desired resolution. After selection, execute "AUTO SETUP" if required.
If no problem is detected, the only available option will be "AUTO".
Select the aspect ratio of the screen image.
Displays the aspect ratio the same as it is sent from the source.
Fills entire screen.
Expands a 16:9 letter box signal to fi ll entire screen.
Expands a 4:3 pictures to fi ll the entire screen with non-linearity. Some of the outside image area
will be cut off due to expansion. TILE MATRIX becomes invalid.
Display the image in a 1 by 1 pixel format. (If the input resolution is higher than a 1920 x 1080
resolution, the image will be scaled down to fi t the screen). TILE MATRIX becomes invalid.
The image can be expanded/reduced.
Note: The expanded image which is outside of active display area is not shown. The reduced
image may have some image degradation.
Maintains the aspect ratio while zooming.
Amount of horizontal zoom.
Amount of vertical zoom.
Horizontal position.
Vertical position.
Resets the following settings within the ADJUST menu back to factory setting: AUTO ADJUST,
H POSITION, V POSITION, CLOCK, PHASE, H RESOLUTION, V RESOLUTION, ASPECT.
Increases or decreases output volume level.
Adjust the balance of L/R volume.
Press + button to move the stereo sound image to right.
Press - button to move the stereo sound image to left.
To accentuate or reduce the high frequency sound.
Press + button to increase TREBLE sound.
Press - button to decrease TREBLE sound.
To accentuate or reduce the low frequency sound.
Press + button to increase BASS sound.
Press - button to decrease BASS sound.
Artifi cial surround sound.
Note: Audio out is disabled when this function is set to ON.
Selects source of PIP audio.
Selecting "VARIABLE" enables control of the line out level with the VOLUME button.
Note: Audio out is disabled when this function is set to ON.
Selects audio input source [IN1], [DPORT], [HDMI], [OPTION]*.
Enables to set the delay time to output the audio. DELAY TIME can be set between 0 and 8.
"ON" activates this function.
Resets "AUDIO" options back to factory settings except VOLUME.
Sets the monitor to power off after a length of time.
A time between 1 to 24 hours is available.
Creates a working schedule for the monitor to use.
NOTE: If your schedule is across date, please set ON time and OFF time individually at Settings.
List of schedules.
English-22
-
-
AUTO
FULL
-
-
-
-
-
-
-
-
40
CENTER
0
0
OFF
MAIN AUDIO
FIXED
Depend on
signal input
OFF, 2
-
OFF
-
-
