NEC Digital Signage Solutions
42", 46", 55" & 65" LED edge-lit, commercial-grade
LCD displays bundled with AMD Dual Core
OPS single board computers
Take the fast track to high-quality digital signage with full PC
functionality integrated directly within an NEC display. NEC's
Highlights
• LED backlighting technology reduces power consumption and allows for a slimmer cabinet depth
• Integrated PC (OPS-PCAF-WS) is optimized for reliable 1080p video playback
• 1920 x 1080 FHD native resolution in true 16:9 aspect ratio, maximum brightness of up to 500 cd/m
typical contrast ratio of up to 4000:1
• TileMatrix™ technology enables video walls (up to 100 displays in a 10x10 matrix)
• Integrated 10W speakers provide stereo audio for those applications requiring sound
• Optional color calibration solution ensures color uniformity and fidelity across individual and multiple screens,
creating a perfectly matched image in tiled environments
• Diverse input connectors allow for maximum compatibility and flexibility during product implementation
• OPS-PCAF-WS' 3-year warranty matches that of the display
• NEC Content Management Software (CMS), a SaaS web-based, digital signage software,
is available at no charge
single board computer
(OPS-PCAF-WS), boasts
an AMD 1.6 GHz Dual Core
Fusion APU and adheres
to the Open Pluggable Specification (OPS), the industry's first standardized input
to increase flexibility for users of any digital signage application. Combining this
PC with the high-performance panel of the NEC V Series (42", 46", 55" and 65"
sizes available), these bundles are a wonderfully simple solution for dynamic digital
signage. Utilizing the expansion slot integrated into V Series displays, the PC
provides for clean, hidden integration while reducing the bill of materials needed
for installation and eliminating the hassle of hiding hardware equipment. Whet
appetites in restaurants. Build brand awareness in retail. Turn heads in corporate
lobbies. The digital signage possibilities are virtually endless.
Large-Screen
Display Bundles
and
2
