Connection Ports

1 2 3
20
1. Power Socket
2. SERVICE
3. VGA Output
4. VGA 1/ YPbPr Connector
5. VGA 2/ YPbPr Connector
6. DisplayPort
7. HDMI 1
8. HDMI 2
9. 3D SYNC OUT
10. 12V OUT
11. Kensington MicrosaverTM Lock Port
12. Speaker
13. IR Receiver
14. Composite Video
15. AUDIO IN (L and R)
16. S-Video
17. RS232
18. AUDIO IN
19. AUDIO OUT
20. LAN
Introduction
4 5 6
19 18 17 16
7 8 9
10
15 14 13 12
11
9
