HIKVISION ECI-B12F Quick Start Manual

Network bullet camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ECI-B12F2 • ECI-B12F4 • ECI-B12F6
Network Bullet Camera
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECI-B12F and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION ECI-B12F

Summary of Contents for HIKVISION ECI-B12F

  • Page 1 ECI-B12F2 • ECI-B12F4 • ECI-B12F6 Network Bullet Camera Quick Start Guide...
  • Page 2 Your actual product may differ in appearance. Your product might not support all features discussed in this document. Hikvision USA Inc., 18639 Railroad St., City of Industry, CA 91748, USA • Hikvision Canada, 4848 rue Levy, Saint Laurent, Quebec, Canada, H4R 2P1 Telephone: +1-909-895-0400 •...
  • Page 3 ECI-B12Fx Network Bullet Camera Quick Start Guide FCC Conditions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 4 ECI-B12Fx Network Bullet Camera Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 5 ECI-B12Fx Network Bullet Camera Quick Start Guide Cautions Do not drop the camera or subject it to physical shock.  Do not place the camera in extremely hot, cold (the operating  temperature shall be -40° to 60° C), dusty or damp locations, and do not expose it to high electromagnetic radiation.

  • Page 6: Table Of Contents

    ECI-B12Fx Network Bullet Camera Quick Start Guide Contents 1 Appearance Description ................. 7 2 Installation ..................... 7 2.1 Ceiling/Wall Mounting ..............7 2.2 Ceiling/Wall Mounting with Junction Box ........9 2.3 Waterproof Jacket Installation............12 3 Set the Network Camera over the LAN ..........13 3.1 Wiring ...................

  • Page 7: Appearance Description

    ECI-B12Fx Network Bullet Camera Quick Start Guide 1 Appearance Description This network bullet camera appearance is shown as the figures below. Network Bullet Camera Overview Description Lens Front Cover Back Cover Fix Ring Power Cord Network Cable NOTE: For power over Ethernet (PoE), the power is passed along with data on Ethernet cabling.
  • Page 8 ECI-B12Fx Network Bullet Camera Quick Start Guide Both wall mounting and ceiling mounting are suitable for the bullet camera. Ceiling mounting will be taken as an example in this section. Use these ceiling mounting steps as a reference for wall mounting. 1.

  • Page 9: Ceiling/Wall Mounting With Junction Box

    ECI-B12Fx Network Bullet Camera Quick Start Guide NOTES: The supplied screw package contains both self-tapping screws and  expansion bolts. If the ceiling is cement, expansion bolts are required to fix the camera. If  the ceiling is wood, self-tapping screws are required. 5.
  • Page 10 ECI-B12Fx Network Bullet Camera Quick Start Guide You will need to purchase a junction box.  1. Paste the drill template (supplied) to the desired mounting position on the wall/ceiling. 2. Drill the screw holes and the cable hole (optional) in the wall/ceiling according to the drill template.
  • Page 11 ECI-B12Fx Network Bullet Camera Quick Start Guide Fasten the Junction Box to the Wall 6. Route the cables through the cable hole. Here we take the bottom cable hole as an example to describe the installation. 1) Separate the waterproof cover and the cable gland from the junction box.

  • Page 12: Waterproof Jacket Installation

    ECI-B12Fx Network Bullet Camera Quick Start Guide Combine Junction Box’s Cover with its Body 8. Repeat steps 5 to 7 of 2.1 9. Ceiling/Wall Mounting to complete the installation. 2.3 Waterproof Jacket Installation It is recommended to use the waterproof jacket (supplied) when the camera is installed outdoors.

  • Page 13: Set The Network Camera Over The Lan

    ECI-B12Fx Network Bullet Camera Quick Start Guide Install Waterproof Jacket 3 Set the Network Camera over the LAN NOTE: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 14: Activation Via Web Browser

    ECI-B12Fx Network Bullet Camera Quick Start Guide Refer to the of Network Camera user manual for activation via client software. 3.2.1 Activation via Web Browser 1. Power on the camera. 2. Connect the camera to your computer or the switch/router that your computer connects to.

  • Page 15: Modify The Ip Address

    ECI-B12Fx Network Bullet Camera Quick Start Guide Select inactive device. Input and confirm password. SADP Interface NOTE: The SADP software supports activating the camera in batch. Refer to the SADP software user manual for details. 3. Create and input the new password in the password field. 4.

  • Page 16: Access Via Web Browser

    ECI-B12Fx Network Bullet Camera Quick Start Guide Use the SADP software or client software to search and change the IP address of the device. We take modifying the IP address via SADP software as an example to introduce IP address modification. For IP address modification via client software, refer to the client software user manual.
  • Page 17 ECI-B12Fx Network Bullet Camera Quick Start Guide Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1 GB or higher Display: 1024 × 768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version 1.

  • Page 18: Operate Via Hik-Connect App

    ECI-B12Fx Network Bullet Camera Quick Start Guide Download Plug-in 6. Reopen the Web browser after installing the plug-in and repeat steps 2 to 4 to login. NOTE: For further configuration instructions, see the network camera user manual. 3.5 Operate via Hik-Connect App Hik-Connect is a mobile application to view live camera images, receive alarm notifications, etc.

  • Page 19: Enable Hik-Connect Via A Web Browser

    ECI-B12Fx Network Bullet Camera Quick Start Guide Verification Code Setting (SADP) NOTE: The verification code is required when adding the camera to Hik-Connect. 2. Click and read the “Terms of Service” and “Privacy Policy.” 3. Confirm the settings. 3.5.5 Enable Hik-Connect via a Web Browser Before You Start Activate the camera before enabling the service.

  • Page 20: Add Camera To Hik-Connect

    ECI-B12Fx Network Bullet Camera Quick Start Guide Platform Access Configuration (Web) 3. Set the Platform Access Mode to Hik-Connect. 4. Check the Enable checkbox. 5. Click and read the “Terms of Service” and “Privacy Policy” in the pop-up window. 6. Create or change the verification code for the camera. NOTE: A verification code is required when adding the camera to Hik-Connect.
  • Page 21 ECI-B12Fx Network Bullet Camera Quick Start Guide NOTE: After the camera connects to the network, wait one minute before using the camera with Hik-Connect. 2. Add the camera to the Hik-Connect app: • If Accessing the Camera through an NVR: Tap “+” on the upper-right corner and scan the QR code that appears in the NVR interface.
