HIKVISION E Series Quick Manual

HIKVISION E Series Quick Manual

Network speed dome
Hide thumbs Also See for E Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual, Installation Manual
E Series
Network Speed Dome
Quick Guide
UD.6L0201B1420A01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E Series and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION E Series

Summary of Contents for HIKVISION E Series

  • Page 1 E Series Network Speed Dome Quick Guide UD.6L0201B1420A01...
  • Page 2 E Series Network Speed Dome·Quick Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to E Series network speed dome. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.

  • Page 3: Regulatory Information

    E Series Network Speed Dome·Quick Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Safety Instruction

    E Series Network Speed Dome·Quick Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death.
  • Page 5 E Series Network Speed Dome·Quick Guide  Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can cause fire danger).  Do not aim the speed dome at the sun or extra bright places. A blooming or smear may occur otherwise (which is not a malfunction however), and affecting the endurance of sensor at the same time.

  • Page 6: Table Of Contents

    E Series Network Speed Dome·Quick Guide Table of Contents 1 Overview ...................... 6 1.1 Check package contents ......................6 1.2 Cables ............................6 1.3 Micro SD Card Instructions ....................... 7 1.4 Installation Flow ........................11 2 Installation ....................12 2.1 Wall Mounting ........................12 2.1.1 Wall Mount Installation ....................

  • Page 7: Overview

    E Series Network Speed Dome·Quick Guide 1 Overview 1.1 Check package contents Before you start: Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. Note: When carrying the speed dome, do not directly pull waterproof group cables.

  • Page 8: Micro Sd Card Instructions

    E Series Network Speed Dome·Quick Guide The cables of the 5-inch and IR speed dome: AC24V Red AC24V YELLOW/GREEN Yellow&Green GND BLACK AC24V Black AC24V Purple AUDIO-IN Black Pink AUDIO-OUT Yellow/Gray ALARM-IN6 Yellow/Red ALARM-IN7 Yellow/Black ALARM-GND White/Black ALARM-COM1 White/Red ALARM-OUT1...
  • Page 9 E Series Network Speed Dome·Quick Guide SD Card Slot Slot Type 2 Slot Type 1 Location Figure 1-3 Micro SD Card Slot Lens Cover Protective Sticker Protective Foam Figure 1-4 Remove the Protective Accessory  Mini IR network speed dome: The micro SD card slot is inside the rear cover. Outdoor mini IR network speed dome is taken as an example here.
  • Page 10 E Series Network Speed Dome·Quick Guide Camera Module Remove Rear Cover Micro SD Card Slot Figure 1-5 Micro SD Card Slot  5-inch network speed dome: The micro SD card slots of 5-inch network speed dome are shown below. Note: There are two locations of SD card slot for different models of mini network speed dome.
  • Page 11 E Series Network Speed Dome·Quick Guide Protective Sticker Protective Foam Figure 1-7 Remove the Protective Accessory  IR network speed dome: The micro SD card slot is inside the rear cover. Outdoor mini IR network speed dome is taken as an example here. Refer to the following steps to install the micro SD card.

  • Page 12: Installation Flow

    E Series Network Speed Dome·Quick Guide 1.4 Installation Flow The installation flow is shown in the following figure. Please install the speed domes according to the flow. Begin Preparation Wiring Wall Mount Installation Whether cable Speed Dome Installation connection &Cable Connection...

  • Page 13: Installation

    E Series Network Speed Dome·Quick Guide 2 Installation Warning: Do not power the speed dome up until the installation is finished. To ensure the safety of personnel and equipment, all the installation steps should be done with power supply off.

  • Page 14: Micro Sd Card Installation

    E Series Network Speed Dome·Quick Guide 2. Drill 4 φ12 screw holes in the wall according to the hole locations of the mount, and then insert M8 expansion screws into the screw holes. Figure 2-2 Drill Screw Hole and Insert Expansion Screw 3.
  • Page 15 E Series Network Speed Dome·Quick Guide 1. Hook the two ends of the safety rope to the back box of the speed dome and the wall mount respectively. Route the cables through the mount as shown follows. Safety Rope Figure 2-4 Safety Rope 2.
  • Page 16 E Series Network Speed Dome·Quick Guide Figure 2-6 Tighten the Lock Screws Mini IR Network Speed Dome Installation Steps: 1. Hook the two ends of the safety rope to the back box of the speed dome and the wall mount respectively.
  • Page 17 E Series Network Speed Dome·Quick Guide Figure 2-8 Tighten the Lock Screws 5-inch Network Speed Dome Installation Notes:  Please remove the protective film on the lower dome after the installation is finished.  Do not touch the bubble of the lower dome directly by hand. The image blurs otherwise.
  • Page 18 E Series Network Speed Dome·Quick Guide Lock Screw Push Rotate Figure 2-10 Align to the Mount 4. Use L-wrench to tighten the lock screws to secure the speed dome and the wall mount. Figure 2-11 Tighten the Lock Screws IR Network Speed Dome Installation Steps: 1.
  • Page 19 E Series Network Speed Dome·Quick Guide Protective Sticker Figure 2-12 Remove Sticker 2. Hook the two ends of the safety rope to the back box of the speed dome and the wall mount respectively. Route the cables through the mount as shown follows.

  • Page 20: In-Ceiling Mounting

    E Series Network Speed Dome·Quick Guide Figure 2-14 Tighten the Lock Screws 2.2 In-ceiling Mounting Notes:  The height of the space above the ceiling must be more than 250mm.  The ceiling must be with the thickness between 5 and 40mm.
  • Page 21 E Series Network Speed Dome·Quick Guide 1). Loosen three screws as shown in the following figure. 2). Remove the lower dome. 3). Loosen three screws and remove the back box. 4). Remove the protective lens cover, foam and sticker from the dome drive.
  • Page 22 E Series Network Speed Dome·Quick Guide Toggle Bolt Figure 2-18 Install the Toggle Bolts 4. Align the toggle bolts with the screw holes on the ceiling. 5. Push the dome to the mounting hole on the ceiling. 6. Rotate the bolts again. The toggle will automatically rotate down to secure the dome to the ceiling.

  • Page 23: Mini Ir Network Speed Dome

    E Series Network Speed Dome·Quick Guide 8. Route the cables through the ceiling for the speed dome. Figure 2-21 Finish the Installation 2.2.2 Mini IR Network Speed Dome Before you start: The in-ceiling mounting is applicable to the indoor ceiling.
  • Page 24 E Series Network Speed Dome·Quick Guide 2). Insert the bolts into the 3 screw holes on the dome. 3). Rotate the bolts through the 3 screw holes. 4). Reinstall the toggles as shown in Figure 2-23. Toggle Bolt Figure 2-23 Install Toggle Bolts 4.

  • Page 25: 5-Inch Network Speed Dome

    E Series Network Speed Dome·Quick Guide Figure 2-25 Install the Dome to the Ceiling 2.2.3 5-inch Network Speed Dome Steps: 1. Drill holes in the ceiling. 1). Attach the drill template to the ceiling where you need to install the speed dome.
  • Page 26 E Series Network Speed Dome·Quick Guide Back Box Foam Lower Dome Bubble Sticker Figure 2-27 Remove the Protective Accessory 5. Connect the cables. Connect the power cable and the red LED indicator turns on when the power is on. Note: Please turn the power off after checking the speed dome.

  • Page 27: Ceiling Mounting

    E Series Network Speed Dome·Quick Guide Lock Lock Screw Figure 2-29 Install the back box 7. Install the trim ring. Steps: 1). Attach the trim ring to the lower dome and align the triangular notch of the trim ring with the arrow label on the in-ceiling mount.

  • Page 28: Mini Network Speed Dome

    E Series Network Speed Dome·Quick Guide  The height of the space above the ceiling must be more than 250mm.  The ceiling must be with the thickness between 5 and 40mm.  The ceiling must be strong enough to withstand more than 4 times the weight of the dome and its accessories.
  • Page 29 E Series Network Speed Dome·Quick Guide Lens Cover Sticker Foam Figure 2-33 Dissemble the Speed Dome 5. Align the ceiling mount with the screw holes on the drill template. Secure the ceiling mount to the ceiling with screws(supplied) as follows.
  • Page 30 E Series Network Speed Dome·Quick Guide Align Unlock Label Figure 2-35 Install Speed Dome Figure 2-36 Install Speed Dome Notes:  For cement ceiling mounting, you need to use the expansion screw to fix the mount. The mounting hole of the expansion pipe on the wall should align with the mounting hole on the mount.

  • Page 31: 5-Inch Network Speed Dome

    E Series Network Speed Dome·Quick Guide 2.3.2 5-inch Network Speed Dome Removing the In-ceiling Mount: The speed dome is installed with an in-ceiling mount by default. Before you mount the speed dome on the ceiling, you need to remove the in-ceiling mount first.
  • Page 32 E Series Network Speed Dome·Quick Guide 3. Install 4 bolts to the screw holes as shown in Figure 2-39. Figure 2-39 Install the bolts Routing Method: The cables of dome can be routed either from the top or the side of the back box, as shown in Figure 2-40.
  • Page 33 E Series Network Speed Dome·Quick Guide 5. If you route cables from the top of the back box, mark the cable hole on the ceiling and drill a hole. Screw Hole Cable Hole Figure 2-41 Mark the Screw Positions 6. Secure the mounting base to the ceiling with set screws.
  • Page 34 E Series Network Speed Dome·Quick Guide Steps: 1). Route the cables for the speed dome. Align the bottom of the speed dome with the mounting base. 2). Line up the direction of arrow with the spring end of the mounting base.

  • Page 35: Setting The Dome Over The Lan

    E Series Network Speed Dome·Quick Guide 3 Setting the Dome over the LAN To view and configure the speed dome via LAN(Local Area Network), you need to connect the network speed dome in the same subnet with your PC. Then, install the SADP or client software to search and change the IP of network speed dome.
  • Page 36 E Series Network Speed Dome·Quick Guide Figure 3-2 Searching Online Devices Note: Device can be searched and displayed in the list in 15 seconds after it goes online; it will be removed from the list in 45 seconds after it goes offline.
  • Page 37 E Series Network Speed Dome·Quick Guide Figure 3-3 Select a Device Figure 3-4 Modify Network Parameters 3. Enter the IP address of speed dome in the address field of the web browser to view the live video. Notes:  The default value of the IP address is 192.0.0.64. The default user name of administrator is admin, and password is 12345.

  • Page 38: Accessing Via Web Browser

    E Series Network Speed Dome·Quick Guide 4 Accessing via Web browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher...
  • Page 39 E Series Network Speed Dome·Quick Guide Figure 4-2 Install Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. Note: For detailed instructions of further configuration, please refer to the user manual of...
