Single Over Bath Screen/Sail Over Bath Screen
INSTALLATION INSTRUCTIONS
Item Number:AP9575S/AP9578S
This product should be installed by a suitably qualified and proficient person. The fitting instructions should be
followed carefully to ensure a proper and safe installation. Failure to follow these instructions could result in future
injury.
These instructions and list of parts assume that installation is done against solid/tiled walls.
Please check this product for damage prior to starting the installation. No claims can be made after the product has
been fitted.
PLEASE NOTE :The minimum and maximum adjustment sizes noted on the product brochures are based on
perfectly plumb walls and trays.
www.aprilproducts.co.uk
www.aprilproducts.co.uk
www.aprilproducts.co.uk
Lifetime Product Guarantee
To activate your Product Guarantee please
visit www.aprilproducts.co.uk and complete
the online form.
Tools Required
6
2.75
PH2 TYPE
Advertisement
Related Manuals for April identiti AP9575S
Summary of Contents for April identiti AP9575S
- Page 1 Single Over Bath Screen/Sail Over Bath Screen INSTALLATION INSTRUCTIONS www.aprilproducts.co.uk www.aprilproducts.co.uk www.aprilproducts.co.uk Item Number:AP9575S/AP9578S Lifetime Product Guarantee To activate your Product Guarantee please visit www.aprilproducts.co.uk and complete the online form. Tools Required 2.75 PH2 TYPE This product should be installed by a suitably qualified and proficient person. The fitting instructions should be followed carefully to ensure a proper and safe installation.
-
Page 2: Box Contents
COMPONENTS AND BOX CONTENTS Box Contents Description Description Wall profile Moving panel Upright profile Bottom seal Frame profile Wall plug Vertical seal Screw ST4 Profile Top cap Screw ST3.5 Pivot part 1 Screw cover cap Pivot part 2 Pivot part 3... - Page 3 Ф 6 drill bit Ф2.75 drill bit Step 1: Position the wall profile (1) onto the bath , approximately 12-15mm from the outside bath edge to ensure that the screen runs along the inside edge of the bath rim. (A). Step 2: Level the profile with a spirit level , then mark the position using a pencil.
- Page 4 Allow 24 hours before use for silicone to set . For cleaning instructions see guarantee . Bottom seal NOTE : To ensure a watertight seal ensure the bottom seal (10) is fully inserted into the base of the hinge as per the above diagram.
- Page 5 It is important to clean your April shower enclosure after every use. Please wipe down all glass and metal parts with a clean soft cloth. Ensure that all residual water on the glass is removed after every use. For reliable, watertight performance from your April enclosure your shower head should not be positioned so that the shower sprays directly onto the enclosure door.
