11. Technical Data

11.1. Environmental
Ambient Temperature Range
Maximum Altitude
Relative Humidity
Refer to section 1 1.8. Derating Information on page 72 for derating information.

11.2. Input Power Supply Requirements

Input Power Supply Requirements
Supply Voltage
Imbalance
Frequency

11.3. Input Voltage Ranges

Depending upon model and power rating, the drives are designed for direct connection to the following supplies:
Model Number
ODV-3-x2xxxx-1xxx-xx
ODV-3-x2xxxx-3xxx-xx
ODV-3-x4xxxx-3xxx-xx
ODV-3-x6xxxx-3xxx-xx

11.4. Phase Imbalance

All three phase Optidrive Eco units have phase imbalance monitoring. The maximum permissible voltage imbalance between any two
phases is 3% for full load operation.

11.5. Output Power and Current ratings

The following tables provide the output current rating information for the various Optidrive Eco models. Invertek Drives always
recommend that selection of the correct Optidrive is based upon the motor full load current at the incoming supply voltage.
Please note that the maximum cable length stated in the following tables indicate the maximum permissible cable length for the drive
hardware and does not take into consideration EMC compliance.
11.5.1. 200 – 240 Volt (+/- 10%),1 Phase Input, 3 Phase Output
Frame Power Rating
Size
kW HP
2 0.75 1
2 1.5 1.5
2 2.2 3
www.invertekdrives.com
Storage All
Operational IP20
IP55
IP66
Operational All
Operational All
200 – 240 RMS Volts for 230 Volt rated units, + /- 10% variation allowed.
380 – 480 RMS Volts for 400 Volt rated units, + / - 10% variation allowed.
500 – 600 RMS Volts for 600 Volt rated units, + / - 10% variation allowed.
Maximum 3% voltage variation between phase – phase voltages allowed.
All Optidrive Eco units have phase imbalance monitoring. A phase imbalance of > 3% will result in the
drive tripping.
50 – 60Hz + / - 5% Variation.
Supply Voltage
200 – 240 Volts + / - 10%
200 – 240 Volts + / - 10%
380 – 480 Volts + / -10%
500 – 600 Volts + / - 10%
Input Fuse or MCB
Current (Type B)
A Non UL UL
8.6 16 15
12.9 16 17.5
19.2 25 25
-40 °C ... 60 °C
-10 ... 50°C without derating
-10 ... 40°C without derating
1000m without derating
=< 95% (no condensation permitted)
Phases
1
3
3
3
Maximum Cable Size
mm AWG/kcmil
8 8
8 8
8 8
Version 3.06 | Optidrive Eco User Guide | 67
Frequency
50 – 60 Hz
50 – 60 Hz
50 – 60 Hz
50 – 60 Hz
Rated Output Maximum Motor
Current Cable Length
A m
4.3 100
7 100
10.5 100
ft
330
330
330
11
