2. General Information and Ratings

2.1. Drive Model Numbers

2.1.1. IP20 Units
Model Code
ODV-3-220043-1F12-TN
ODV-3-220070-1F12-TN
ODV-3-220105-1F12-TN
Model Code
ODV-3-220043-3F12-TN
ODV-3-220070-3F12-TN
ODV-3-220105-3F12-TN
ODV-3-320180-3F12-TN
ODV-3-320240-3F12-TN
ODV-3-420300-3F12-MN
ODV-3-420460-3F12-MN
ODV-3-520610-3F12-MN
ODV-3-520720-3F12-MN
ODV-3-520900-3F12-MN
ODV-3-621 100-3F12-MN
ODV-3-621500-3F12-MN
ODV-3-621800-3F12-MN
ODV-3-622020-3F12-MN
Model Code
ODV-3-240022-3F12-TN
ODV-3-240041-3F12-TN
ODV-3-240058-3F12-TN
ODV-3-240095-3F12-TN
ODV-3-340140-3F12-TN
ODV-3-340180-3F12-TN
ODV-3-340240-3F12-TN
ODV-3-440300-3F12-MN
ODV-3-440390-3F12-MN
ODV-3-440460-3F12-MN
ODV-3-540610-3F12-MN
ODV-3-540720-3F12-MN
ODV-3-540900-3F12-MN
ODV-3-641 100-3F12-MN
ODV-3-641500-3F12-MN
ODV-3-641800-3F12-MN
ODV-3-642020-3F12-MN
ODV-3-843700-3F12-MN
ODV-3-844500-3F12-MN
www.invertekdrives.com
200 – 240 Volt, 1 Phase Input
Frame kW
2 0.75
2 1.5
2 2.2
200 – 240 Volt, 3 Phase Input
Frame kW
2 0.75
2 1.5
2 2.2
3 4
3 5.5
4 7.5
4 1 1
5 15
5 18.5
5 22
6A 30
6A 37
6B 45
6B 55
380 – 480 Volt, 3 Phase Input
Frame kW
2 0.75
2 1.5
2 2.2
2 4
3 5.5
3 7.5
3 1 1
4 15
4 18.5
4 22
5 30
5 37
5 45
6A 55
6A 75
6B 90
6B 1 10
8 200
8 250
HP Amps Low Harmonic
1 4.3
2 7
3 10.5
HP Amps Low Harmonic
1 4.3
2 7
3 10.5
5 18
7.5 24
10 30
15 46
20 61
25 72
30 90
40 1 10
50 150
60 180
75 202
HP Amps Low Harmonic
1 2.2
2 4. 1
3 5.8
5 9.5
7.5 14
10 18
15 24
20 30
25 39
30 46
40 61
50 72
60 90
75 1 10
100 150
150 180
175 202
300 370
400 450
Version 3.06 | Optidrive Eco User Guide | 5
