1-1 Major Feature

1. Intel Cedarview-M N2600 1.6GHz CPU
2. Intel Cedarview-M and NM10 chipset on board
3. Intel Cedarview-M Integrated Graphics chipset,
N2600 400 MHz render clock frequency. Support Directx* 10.1 compliant
Pixel Shader* v2.0 and OGL 3.0, Display Ports: HDMI or DVI, CRT
4. On board DDR3 SDRAM 2GB, N2600 Memory DDR3 data transfer rate of 800MT/s
5. On board SSD 2/4/8/16/32/64 GBytes (Option)
6. Support 1 x 10 / 100 / 1000 Mbps Realtek LAN
7. Support extended 2 x Mini PCIe card ( full size & half size)
8. One SATA port with independent DMA operation supported
mSATA share with mini PCIe (Option)
9. 1 x HDMI support resolution up to 1920 x 1200
10. Hardware digital Input & Output, 4 x DI / 4 x DO (Option)
Hardware Watch Dog Timer, 0~255 sec programmable (Option)
11. On board DC +12V
12. PCB Dimension: 102 x 73 mm (2.5 inch)
13. One 3G SIM card socket (Option)
