Chapter-1
General lnformation
The 2I260A is a 2.5 inches form factor All-In-One Board. The board design combines
all necessary input and output effects interfaces, which makes itself an ideal all-in-one control
board for Digital Signage and Thin Client application. Due to its compact size,
2I260A is also the perfect platform for a whole range of small form factor and
low-power devices, such as mobile PC or small panel PC
The 2I260A All-In-One motherboard is with Intel Cedar view-M N2600 1.6GHz CPU
(Dual core processor), Intel Cedarview-M + NM10 chipset and Intel Cedar view-M
Integrated Graphics chipset. This integrated Cedar View platform offers superb performance
and PC specification in the industry.
Despite the limited space of 2I260A, it supports 2 COM ports of RS232 (or RS485) and
multi-ports of Hi-Speed USB 2.0 to enhance the host controller interface which will ensure
the high performance level and flexible expansion.
2I260A is supported with one 10/100/1G Ethernet for seamless broadband
connectivity. With Wake-On LAN function and the PXE function in BIOS,
these are perfect control boards for networking devices. The built-in Lan is
RTL8111F LAN chipset for PCIe x 1 interface, integrated 10/100/1000 transceiver.
The 2I260A motherboard is built in on board DDR3 SDRAM 2GB, N2600 Memory DDR3 data
transfer rate of 800MT/s and optional with On board SATA SSD 2/4/8/16/32/64---GBytes.
The expendable interfaces include one full size PCIe Mini card for PCIe by one and
USB interface, one half size PCIe Mini card for mSATA and USB interface.
The All-In-One motherboard 2I260A is fully compatible with industry standards,
plus technical enhancements and thousands of software applications developed for
IBM PC/AT compatible computers. These control logic provides high-speed performance
for the most advanced multi user and multitasking applications available today.
