Drain Up Kit
K-KDU303KVE
Read this manual and the BS/SV unit manuals carefully before use.
Safety precautions
Read these ''Safety precautions'' carefully before performing installation work.
The precautions shown here are divided into a ''
Warning'' and ''
Caution'' section, but those that
are likely to lead to serious consequences such as death or serious injury if the installation is performed
incorrectly are noted collectively in the ''
Warning'' section. However, even the items described in the
''
Caution'' section may lead to serious consequences depending on the situation. Observe all of the
following, as each contains important information regarding safety.
After the installation work is complete, perform a test run and check that there are no abnormalities.
In addition, ask the customer to keep this manual for future reference.
Warning
• For drainage of BS/SV units. Do not use for any other application. If the usage application is incorrect,
fire/water leakage, etc. may result.
• Regarding the installation, ask your dealer or a specialist. If you perform installation work yourself and
there are imperfections in the installation, water leakage/electrocution/fire may result.
• Make sure to perform installation work properly according to the installation manual (16). If there are
imperfections in the installation, water leakage/electrocution/fire may result.
• For the safety circuit power supply wire (3), shape the wire so that the service cover of the BS/SV unit
does not rise. Install the service cover securely. If the service cover is not installed completely, electrocu-
tion/fire may result.
• Perform earthing work.
Do not connect earth wires to gas pipes, water pipes, lightning rods, or
telephone earth wires. If earthing is performed incorrectly, electrocution may result.
• For installation parts, be sure to use accessories and parts with the designated specifications. If parts
without the designated specifications are used, water leakage/electrocution/fire may result.
• Turn off the power supply before performing installation work. If electrical parts are touched while the
power supply is turned on, electrocution may result.
• Connect the wire securely using the specified power supply wire (3). Secure it properly so that the
external force from the wire is not applied to the terminal connection part. If connections are incomplete
or incorrectly secured, heat generation/fire at the terminals may result.
• Install the product securely in a place that can sufficiently withstand the weight of the kit. If the strength
is insufficient, the kit may fall and cause injuries.
Caution
• For drainage work, install the pipes according to this installation manual (16) to ensure proper drainage
and insulate them to prevent condensation. If there are imperfections in the pipe work, water may leak
and cause household goods to get wet.
• Do not install in locations such as the following:
- Locations where flammable gas may leak, locations where carbon fibre and flammable dust float, or
locations where volatile flammable materials such as thinner and gasoline are handled. If gas leaks
and collects around the drain up kit (1), fire may result.
- Locations with machines that generate electromagnetic waves. These may cause abnormalities in the
control system, making normal operation impossible.
Drain up specifications
Main applicable models
BS4A14AJV1B
Insulation
BS6A14AJV1B
BS8A14AJV1B
BS10A14AJV1B
BS12A14AJV1B
Exterior
White (Munsell 10Y9/0.5)
Drain inlet connection pipe diameter
Maximum lift (mm)
1000 (*)
Drain outlet connection pipe diameter
Drain discharge flow rate (L/h)
24
Safety device
Power supply
Single-phase 220-240V, 50Hz
Operation sound (dB)
Power consumption (W)
14.1
Product weight (kg)
Operation current (A)
0.18
*
Height from the bottom of the drain up kit (1) to the drain pipe
** Connected with the soft socket (10)
*** Connected to VP20 with the soft drain pipe (11)
Components
Name
Shape
Qty
Name
Shape
Hose clamp
Drain up kit
1
(small) (8)
(1)
Relay harness
Hose clamp
1
(2)
(big) (9)
Soft socket
Power supply
1
(10)
wire (3)
VP13
160
Thermal
Soft drain pipe
1
VP20
insulation (4)
(11) (for drain
200
15X70Xt3
outlet)
Thermal
Casing screw
1
insulation (for
+ washer (12)
drain inlet) (5)
30X130Xt5
Thermal
1
Screw (13)
insulation (for
50X180Xt10
M4X8
drain outlet) (6)
Clamp
Hanger metal
4
material (7)
(14)
Installation Manual
Operation
Tapping
5
manual (17)
screw (15)
M5X35
Installation
manual (16)
1
Parts required for installation (field supply)
Elbow
Thermal insulation
Horizontal drain pipe (VP20)
BS/SV unit
Standing drain pipe (VP20)
Drain position
The drain up kit (1) can only be installed on the right side of the BS/SV unit. Before installing the drain up
kit (1), make sure that you have enough room above it to install the drain pipes at the outlet.There are
two ways of installing the drain up kit (1): close-by or at a slight distance. Installing the drain up
kit (1) close-by is only advised when the ducting is installed on the other side or when no ducting is
installed at all.
Insulated refrigerant pipes
(Field supply)
Accessory BS/SV unit
Soft socket
(10)
BS/SV unit
(Duct closing plate or damper only)
When the ducting is installed on the same side as the drain up kit (1), there is not enough room to properly
Type E
conduct maintenance on the drain up kit (1). In this case, it is advised to use PVC pipes to install the drain
up kit (1) further away.
VP13 (**)
VP20 (***)
Float switch
25
Insulated refrigerant pipes
3.2
(Field supply)
Accessory BS/SV unit
Soft socket (10)
Qty
BS/SV unit
4
Air ducting pipe
(Field supply)
1
Drain pipe (VP13)
(Field supply)
Soft socket (10)
2
Minimum downward slope:1/100
1
Note 1: Secure the space required on the right of the BS/SV unit and the space required for service
around the drain up kit (1) installation location.
1
Note 2: Field supply pipes such as PVC pipes cannot be connected directly to the drain inlet and drain
outlet of the drain up kit (1). Use the accessories described in the installation manual (16).
1. Preparation before installation
4
Preparation of the drain up kit (1)
Separate the casing and drain up kit (1) from the mounting plate.
1. Remove the casing fixing screw and washer (12). Lower the casing and pull it forward to
2
separate it from the drain up kit (1).
2. Remove the 2 drain up kit fixing screws. Lift the drain up kit (1) to separate it from the mounting plate.
3P678074-1A
Drain up kit (1)
Drain up kit
fixing screw
Casing
1
Washer (12)
Casing
fixing screw (12)
Both soft sockets (10) as well as the soft drain pipe (11) can be cut if a shorter length is preferred. Howev-
er, make sure that the pipe never risks kinking, as a kink obstructs the flow of the drained water.
2. Preparation of the BS/SV unit
Caution
• Work with the power supply turned off.
• When connecting terminals to the inter-unit wiring terminal block, attach them correctly. If the crimp
terminals are both installed in the same orientation accidentally, the terminal contact area decreases
and there will be a risk of overheating and burning.
-
Precautions for power supply wire (3) (includes the earth wire)
Use round type crimp terminals to connect the inter-unit wiring terminal block and the earth wire. If for
some reason you cannot use round type terminals, observe the following items.
