Summary of Contents for Daikin KPW5E112
- Page 1 INSTALLATION MANUAL Wind Baffle ACCESSORY MODEL NO. KPW5E112 SKY-AIR RELATED PRODUCTS RKS30LVJU RKS36LVJU RXS30LVJU RXS30LVJU VRV IV RELATED PRODUCTS RXTQ36TAVJU RXTQ48TAVJU...
- Page 2 INSTALLATION MANUAL KPW5E112 1. BEFORE INSTALLATION a. Components i. Make sure that the accessories shown below are all present. Name Wind Baffle Set Screw Manuals, etc. Quantity 1 pc. 4 pcs. per each wind baffle 1 pc. Installation Shape Manual 2.
- Page 3 INSTALLATION MANUAL KPW5E112 4. INSTALLATION OF WIND BAFFLE Do not remove existing standard grill for your safety. Wind baffle is designed for installation over the existing grill. Removal of existing grill will expose rotating parts of the fan and can cause injury.
- Page 4 INSTALLATION MANUAL KPW5E112 e. Illustration showing the completed mounting of the Wind Baffle (with the air blowing in the upper direction). 4 ...
