- Page 1 INSTALLATION AND OPERATION MANUAL Option kit for combination of Daikin condensing units with field supplied evaporators EKEXMCBV3...
- Page 2 OTES expansion valve liquid remocon outdoor ON/OFF R3 R4 R1 R2 R5 R6 P1 P2 F1 F2 T1 T2 H3 H4 H6 X24A H3 H5 H5...
- Page 3 3PW26871-3C...
-
Page 4: Table Of Contents
Installation and Option kit for combination of Daikin condensing units EKEXMCBV3 operation manual with field supplied evaporators ONTENTS EFORE INSTALLATION Page Introduction ............... 1 The system will operate as a standard indoor unit to control the room temperature. This system does not require a specific Before installation................ -
Page 5: Name And Function Of Parts
Additional limits exist when connecting the EKEXMCB control box. These can be found in the technical data book of the EKEXMCB and in this manual. EKEXMCBV3 Installation and operation manual Option kit for combination of Daikin condensing units with field supplied evaporators 4PW32096-1... -
Page 6: Selecting The Installation Site
L is to be considered as a part of the total maximum piping length. See installation manual of the outdoor unit for piping installation. EKEXMCBV3 Installation and operation manual Option kit for combination of Daikin condensing units with field supplied evaporators 4PW32096-1... -
Page 7: Valve Kit Installation
Outlet to evaporator Pipe fixing clamp Remove the pipe fixing clamp (C) by unscrewing 2x M5. Remove the upper and lower pipe insulations. EKEXMCBV3 Installation and operation manual Option kit for combination of Daikin condensing units with field supplied evaporators 4PW32096-1... -
Page 8: Installation Of The Electrical Control Box
Use a small screwdriver and follow indicated instructions for wrap.- connecting cable wires into the terminal connector according to the wiring diagram. EKEXMCBV3 Installation and operation manual Option kit for combination of Daikin condensing units with field supplied evaporators 4PW32096-1... - Page 9 X1M-Y1~6 ..Expansion valve RED ....Red X1M-P1/P2 ..Communication remote controller WHT....White X1M-T1/T2..Input: ON/OFF YLW ....Yellow X1M-F1/F2..Communication line EKEXMCBV3 Installation and operation manual Option kit for combination of Daikin condensing units with field supplied evaporators 4PW32096-1...
-
Page 10: Installation Of Thermistors
For room temperature control the delivered thermistor (R1T) can be replaced by an optional remote sensor kit KRCS01-1(A) (to be ordered separately). EKEXMCBV3 Installation and operation manual Option kit for combination of Daikin condensing units with field supplied evaporators 4PW32096-1... -
Page 11: Refrigerant Piping Work
Failure to this will cause a If the unit collects ice: see "Troubleshooting" on page safety to operate or freezing up of the evaporator (air handling unit). EKEXMCBV3 Installation and operation manual Option kit for combination of Daikin condensing units with field supplied evaporators 4PW32096-1... -
Page 12: Troubleshooting
Check if the heat source of the room is excessive. Cooling effect decreases if heat gain of the room is too large. EKEXMCBV3 Installation and operation manual Option kit for combination of Daikin condensing units with field supplied evaporators 4PW32096-1... - Page 13 NOTES NOTES...
