Page 2: Know Your Device
Know your device ACT 400-m Device view Pinout ACT 400-m 2x6 socket pinout Pin name Description number VCC (10-30) V DC (+) Power supply (+10-30 V DC). Digital output, channel 3. Open collector output. Max. DOUT 3 0,5 A DC. Analog input, channel 2. -
Page 3: Wiring Scheme
Wiring scheme ACT 400-m Wiring scheme Set up your device How to insert Micro-SIM card and connect the battery Cover removal Micro-SIM card insert Battery connection Attaching cover back... -
Page 4: Mounting Recommendations
1. Gently remove ACT 400-m cover using plastic pry tool from both sides. 2. Insert Micro-SIM card as shown with PIN request disabled or read our Wiki how to enter it later in Amber Configurator. Make sure that Micro-SIM card cut-off corner is pointing forward to slot. 3. - Page 5 Status LED indications Behaviour Meaning Blinking every second Normal mode Blinking every two seconds Sleep mode Blinking fast for a short time Modem activity Device is not working or Device is in boot mode Characteristics Basic characteristics Module Name ACT 400-m Technology LTE CAT M1/NB-IoT/GSM/GPRS/GNSS/BLUETOOTH GNSS...
- Page 6 At 12V < 18 mA (GPS Sleep) At 12V < 34 mA (nominal with no load) At 12V < 2A Max. (with full Load / Peak) Bluetooth Specification 4.0 + LE Temperature and Humidity sensor, Headset, OBDII Supported peripherals dongle, Inateck Barcode Scanner, Universal BLE sensors support Interface Digital Inputs...
-
Page 7: Electrical Characteristics
Electrical characteristics Value Characteristic description Min. Typ. Max. Unit Supply Voltage Supply Voltage (Recommended Operating Conditions) Digital Output (Open Drain grade) Drain current μA (Digital Output OFF) Drain current (Digital Output ON, Recommended Operating Conditions) Static Drain-Source resistance (Digital mΩ Output ON) Digital Input kΩ... -
Page 8: Safety Information
Output current (U > 3.0 V) Short circuit current (U = 0) NEGATIVE INPUT kΩ Input resistance 38.45 Input voltage (Recommended Operating Supply Conditions) voltage Input voltage threshold Sink current Safety information This message contains information on how to operate ACT 400-m safely. By following these requirements and recommendations, you will avoid dangerous situations. -
Page 9: Certification And Approvals
Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Battery should not be disposed of with general household waste. Bring damaged or worn-out batteries to your local recycling center or dispose them to battery recycle bin found in stores. - Page 10 hereby excluded. also excluded from this limited warranty are any and all incidental or consequential damages including but not limited to, loss of use or revenue, loss of time, inconvenience or any other economic loss.
