Summary of Contents for amber connect Covert T300
-
Page 2: Know Your Device
Know your device ACT 300 Device view Pinout ACT 300 2x6 socket pinout Pin name Description number VCC (10-30) V DC (+) Power supply (+10-30 V DC). Digital output, channel 3. Open collector output. Max. DOUT 3 0,5 A DC. Analog input, channel 2. -
Page 3: Wiring Scheme
Wiring scheme ACT 300 Wiring scheme Set up your device How to insert Micro-SIM card and connect the battery Cover removal Micro-SIM card insert Battery connection Attaching cover back... -
Page 4: Mounting Recommendations
1. Gently remove ACT 300 cover using plastic pry tool from both sides. 2. Insert Micro-SIM card as shown with PIN request disabled or read our Wiki how to enter it later in Amber Configurator. Make sure that Micro-SIM card cut-off corner is pointing forward to slot. 3. - Page 5 Status LED indications Behaviour Meaning Blinking every second Normal mode Blinking every two seconds Sleep mode Blinking fast for a short time Modem activity Device is not working or Device is in boot mode Characteristics Basic characteristics Module Name ACT 300 Technology 3G(UMTS/HSPA)/2G(GSM/GPRS)/GNSS/BLUETOOTH GNSS...
-
Page 6: Electrical Characteristics
Interface Digital Inputs Negative Inputs 1 (Digital input 2) Digital Outputs Analog Inputs CAN interfaces 1-Wire GNSS antenna Internal High Gain GSM antenna Internal High Gain 2.0 Micro-USB LED indication 2 status LED lights Micro-SIM + eSIM Memory 128MB internal flash memory Physical specification Dimensions 65 x 56.6 x 20.6 mm (L x W x H) - Page 7 Value Characteristic description Min. Typ. Max. Unit Supply Voltage Supply Voltage (Recommended Operating Conditions) Digital Output (Open Drain grade) Drain current μA (Digital Output OFF) Drain current (Digital Output ON, Recommended Operating Conditions) Static Drain-Source resistance (Digital mΩ Output ON) Digital Input kΩ...
-
Page 8: Safety Information
NEGATIVE INPUT kΩ Input resistance 38.45 Input voltage (Recommended Operating Supply Conditions) voltage Input voltage threshold Sink current Safety information This message contains information on how to operate ACT 300 safely. By following these requirements and recommendations, you will avoid dangerous situations. You must read these instructions carefully and follow them strictly before operating the device! •... -
Page 9: Certification And Approvals
Battery should not be disposed of with general household waste. Bring damaged or worn-out batteries to your local recycling center or dispose them to battery recycle bin found in stores. Certification and Approvals • ACT 300 CE / RED •...
