Summary of Contents for amber connect Amber Govern T400-la
-
Page 2: Know Your Device
Know your device AGT400-LA Device view Pinout AGT400-LA pinout Pin name Description number GND (-) Ground CAN 1L SAE J1939 CAN interface Low channel 1 1WIRE POWER Power supply pin for Dallas 1-Wire® devices DIN4 Digital input, channel 1 DIN2 Digital input, channel 2 CAN 2L SAE J1939 CAN interface Low channel 2... -
Page 3: Wiring Scheme
1WIRE DATA Data channel for Dallas 1-Wire® devices DIN3 Digital input, channel 3 Digital input, channel 1. DEDICATED FOR IGNITION IGN (DIN1) INPUT CAN 2H SAE J1939 CAN interface High channel 2 AIN1 Analog input, channel 1. Input range: 0-30V/0-10V DC Digital output. -
Page 4: Mounting Recommendations
Unscrew screws Cover removal SIM card insert Battery connection Attaching cover back Device is ready Mounting recommendations • Connecting wires 1. Wires should be connected while the module is not plugged in. 2. Wires should be fastened to the other wires or non-moving parts. Try to avoid heat emitting and moving objects near the wires. -
Page 5: Connecting Power Source
• Connecting power source 1. Be sure that after the car computer falls asleep, power is still available on chosen wire. Depending on car, this may happen in 5 to 30 minutes period. 2. When the module is connected, measure the voltage again to make sure it did not decrease. - Page 6 Blinking every two seconds Sleep mode Blinking fast for a short time Modem activity Device is not working or Device is in boot mode Characteristics Basic characteristics Module Name AGT 400-LA Technology LTE Cat 1, UMTS, GSM GNSS GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, GNSS DGPS, AGPS Receiver...
-
Page 7: Electrical Characteristics
RS232 RS485 CAN J1939 J1708 K-Line LVCAN/ALLCAN GNSS antenna External High Gain GSM antenna External High Gain 2.0 Mini-USB LED indication 2 status LED lights Micro-SIM 2x SIM Card (Dual-SIM) 2MB internal flash memory and external SD card Memory up to 32 GB. Features Sensors Accelerometer... -
Page 8: Safety Information
Supply Voltage Supply Voltage (Recommended Operating Conditions) Digital Output (Open Drain grade) Drain current μA (Digital Output OFF) Drain current (Digital Output ON, Recommended Operating Conditions) Static Drain-Source resistance (Digital mΩ Output ON) Digital Input kΩ Input resistance (DIN1) kΩ Input resistance (DIN2) kΩ... -
Page 9: Certification And Approvals
• When connecting the 2x10 connector wires to the vehicle, the appropriate jumpers of the vehicle power supply should be disconnected. • Before dismounting the device from the vehicle, the 2x10 connector must be disconnected. • The device is designed to be mounted in a zone of limited access, which is inaccessible to the operator. -
Page 10: Warranty Disclaimer
Directive 2014/53/EU (RED). Warranty Amber connect guarantees its products to be free of any manufacturing defects for a period of 24 months. With additional agreement we can agree on a different warranty period, for more detailed information please contact our sales manager.
