Biomedical Life Systems BioStim NMS2 Instructions Manual page 18

DELAY: The amount of time in seconds between the begininning
of Channel 1 cycle and beginning 2 cycle. (DELAY is available in
the CYCLED mode only). The DELAY can be adjusted from 1-99
seconds.
Note: If a "DELAY" value is set in the CYCLED mode, the number
of seconds set for the DELAY will be automatically deducted from
the OFF TIME of Channel 2, as both Channel 1 and Channel 2 total
cycle times must be the same. The following is an example of a
Cycled Program with a DELAY time of 5 seconds.
Ramp on
Ramp off
On time
Off time
Delay
TOTAL
CH 1
DELAY
CH 2
8.3: Changing Timing Options; RAMP TIME, ON TIME OFF
TIME & DELAY
Step 1: Turn the device OFF and then back ON by pressing the
"ON/OFF" Key (1)
Step 2: Press the "Mode Key" (5)
"Cycled or "RECIPR" appear on the screen.
Channel 1
2.0 sec.
2.0 sec.
20 sec.
10 sec.
N/A
35 sec.
ON TIME
OFF TIME
ON TIME
Channel 2
2.0 sec.
2.0 sec.
10 sec.
15 sec.
5 sec.
35 sec.
OFF TIME
repeatedly until either
