The threads of the lens mount can have sharp edges. Intended use Intended use of Allied Vision product is the integration into vision systems by professionals. All Allied Vision product is sold in a B2B setting. Cameras without closed housings Cameras without housing or with incomplete housing must be shielded against EMC emission by professionals according to local EMC provisions.
Fare for snitsår på linsemodulets skarpe kanter Linsemodulets gevind kan have skarpe kanter. Tilsigtet brug Allied Vision produktets tilsigtede brug er en indbygning i et visionssystem, udført af fagfolk. Alle Allied Vision produkter sælges i B2B. Kameraer uden lukket hus Kameraer uden hus eller uden komplet hus skal beskyttes mod EMC emissioner iht.
VORSICHT Schnitte durch scharfkantige Objektivgewinde Objektivgewinde können scharfe Kanten haben. Bestimmungsgemäßer Gebrauch Allied Vision Produkte sind bestimmt für die Integration in Bildverarbeitungs- systeme durch Fachpersonal. Alle Allied Vision Produkte werden in einer B2B-Umgebung verkauft. Kameras ohne geschlossenes Gehäuse Für Kameras ohne Gehäuse oder mit unvollständigem Gehäuse muss die Abschirmung gegen EMV-Emissionen gemäß...
Las roscas de los objetivos pueden tener bordes afilados. Uso previsto El uso previsto del producto Allied Vision es la integración en el sistema de visión por parte de profesionales. Todos los productos Allied Vision se venden dentro de una relación B2B.
Linssin kiinnikkeiden kierteiden reunat voivat olla teräviä. Käyttötarkoitus Allied Vision -tuotteen käyttötarkoitus on integrointi kuvajärjestelmiin ammattilaisten toimesta. Kaikki Allied Vision -tuotteet myydään B2B-ympäristössä. Kamerat, joissa ei ole suljettuja koteloita Ammattilaisten on suojattava kamerat, joissa ei ole koteloa tai joiden kotelo on epätäydellinen, EMC-päästöiltä...
Les filetages des montures d’objectif peuvent présenter des bords tranchants. Utilisation prévue L’utilisation prévue du produit Allied Vision est son intégration dans des systèmes de vision par le soin de professionnels. Tout produit Allied Vision est vendu dans un cadre B2B. Caméras sans boîtier fermé...
Pericolo di tagliarsi sui bordi affilati degli attacchi della lente I bordi della filettatura dell’attacco della lente possono essere affilati. Uso previsto Il prodotto Allied Vision è concepito per essere integrato in sistemi di monitoraggio in campo professionale. Tutti i prodotti Allied Vision sono venduti in uno scenario B2B.
Risico van snijwonden door scherpe randen van lensbevestigingen Het schroefdraad van de lensbevestiging kan scherpe randen hebben. Beoogd gebruik Het beoogde gebruik van het Allied Vision-product is de integratie in optische systemen door professionals. Alle Allied Vision-producten worden verkocht in de B2B-markt.
Risiko for kutt fra skarpe kanter på linsefester Sporene på linsefestet kan ha skarpe kanter. Tiltenkt bruk Den tiltenkte bruken av Allied Vision-produktet er integrering i visjonssystemer av profesjonelle. Alle Allied Vision-produkter selges i en forretning til forretning-situasjon. Kameraer uten lukkede kamerahus Kameraer uten kamerahus eller med ufullstendige kamerahus må...
Objektivets gängor kan ha vassa kanter. Avsedd användning Den avsedda användningen av Allied Vision-produkter är integrering i visionssystem av fackmän. Samtliga Allied Vision-produkter säljs i en B2B-miljö. Kameror utan slutna kamerahus Kameror utan eller med ofullständiga kamerahus måste skyddas mot elektromagnetiska emissioner av fackmän enligt lokala bestämmelser för...
Alvium CSI-2 cameras at a glance Get an overview of Alvium CSI-2 camera documentation: Notes ..................15 Consider for Alvium CSI-2 cameras........15 Specifications status.............. 15 Shipping contents..............15 What else do you need? ............16 Alvium CSI-2 Cameras User Guide V2.8.1...
Alvium CSI-2 cameras at a glance Notes Read this document carefully Learn to avoid damage to your Alvium CSI-2 camera and use it in the most safe and efficient way. NOTICE Damage to camera and embedded hardware by improper handling Setup and operation for Alvium CSI-2 cameras in embedded systems is different than for cameras in PC-based systems.
Alvium CSI-2 cameras at a glance What else do you need? This is a selection of helpful downloads: Download Link Controls and features Alvium CSI-2 Register Controls www.alliedvision.com/en/support/technical- Reference documentation/alvium-csi-2-documentation www.alliedvision.com/en/support/technical- GenICam Alvium Features Reference for CSI-2 documentation/alvium-csi-2-documentation Access Applications www.alliedvision.com/en/support/technical- Application notes documentation/alvium-csi-2-documentation...
Document history and conventions This chapter includes: Document history ..............26 Conventions used in this user guide........31 Naming and terms ..............33 Alvium CSI-2 Cameras User Guide V2.8.1...
Document history and conventions Document history Version Date Remarks V2.8.1 2022-Jul-22 • Added values for minimum and maximum exposure times in Specifications on page 47. • Corrected dimensions for screws from M2 to M1.6 Mounting bare board cameras on page 205. Firmware version: 00.10.00.6c9062b1 V2.8.0 2022-Jul-20...
Page 27
Document history and conventions Version Date Remarks Firmware version: 00.08.00.6727174b V2.7.0 2022-Mar-17 • Added contents for GenICam for CSI-2 Access at various places, including User sets on page 176. • Renamed Alvium 1800 C-030m VSWIR to Alvium 1800 C-030 VSWIR, and Alvium 1800 C-130m VSWIR correspondingly.
Page 28
Document history and conventions Version Date Remarks Firmware version: 00.07.00.81db3896 V2.6.0 2021-Nov-03 • Added 1800 C-030m VSWIR and 1800 C-130m VSWIR models in Specifications page 47 and in Lenses: Focal length vs. field of view on page 179. • Added Digital Binning on page 50.
Page 29
Document history and conventions Version Date Remarks Firmware version: 00.04.00.34658 V2.4.0 2021-Apr-08 • Added RAW pixel formats for 10-bit and 12-bit Mono in Specifications on page 47. • Added 1800 C-2460m/c models in Specifications on page 47. • Updated mass values in Dimensions and mass page 166.
Page 30
Document history and conventions Version Date Remarks Firmware version: 00.02.00.29974 V2.2.0 2020-Jul-22 • Added Alvium 1800 C-240m/c, 1800 C-508m/c, and 1800 C-1240m/c models. • Updated ROI frame rates and pixel formats in Specifications on page 47. • Updated Type for Alvium 1500 C-210m/c on page •...
Document history and conventions Version Date Remarks Firmware version: 00.01.02.28100 V2.0.0 2020-Jan-06 • Added Alvium 1500 C-210m/c, 1800 C-040m/c, and 1800 C-158m/c models. • Added descriptions for Hue and Saturation in Access modes on page 194. • Added Dark current compensation on page 237.
Document history and conventions Style Function Input commands Text or command to type in by the user, selected menu options, or other selectable options UIElements Text that is displayed or output by the system, like parts of the GUI, dialog boxes, buttons, menus, important information, or windows titles Web addresses and Links to webpages and internal cross references...
Document history and conventions GenICam for CSI-2 Access Selected Alvium 1800 C models support GenICam for CSI-2 Access, see Access modes on page 194. Data in this document applies to all Alvium CSI-2 cameras if not otherwise stated. Data applying to GenICam for CSI-2 Access is marked as follows: Paragraphs and graphics GenICam...
Resolution Color/ element series monochrome Examples Alvium 1500: Basic feature set C: MIPI CSI-2 500: 5.0 MP c: color 1800: Advanced feature set U: USB 050: 0.5 MP m: monochrome or high-performance sensors Model resolutions may slightly deviate from model naming.
Page 35
Term or acronym Description Reference Electrostatic discharge on page 41 FPC cable (MIPI CSI-2 FPC cable) Flexible printed circuit Alvium Cameras Accessory Guide at cable, component that connects embedded www.alliedvision.com/en/support/ boards and cameras via adapter board technical-documentation/ alvium-csi-2-documentation. FPC connector Hirose FH55-22S-0.5SH connector...
Compliance, safety, and intended use This chapter includes: Camera identification............37 Compliance notifications ............37 Intended use ................. 38 Copyright and trademarks ............ 38 Your safety................39 Product safety ............... 41 Alvium CSI-2 Cameras User Guide V2.8.1...
Compliance, safety, and intended use Camera identification You can identify your Alvium CSI-2 open housing camera like this: Model ID (for DoC) Camera series Camera model Product code Serial number Open housing Alvium CSI-2 cameras have the Model ID: A 1 B. Preparations to introduce Model IDs for Alvium bare board cameras are ongoing.
We are offering standard products as well as customized solutions. Intended use of Allied Vision product is the integration into Vision systems by professionals. All Allied Vision product is sold in a B2B setting.
Compliance, safety, and intended use Your safety This section informs about issues related to your personal safety. Descriptions explain how to avoid hazards and operate Alvium CSI-2 cameras safely. Handling lens mounts The lens mount thread has sharp edges. Be careful these edges do not cut your skin when mounting or unmounting lenses.
Compliance, safety, and intended use For your safety and to improve camera performance, operate the camera: • Mounted to a base with a high thermal conductivity • With lens or other optical components mounted • With a heat sink mounted that has large surface areas (closed housing cameras include a heat sink) •...
Electrical connections The MIPI CSI-2 standard does not specify electrical connections as extensively as the USB or GigE standard. Read specifications carefully. Allied Vision accessories help to avoid damage to the camera and connected components.
Compliance, safety, and intended use • Housing: use an ESD housing, including the camera, embedded board, adapter board, and MIPI CSI-2 FPC cable. Cable connections Provide sufficient strain relief for all cable connections to avoid short circuits and malfunctions. PCBAs Alvium CSI-2 cameras enable access to PCBAs.
MIPI CSI-2 FPC cables Manufacturing FPC cables or embedded boards If you want to design your own components to connect Alvium CSI-2 cameras to embedded boards, contact your Allied Vision Sales representative or visit www.alliedvision.com/en/about-us/contact-us/technical-support-repair-/-rma. FPC cable position Short circuits of the FPC cable can damage the camera or connected hardware.
Noise and electromagnetic interference can disable camera functions. • Avoid contact to metal surfaces, causing electromagnetic interference. • Please use cables recommended by Allied Vision. Handling bare board cameras Bare board cameras are an electronic assembly without a protective housing.
Compliance, safety, and intended use Optical components Provide the following conditions to keep dirt and droplets out of the optical system of camera and lens: • Dust-free environment • Low relative humidity • No condensation. When camera or lens are stored: •...
Compliance, safety, and intended use Lenses Maximum protrusion The sensor, filter, lens, or camera electronics can be damaged if a lens exceeding maximum protrusion is mounted to the camera. Use lenses with a maximum protrusion within camera specifications. Figure 4 shows maximum protrusion.
Specifications This chapter includes: Applied standards ..............48 Notes on specifications............51 Alvium 1500 C model specifications........58 Alvium 1800 C model specifications........78 White balance default............165 Dimensions and mass ............166 Technical drawings .............. 166 Lens mounts and maximum protrusion ......172 IR cut filter................
MIPI CSI-2 The MIPI (Mobile Industry Processor Interface) CSI (Camera Serial Interface) -2 standard describes a class of MIPI CSI-2 cameras for still image photography and video streaming. Generically, MIPI CSI-2 cameras are operated by Direct Register Access. Alvium CSI-2 cameras have a MIPI CSI-2 interface. They comply with: •...
Specifications Cameras were inspected before and after the tests. All tests were passed successfully: Condition Passed Mechanics • The camera housings showed no deformations. • The connections between camera components had not come loose. • The sensor position was within the specified tolerances of a new camera. Camera behavior Camera functionalities were not affected, no deviations occurred.
Specifications IEC 60068-2-27: Shock Parameter Value Axis x, y, z Acceleration 20 g Number of shocks per axis Duration per axis 11 ms Waveform Half sine Table 11: Parameters for IEC 60068-2-27 tests IEC 60068-2-64: Random vibration Frequency Acceleration 15 Hz to 500 Hz 0.05 g Table 12: Frequency and acceleration for IEC 60068-2-64 tests Parameter...
Specifications Notes on specifications This section defines the conditions for specifications stated in this chapter. Sensor Absolute QE plots Measurements for color cameras were done with IR cut filter, measurements for monochrome and S-Mount cameras were done without optical filters. With optical filters, QE decreases by approximately 10 percent.
Specifications Exposure time and frame rates Achieved values deviating from specified values Values stated in the model specifications show the maximum available on an ideal system, supporting a bandwidth of 1.051 Gbps per lane. Your individual setup may affect available values such as for: •...
Specifications Readout modes to reduce the bandwidth GenICam for CSI-2 Selected Alvium CSI-2 camera models support various readout modes. This is Access stated in the tables for ROI frame rates. If you are using pixel formats that do not require 12-bit sensor readout and you want to achieve higher frame rates, you can select between readout modes for 12-bit, 10-bit, and 8-bit with some Alvium USB camera models.
Specifications Continued from the previous page. GenICam for CSI-2 Access ExposureMode = TriggerWidth or TriggerControlled In addition, most global shutter (GS) cameras can control exposure time by the trigger signal, with the set to ExposureMode TriggerWidth TriggerControlled (using ExposureStart ExposureStop The trigger controlled exposure time is extended automatically: •...
Specifications Frame rates with rolling shutter sensors The following table shows how the shutter type impacts available frame rates. Reducing the area for ROI reduces readout time. The relations in Table 16 apply only if exposure time is shorter than readout time. Sensor type Shutter mode Trigger mode...
Specifications Sensor shutter types Differences between global shutter (GS), rolling shutter (RS), and global reset shutter (GRS, GenICam for CSI-2 Access only) sensors are explained in Shutter types affecting image readout on page 239. Triggering behavior differs between cameras with global shutter (GS) and rolling shutter (RS). See Triggering on page 220 for details.
GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 1.3 W (typical, at 5 VDC) Table 17: Alvium 1500 C-050m/c specifications (sheet 1 of 2)
Page 59
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE ON Semi PYTHON 480 absolute QE 1000 1050 1100 Wavelength [nm] Figure 5: Alvium 1500 C-050m/c (ON Semi PYTHON 480) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.300 ON Semi PYTHON 480 spectral response...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 1 lane with 1.051 Gbps.
GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 1.1 W (typical, at 5 VDC) In triggered mode, maximum frame rates require minimum exposure times.
Page 63
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE ON Semi AR0135CS absolute QE 1000 1050 1100 Wavelength [nm] Figure 7: Alvium 1500 C-120m/c (ON Semi AR0135CS) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.350 ON Semi AR0135CS spectral response 0.300...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 1 lane with 1.051 Gbps.
2 programmable GPIOs GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 1.9 W (typical, at 5 VDC) In triggered mode: 59 fps Table 21: Alvium 1500 C-210m/c specifications (sheet 1 of 2) Alvium CSI-2 Cameras User Guide V2.8.1...
Page 67
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE 100% ON Semi AR0521 absolute QE 1000 1050 1100 Wavelength [nm] Figure 9: Alvium 1500 C-210m/c (ON Semi AR0521HD) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.400 ON Semi AR0521 spectral response...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 2 lanes with 2.102 Gbps.
2 programmable GPIOs GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 1.9 W (typical, at 5 VDC) In triggered mode: 34 fps Table 23: Alvium 1500 C-500m/c specifications (sheet 1 of 2) Alvium CSI-2 Cameras User Guide V2.8.1...
Page 71
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE 100% ON Semi AR0521 absolute QE 1000 1050 1100 Wavelength [nm] Figure 11: Alvium 1500 C-500m/c (ON Semi AR0521SR) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.400 ON Semi AR0521 spectral response...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 1.9 W (typical, at 5 VDC) In triggered mode: 34 fps Table 25: Alvium 1500 C-501m/c NIR specifications (sheet 1 of 2) Alvium CSI-2 Cameras User Guide V2.8.1...
Page 75
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE 100% ON Semiconductor AR0522 absolute QE 1000 1050 1100 Wavelength [nm] Figure 13: Alvium 1500 C-501m/c NIR (ON Semi AR0522) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.450 ON Semiconductor AR0522 spectral response...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 1.8 W (typical, at 5 VDC) Table 27: Alvium 1800 C-030 VSWIR specifications (sheet 1 of 2)
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 1 lane with 1.051 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 1.7 W (typical, at 5 VDC) Table 29: Alvium 1800 C-040m/c specifications (sheet 1 of 2)
Page 82
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX287 absolute QE 1000 Wavelength [nm] Figure 16: Alvium 1800 C-040m/c (Sony IMX287) absolute QE Spectral response Figure 17: Alvium 1800 C-040m/c (Sony IMX287) spectral response Alvium CSI-2 Cameras User Guide V2.8.1...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 2 lanes with 2.102 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 3.8 W (typical, at 5 VDC) Table 31: Alvium 1800 C-052m/c specifications (sheet 1 of 2)
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 1.9 W (typical, at 5 VDC) Table 33: Alvium 1800 C-130 VSWIR specifications (sheet 1 of 2)
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 1 lane with 1.051 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 2.4 W (typical, at 5 VDC) Table 34: Alvium 1800 C-158m/c specifications (sheet 1 of 2)
Page 92
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX273 absolute QE 1000 Wavelength [nm] Figure 20: Alvium 1800 C-158m/c (Sony IMX273) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX273 spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 1.9 W (typical, at 5 VDC) Table 35: Alvium 1800 C-234m/c specifications (sheet 1 of 2)
Page 96
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications ROI frame rates Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 1 lane with 1.051 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 2.6 W (typical, at 5 VDC) Table 37: Alvium 1800 C-235m/c specifications (sheet 1 of 2)
Page 100
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX174 absolute QE 1000 Wavelength [nm] Figure 25: Alvium 1800 C-235m/c (Sony IMX174) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX174 spectral response 0.3000 0.2000 0.1000...
Specifications ROI frame rates Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 2.7 W (typical, at 5 VDC) Table 39: Alvium 1800 C-240m/c specifications (sheet 1 of 2)
Page 104
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX392 absolute QE 1000 Wavelength [nm] Figure 27: Alvium 1800 C-240m/c (Sony IMX392) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX392 spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 3.8 W (typical, at 5 VDC) Table 41: Alvium 1800 C-291m/c specifications (sheet 1 of 2)
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 1.9 W (typical, at 5 VDC) Table 43: Alvium 1800 C-319m/c specifications (sheet 1 of 2)
Page 111
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX265 absolute QE 1000 Wavelength [nm] Figure 29: Alvium 1800 C-319m/c (Sony IMX265) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX265 spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 2 lanes with 2.102 Gbps.
Specifications Alvium 1800 C-500m/c GenICam for CSI-2 Access signal that GenICam for CSI-2 Access is required. Red table boarder lines Feature Specification 1800 C-500m (monochrome) 1800 C-500c (color) Sensor model ON Semiconductor AR0521SR Resolution 2592 (H) × 1944 (V); 5.0 MP Sensor type CMOS Shutter type...
Page 115
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane GenICam V2.0 (GenICam for CSI-2 Access) Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE 100% ON Semi AR0521 absolute QE 1000 1050 1100 Wavelength [nm] Figure 31: Alvium 1800 C-500m/c (ON Semi AR0521SR) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.400 ON Semi AR0521 spectral response...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
Specifications Alvium 1800 C-507m/c GenICam for CSI-2 Access signal that GenICam for CSI-2 Access is required. Red table boarder lines Feature Specification 1800 C-507m (monochrome) 1800 C-507c (color) Sensor model Sony IMX264 Resolution 2464 (H) × 2056 (V); 5.1 MP Sensor type CMOS Shutter type...
Page 119
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane GenICam V2.0 (GenICam for CSI-2 Access) Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX264 absolute QE 1000 Wavelength [nm] Figure 33: Alvium 1800 C-507m/c (Sony IMX264) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX264 spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 2 lanes with 2.102 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 2.8 W (typical, at 5 VDC) Table 49: Alvium 1800 C-508m/c specifications (sheet 1 of 2)
Page 123
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX250 absolute QE 1000 Wavelength [nm] Figure 35: Alvium 1800 C-508m/c (Sony IMX250) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX250 spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
Specifications Alvium 1800 C-511m/c GenICam for CSI-2 Access signal that GenICam for CSI-2 Access is required. Red table boarder lines Feature Specification 1800 C-511m (monochrome) 1800 C-511c (color) Sensor model Sony IMX547 Resolution 2464 (H) × 2064 (V); 5.1 MP Sensor type CMOS Shutter type...
Page 127
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane GenICam V2.0 (GenICam for CSI-2 Access) Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX54x absolute QE 1000 Wavelength [nm] Figure 37: Alvium 1800 C-511m/c (Sony IMX547) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX54x spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 3.1 W (typical, at 5 VDC) Table 53: Alvium 1800 C-811m/c specifications (sheet 1 of 2)
Page 131
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX54x absolute QE 1000 Wavelength [nm] Figure 39: Alvium 1800 C-811m/c (Sony IMX546) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX54x spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 3.7 W (typical, at 5 VDC) Table 55: Alvium 1800 C-812 UV specifications (sheet 1 of 2)
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
Specifications Alvium 1800 C-1236m/c GenICam for CSI-2 Access signal that GenICam for CSI-2 Access is required. Red table boarder lines Feature Specification 1800 C-1236m (monochrome) 1800 C-1236c (color) Sensor model Sony IMX304 Resolution 4112 (H) × 3008 (V); 12.4 MP Sensor type CMOS Shutter type...
Page 138
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane GenICam V2.0 (GenICam for CSI-2 Access) Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX304 absolute QE 1000 Wavelength [nm] Figure 41: Alvium 1800 C-1236m/c (Sony IMX304) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX304 spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 2.9 W (typical, at 5 VDC) In triggered mode: 20 fps Table 59: Alvium 1800 C-1240m/c specifications (sheet 1 of 2) Alvium CSI-2 Cameras User Guide V2.8.1...
Page 142
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX226 absolute QE 1000 Wavelength [nm] Figure 43: Alvium 1800 C-1240m/c (Sony IMX226) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX226 spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 3.2 W (typical, at 5 VDC) Table 61: Alvium 1800 C-1242m/c specifications (sheet 1 of 2)
Page 146
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX54x absolute QE 1000 Wavelength [nm] Figure 45: Alvium 1800 C-1242m/c (Sony IMX545) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX54x spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 3.8 W (typical, at 5 VDC) Table 63: Alvium 1800 C-1620m/c specifications (sheet 1 of 2)
Page 150
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX54x absolute QE 1000 Wavelength [nm] Figure 47: Alvium 1800 C-1620m/c (Sony IMX542) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX54x spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 3.7 W (typical, at 5 VDC) Table 65: Alvium 1800 C-2040m/c specifications (sheet 1 of 2)
Page 154
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX54x absolute QE 1000 Wavelength [nm] Figure 49: Alvium 1800 C-2040m/c (Sony IMX541) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX54x spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
Specifications Alvium 1800 C-2050m/c GenICam for CSI-2 Access signal that GenICam for CSI-2 Access is required. Red table boarder lines Feature Specification 1800 C-2050m (monochrome) 1800 C-2050c (color) Sensor model Sony IMX183 Resolution 5376 (H) × 3672 (V); 19.7 MP Sensor type CMOS Shutter type...
Page 158
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane GenICam V2.0 (GenICam for CSI-2 Access) Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX183 absolute QE 1000 Wavelength [nm] Figure 51: Alvium 1800 C-2050m/c (Sony IMX183) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX183 spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
2 programmable GPIOs As direct inputs (push-pull): 0 to 5.5 VDC As direct outputs (push-pull): 0 to 3.3 VDC at 12 mA Power requirements Power over MIPI CSI-2 Power consumption 3.8 W (typical, at 5 VDC) Table 69: Alvium 1800 C-2460m/c specifications (sheet 1 of 2)
Page 162
Open housing Relative humidity 0% to 80% (non-condensing) Digital interface MIPI CSI-2 D-PHY V1.1; 1, 2, or 4 lanes; maximum 1.051 Gbps per lane Camera controls V4L2 controls (Video4Linux Access), Direct Register Access Mounting the heat sink on page 204.
Specifications Absolute QE Blue QE Green QE Red QE Monochrome QE Sony IMX54x absolute QE 1000 Wavelength [nm] Figure 53: Alvium 1800 C-2460m/c (Sony IMX540) absolute QE Spectral response Blue Response Green Response Red Response Monochrome Response 0.4000 Sony IMX54x spectral response 0.3000 0.2000 0.1000...
Specifications Frame rates with Cropping Values were calculated as defined in Frame rates with ROI/Cropping on page 53 and in Operation for maximum frame rates on page 55. Frame rates at maximum bandwidth calculates for 1.051 Gbps per lane. To reach the maximum frame rate available for typical operation, the bandwidth for image traffic is at 4 lanes with 4.204 Gbps.
Specifications White balance default Alvium color cameras are balanced for neutral color reproduction with an illumination of 5000 °K (warm daylight). Table 71 shows default values for the red and blue channel by model. For different illuminations, use auto white balance or adapt the color channel values manually.
Specifications Monochrome and VSWIR models White balance default does not apply to monochrome and VSWIR models. Dimensions and mass Bare board cameras Specification Dimensions (L × W × H [mm]) [Model specific] × 26 × 26 Mass [g] 10 g Table 72: Bare board dimensions and mass Open housing cameras S-Mount...
Specifications Bare Board 26.3 26.4 ±0.10 A (10 : 1) IPSB CODE B1 ± 10% Sensor area ±0.1 Do not mount here B2 ± 10% B3 ± 10% Figure 55: Bare Board dimensions Dimensions that are common between different models are shown in Figure 74.
Page 168
Specifications ML: Mechanical CH: Components B1: Board B2: Board B3: Board Camera model length* height, thickness thickness thickness for C-Mount incl. the sensor *Theoretical values Alvium 1800 C-235m/c 19.713 mm 2.87 mm 1.10 mm 2.20 mm 3.75 mm Alvium 1800 C-240m/c 19.929 mm 2.27 mm 1.25 mm...
Specifications Open Housing CS-Mount 19.4 MIN - 21.4 MAX M2 - 2.0 CS - Mount Figure 57: Open Housing CS-Mount dimensions Alvium CSI-2 Cameras User Guide V2.8.1...
Specifications Lens mounts and maximum protrusion No need to readjust lens mounts Alvium CSI-2 camera mounts are adjusted with high precision during manufacturing. Construction ensures permanent accuracy without need to readjust. Maximum Maximum protrusion protrusion Filter Electronics Sensor Sensor Lens mount Lens mount Figure 59: Maximum protrusion S-Mount (left);...
Specifications IR cut filter Table 76 shows which Alvium models are equipped with an IR cut filter. The filter is permanently installed and cannot be removed. Color or monochrome model Bare Board S-Mount CS-Mount C-Mount Color No filter Type Hoya C-5000 IR cut filter Monochrome and VSWIR No filter Table 76: Optical filter availability...
Specifications Sensor position accuracy Sensor shift and rotation Gray rectangle Red rectangle Straight line: Reference edge : Current reference edge Figure 61: Sensor shift and rotation The following table defines the manufacturing accuracy for sensor positioning. Criteria Subject Properties Alignment method Optical alignment of the photosensitive sensor area into the camera front module (lens mount front flange) Reference Points...
Specifications Sensor tilt Gray rectangle Red rectangle Figure 62: Sensor tilt The following table defines sensor tilt as the variance between highest and lowest pixel of a sensor along the z-axis, measured in micrometers. Alvium model Pixel size Maximum tilt Alvium 1500 C-050m/c 4.8 µm ×...
Specifications GenICam for CSI-2 Access User sets Supported features UserSet features enable to store individual settings on selected Alvium 1800 C cameras. These user sets can be loaded by default, without needing to set values by software after every restart of the camera. Or they can be used to switch between different settings, for example, to adjust from daylight to artificial light.
Specifications Camera feature availability Alvium CSI-2 cameras support a number of standard and extended controls and features. The following tables compare the availability of selected controls and features by model. Feature descriptions and firmware downloads GenICam for CSI-2 Access: Alvium Features Reference: www.alliedvision.com/en/support/ technical-documentation/alvium-csi-2-documentation Other access modes: Alvium CSI-2 Register Controls Reference:...
Page 178
Specifications Monochrome Color Supported Camera control models models models ✔ ✔ Acquisition frame rate ✔ ✔ Counters and timers ✔ ✔ I/O and trigger control ✔ ✔ Firmware update in the field ✔ ✔ Serial I/Os ✔ ✔ Temperature monitoring (mainboard, companion board, interface board) ✔...
Lenses: Focal length vs. field of view This chapter includes: About this chapter .............. 180 Optical vignetting with certain lenses ........ 180 About S-Mount lenses ............181 Focal length vs. field of view..........181 Alvium CSI-2 Cameras User Guide V2.8.1...
Production spread causes tolerances for all values, including actual focal lengths. Calculations apply for image reproduction without distortion. Therefore, values do not apply for fisheye lenses. Please ask your Allied Vision Sales representative in case you need more information. Optical vignetting with certain lenses Lenses with short focal lengths may show optical vignetting at the edges of the image.
Lenses: Focal length vs. field of view About S-Mount lenses Alvium CSI-2 models with S-Mount have no filter. For typical applications, we recommend using S-Mount lenses with an integrated IR cut filter for a better image quality. Read Mounting and focusing S-Mount lenses on page 209 to avoid damage when using S-Mount lenses.
Lenses: Focal length vs. field of view Alvium 1500 C-120m/c Values for 1500 C-120m/c cameras with Type 1/3 (6.0 mm diagonal) sensors: Field of view (H × V [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 852 ×...
Lenses: Focal length vs. field of view Alvium 1500 C-500m/c, 1500 C-501m/c NIR Values for 1500 C-500m/c and 1500 C-501m/c NIR cameras with Type 1/2.5 (7.1 mm diagonal) sensors: Field of view (H × V in [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 1013 ×...
Lenses: Focal length vs. field of view Alvium 1800 C-040m/c Values for 1800 C-040m/c cameras with Type 1/2.9 (6.3 mm diagonal) sensors: Field of view (H × V [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 892 ×...
Lenses: Focal length vs. field of view Alvium 1800 C-130 VSWIR Values for 1800 C-130 VSWIR cameras with Type 1/2 (8.2 mm diagonal) sensors: Field of view (H × V [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 671 ×...
Lenses: Focal length vs. field of view Alvium 1800 C-234m/c, 1800 C-235m/c Values for 1800 C-234m/c and 1800 C-235m/c cameras with Type 1/1.2 (13.4 mm diagonal) sensors: Field of view (H × V in [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 698 ×...
Lenses: Focal length vs. field of view Alvium 1800 C-291m/c Values for 1800 C-291m/c cameras with Type 2/3 (10.8 mm diagonal) sensors: Field of view (H × V in [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 644 ×...
Lenses: Focal length vs. field of view Alvium 1800 C-500m/c Values for 1800 C-500m/c cameras with Type 1/2.5 (7.1 mm diagonal) sensors: Field of view (H × V in [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 1013 ×...
Lenses: Focal length vs. field of view Alvium 1800 C-511m/c Values for 1800 C-511m/c cameras with Type 1/1.8 (8.8 mm diagonal) sensors: Field of view (H × V in [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 671 ×...
Lenses: Focal length vs. field of view Alvium 1800 C-1236m/c Values for 1800 C-1236m/c cameras with Type 1.1 (17.6 mm diagonal) sensors: Field of view (H × V in [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 872 ×...
Lenses: Focal length vs. field of view Alvium 1800 C-1242m/c Values for 1800 C-1242m/c cameras with Type 1/1.1 (14 mm diagonal) sensors: Field of view (H × V in [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 931 ×...
Lenses: Focal length vs. field of view Alvium 1800 C-2040m/c Values for 1800 C-2040m/c cameras with Type 1.1 (17.5 mm diagonal) sensors: Field of view (H × V in [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 1018 ×...
Lenses: Focal length vs. field of view Alvium 1800 C-2460m/c Values for 1800 C-2460m/c cameras with Type 1.2 (19.3 mm diagonal) sensors: Field of view (H × V in [mm]) Focal length [mm] Object distance = 500 mm Object distance = 1000 mm 898 ×...
Access modes This chapter includes: Overview ................195 Notes on GenICam for CSI-2 Access ........195 V4L2 controls and register controls ........197 GenICam features ............... 197 Alvium CSI-2 Cameras User Guide V2.8.1...
Direct www.alliedvision.com/en/support/technical-documentation Register Access /alvium-csi-2-documentation. Controls the camera by V4L2 controls, using the Allied Vision Video4Linux Access driver for CSI-2 cameras directly. Existing PC-based machine vision applications can be scaled down to V4L2 on lean embedded systems, reducing power consumption and costs.
V4L2 GenICam IOCTLs driver ioctls cameras Kernel space Direct I2C driver: I2C driver: MIPI CSI-2 driver: Image data MIPI CSI-2 driver: Image data Register Control data Control data Access Embedded MIPI CSI-2 PHY MIPI CSI-2 PHY I2C PHY I2C PHY...
Access modes V4L2 controls and register controls Embedded applications often use V4L2 controls provided with the Linux kernel to operate and configure the camera. V4L2 controls - general information Consider that V4L2 controls change through the Linux kernel development. The driver for Alvium CSI-2 cameras currently supports kernel 4.9.140.
Access modes GenICam for CSI-2 Access - Camera operation Need to restart the embedded board Whenever you change between different access modes: • You must restart the embedded board. • Closing the application while the camera is streaming is not sufficient. Device reset command does not work.
Installing the hardware This chapter includes: Touching hot cameras ............200 Scope of instructions ............200 Bare board cameras ............200 Connecting FPC cable and FPC connectors ......202 Mounting the heat sink............204 Mounting the camera ............205 Mounting the lens............... 208 Alvium CSI-2 Cameras User Guide V2.8.1...
Hardware installation This chapter instructs on using Alvium CSI-2 cameras safely and effectively. However, we cannot provide complete information. The MIPI CSI-2 standard does not specify electrical connections as extensively as USB or GigE standard. Therefore, instructions on camera connections can be general only.
11500 Chip SN: 183603543 SN: R7QW5 Alvium® chip SN Allied Vision TASCHENWEG 2A 07646 STADTRODA Made in Germany Figure 65: Sandwich label on blister packs shipped for bare board cameras Before operating the camera, we recommend you to pull the sandwich label off the blister pack and stick it close to the camera.
Connecting FPC cable and FPC connectors Connecting Alvium CSI-2 cameras to embedded boards • For evaluation, Allied Vision offers components to connect Alvium CSI-2 cameras to embedded boards. Adapter boards provide common pinning and voltage for connections to the camera using FPC cables.
Page 203
Installing the hardware NOTICE Damage to the camera by reverse polarity If Alvium CSI-2 cameras are powered with reverse polarity, camera electronics is damaged. • Before connecting camera power and I/O power, carefully read FPC connector pin assignment on page 214. •...
Installing the hardware Mounting the heat sink Keep the operating temperature in the specified range to enable best image quality and to protect the camera from damage. We recommend you to equip Alvium bare board and open housing cameras with heat sinks. Optimizing heat dissipation For details, see the Optimum Heat Dissipation for Housed Alvium Cameras application note at...
Installing the hardware Mounting the camera CAUTION Injury by falling cameras or lenses A falling camera or lens can cause injury. • Ensure proper mounting of cameras and lenses, especially for dynamic applications. • Mount cameras as described in the instructions. •...
Installing the hardware Schematic drawings in Figure 74 show the Alvium CSI-2 bare board camera. Only the mounting area (gray) can be used for mounting. The sensor and electronics area (red) must not be touched nor put at mechanical stress. a = Mounting hole | b = Mounting hole and chassis ground Figure 74: Mounting area of Alvium CSI-2 bare board cameras connector side (left);...
Installing the hardware Front mounting Detail d: Figure 76: Camera front with mounting threads (d) The maximum torque value applies only if the entire thread engagement is used. For other values, see Adapting maximum torque values on page 207. 1. Mount the camera to the base using suitable M2 screws at 0.17 Nm maximum torque for a thread engagement (C) of 1.7 mm between screws and mounting threads, see Figure...
Installing the hardware To ensure that the bolts do not become loose over time, we recommend you to use means for securing bolts, such as screw locking varnish. Tripod adapter For more information, see the Alvium Cameras Accessory Guide at www.alliedvision.com/en/support/technical-documentation/ alvium-csi-2-documentation.
Installing the hardware Mounting and focusing S-Mount lenses Allied Vision S-Mount lenses For technical data of Allied Vision S-Mount lenses with dedicated operating instructions, see the S-Mount Lenses User Guide at www.alliedvision.com/fileadmin/content/documents/products/accessories/lenses /Allied_Vision/User_Guide/S-Mount-Lenses_User-Guide.pdf. This section instructs how to use S-Mount lenses with your camera safely.
Page 210
Installing the hardware NOTICE Damage to sensor, optics, or electronics by improper handling If an S-Mount lens is screwed against the sensor or electronics, sensor, lens, or electronics can be damaged. • Screw in the lens at less than 11.0 mm maximum protrusion. •...
Page 211
Installing the hardware NOTICE Damage to lens threads and fixing nut by excessive force If the fixing nut is screwed with too much force, threads are worn out and the lens cannot be locked anymore. Screw fixing nuts hand tight to keep the lens in a fixed position. Locking focus Pinch nose pliers are used to screw the fixing nut: 7.
Camera interfaces Recommended accessories Compatible electronics accessories For more information, see the Alvium Cameras Accessory Guide at www.alliedvision.com/en/support/technical-documentation/ alvium-csi-2-documentation. Back panel FPC connector Pin 1 Figure 83: Camera back panel For connector pin assignment, see FPC connector pin assignment on page 214. Alvium CSI-2 Cameras User Guide V2.8.1...
Camera interfaces FPC connector pin assignment Alvium CSI-2 cameras have a 22-pin Hirose FH55-22S-0.5SH connector. NOTICE Damage to the camera by reverse polarity If Alvium CSI-2 cameras or camera I/Os are powered with reverse polarity, camera electronics can be damaged. Observe polarity for camera and I/O power.
Page 215
4.5 to 5.5 VDC Power supply voltage Maximum input current: 1.5 A CSI2-TXD3_N According to MIPI CSI-2 D-PHY V1.1 CSI-2 TX data lane 3 negative rail CSI2-TXD3_P According to MIPI CSI-2 D-PHY V1.1 CSI-2 TX data lane 3 positive rail...
Camera interfaces I/O use for UART GenICam for CSI-2 Table 109 shows which values must be selected to control I/Os using Access LineSelector. Signal LineSelector (GenICam) UART line EXT-GPIO 0 Line0 Not applicable EXT-GPIO 1 Line1 Not applicable EXT-GPIO 2 Line2 UART Tx EXT-GPIO 3...
Camera interfaces Alvium GPIOs feature the CMOS push-pull output drivers and Schmitt trigger inputs with an internal pull-up resistor and a filter circuit, shown in Figure 85. The push-pull GPIOs are able to source or sink current from an external pin. ALVIUM Internal External...
Camera interfaces Output levels NOTICE Damage to the camera by high output current or voltage The camera can be damaged when connected to a device that exceeds the specified maximum current or voltage. Consider maximum values: • Max. current = 12 mA per output •...
Camera interfaces Error conditions Four short flashes followed by another sequence indicate errors. In this case, try the following to get the camera back to normal operation: 1. Restart the camera. 2. If the LED again indicates error state after restart, please contact support at www.alliedvision.com/en/about-us/contact-us/technical-support-repair-/ -rma.
Triggering This chapter includes: Availability of triggering controls for CSI-2 ......221 Trigger signal flow ............... 221 Trigger latency..............222 Triggering with rolling shutter cameras......222 Alvium CSI-2 Cameras User Guide V2.8.1...
Triggering Term Description External signal Electrical trigger signal starting the signal flow Exposure Active Exposing a frame Readout Active Reading out a frame Frame Start Trigger Wait Waiting for a trigger Acquisition Active Enables frame acquisition: Expose, read out data, or wait for triggers. Table 113: Trigger signal flow, legend Trigger latency In theory, a trigger creates an immediate response of the camera, depending on...
Page 223
Triggering External signal Sensor cycle state Exposure area Readout area Idle Exposure area Readout area Exposure area Readout area Delay Delay Exposure start delay Figure 87: Triggering rolling shutter (RS) cameras Conditions Results Exposure time is shorter than readout time. Trigger 1 starts exposure 1 with a delay Trigger 2 starts exposure 2 with a delay shorter Exposure time is shorter than readout time, but...
Triggering Ignored triggers Alvium 1500 C-210m/c, C-500m/c, 1800 C-1240m/c, 1800 C-2050m/c Changing parameters while acquisition is active leads to ignored triggers until the parameters get active. Trigger delay with 1500 C-120 cameras If sensor related parameters are changed directly before sending an external trigger, the trigger delay can be increased.
Firmware update Please note You should update firmware only to change camera functions or fix known issues. Consider: Any firmware update may not only add new features to a camera or fix known issues. It may also replace previous features or change camera characteristics.
Firmware update Updating the firmware Screenshots The following instruction shows the firmware update on a Linux system. On Linux systems with other skins and on Windows, the GUI will look different. If you are using command lines, you can derive the workflow from this instruction. 1.
Page 228
Firmware update 4. Click OK to confirm. Figure 92: The command to update the firmware is confirmed The update progress is displayed. Figure 93: The update progress is displayed 5. Click Close to confirm the completion of the update. Figure 94: The update has been successfully completed Alvium CSI-2 Cameras User Guide V2.8.1...
Firmware update The camera is displayed with the updated firmware version. Figure 95: The updated firmware version is displayed Error handling If firmware update fails, • The camera is shown as “Fallback” on the CSI-2 interface. • The camera is recognized by viewer applications but can not be used for streaming.
Image data flow This chapter includes an image data flow of Alvium CSI-2 cameras. Alvium CSI-2 Cameras User Guide V2.8.1...
Page 231
Image data flow Figure 96 shows image data processing in Alvium CSI-2 cameras in general. Sensor frontend Sensor frontend Sensor Analog Region of interest Region of interest Region of interest Gain Gain Black level Black level Reverse Y Reverse Y (ROI) (ROI) (ROI)
Page 232
Image data flow Descriptions for controls and features The shown functionalities represent controls or groups of controls: • For V4L2 controls, see www.linuxtv.org. • For register controls, see the Alvium CSI-2 Register Controls Reference. www.alliedvision.com/en/support/technical-documentation/ alvium-csi-2-documentation for details. • For GenICam features, see the Alvium Features Reference. www.alliedvision.com/en/support/technical-documentation/ alvium-csi-2-documentation for details.
Performance This chapter includes: Image transfer with rolling shutter cameras ...... 234 Frame rate jitter ..............234 Value changes by control interdependencies..... 235 Dark current compensation ..........237 Shutter types affecting image readout ....... 239 Alvium CSI-2 Cameras User Guide V2.8.1...
Performance Image transfer with rolling shutter cameras Alvium 1500 C-210m/c, C-500m/c, 1800 C-1240m/c, and 1800 C-2050m/c If acquisition is started and stopped in a short sequence, no image is transferred to the host. The duration cannot be predicted, because it depends on various factors. Frame rate jitter Alvium 1500 C-120m/c, C-210m/c, C-500m/c, 1800 C-1240m/c, 1800 C-2050m/c Generally, some parameters can be changed during exposure without affecting the...
Performance Value changes by control interdependencies The conversion between time and clock cycles affects control values. Controls for pixel format, bandwidth, ROI, and exposure time are related to each other. Changing values for one control can change values for another control. For example, frame rates can be reduced when MIPI Data Format is changed...
Performance Effects for the interdependent controls Changing one control's value affects other control's values, such as: value is changed. Height Then: Other values may be affected, such as for ExposureTime We recommend you to consider: • The more controls you adjust, the more current values deviate from previously set values.
Performance Dark current compensation All sensors accumulate dark current in the pixels. Dark current increases the signal level and black level. Most sensors in Alvium CSI-2 cameras compensate for this. For Alvium 1500 C-050m/c with the ON Semi PYTHON 480 sensor, see Black level compensation for 1500 C-050m/c on page 238.
Performance Additional compensation If compensation limits are reached and you cannot decrease operating temperature or exposure time, what can you do to keep signal quality high? Measures for type 1 compensation Alvium 1500 C-050m/c supports compensation type 1. For additional compensation, see Black level compensation for 1500 C-050m/c on page 238.
Performance Shutter types affecting image readout Some Alvium CSI-2 camera models are operated using global shutter (GS). Property Line readout Moving image Global shutter (GS) Time Other models use rolling shutter (RS). Alvium 1800 C-2050 models with Sony IMX183 sensor offer global reset shutter (GRS) in addition: Property Rolling shutter (RS) Global reset...
............179 maximum protrusion ....... 46 black level compensation ......238 mounting ..........208 compliance ............37 MIPI CSI-2 ............48 connectors ............ 212 pin assignment ..........214 dark current compensation ......237 power consumption ........57 digital binning ..........57 power consumption >...
Page 241
Index troubleshooting ..........233 Video4Linux Access ........195 typical operation ..........57 user sets ............176 Alvium CSI-2 Cameras User Guide V2.8.1...
