Summary of Contents for Allied Vision Bonito PRO
- Page 1 RESS AMERAS Bonito PRO Technical Manual V1.0.4 Allied Vision Technologies GmbH Taschenweg 2a, 07646 Stadtroda, Germany 2019-Apr-30...
-
Page 2: Bonito Pro At A Glance
Read this manual carefully Learn how to protect your camera from damage and fully understand its functions. The Bonito PRO is Allied Vision’s brand new high-bandwidth camera series with a CoaXPress interface. Equipped with four DIN 1.0/2.3 connectors the camera is capable to transmit 25 Gbps via quad CXP-6 (6.25 Gbps) high-speed connections. -
Page 3: Contact Us
Contact us Contact us Connect with Allied Vision by function www.alliedvision.com/en/meta-header/contact Find an Allied Vision office or distributor www.alliedvision.com/en/about-us/where-we-are General inquiries info@alliedvision.com Technical support support@alliedvision.com Sales offices Europe, Middle East, and Africa: +49 36428 677-0 North, Central, and South America: +1 (877) USA-1394... -
Page 4: Table Of Contents
Contents Bonito PRO at a glance Scope of delivery ................2 What else do you need? . - Page 5 Bonito PRO housing and mounts ........
- Page 6 Bonito PRO image data flow........
-
Page 7: Document History And Conventions
Document history and conventions This chapter includes: • Document history • Layout styles and symbols used in this manual • Acronyms and terms used in this manual Bonito PRO Technical Manual V1.0.4... -
Page 8: Document History
References to other documents or web pages, like web links, hypertext links, emails, but also cross references, that include a link the user can follow by clicking. Table 3: Markup conventions used in this manual Bonito PRO Technical Manual V1.0.4... -
Page 9: Symbols And Notes
The following table provides a list of abbreviations and acronyms used in this document. Acronym or term Description Analog-to-digital converter Automated Imaging Association CMOS Complementary metal-oxide semiconductor Table 4: Acronyms and terms used in this document (sheet 1 of 2) Bonito PRO Technical Manual V1.0.4... - Page 10 Software Development Kit SFNC Standard Feature Naming Convention Trigger over Ethernet Action Command TTL I/O Transistor-transistor logic input/output TxD and RxD Transmit and receive Table 4: Acronyms and terms used in this document (sheet 2 of 2) Bonito PRO Technical Manual V1.0.4...
-
Page 11: Compliance And Intended Use
§ This chapter includes: • Compliance notifications for the following areas: - Europe (CE) - US (FCC) - Canada (ICES) • Information about application and intended use of the camera • Copyright and trademark statement Bonito PRO Technical Manual V1.0.4... -
Page 12: Compliance Notifications
• Directive 2011/65/EU, including amendment 2015/863/EU (RoHS) For customers in the US Supplier Declaration of Conformity Bonito PRO CXP-6 cameras comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. -
Page 13: For Customers In Canada
Cet appareil est conforme aux normes classe A pour bruits radioélectriques, spécifiées dans le Règlement sur le brouillage radioélectrique. CAN ICES-3 (A) / NMB-3 (A) Avoid electromagnetic interferences For all power and interface connections, only use shielded cables or cables recommended by Allied Vision. Bonito PRO Technical Manual V1.0.4... -
Page 14: Camera Applications And Intended Use
• The camera-supporting software can be obtained and installed separately from the camera. Usage of the software is solely the responsibility of the user. • The camera must not be opened. For all repair tasks, contact Allied Vision or one of Allied Vision's authorized representatives. -
Page 15: Copyright And Trademarks
All trademarks, logos, and brands cited in this document are property and/or copyright material of their respective owners. Use of these trademarks, logos, and brands does not imply endorsement. Copyright © 2019 Allied Vision GmbH. All rights reserved. Bonito PRO Technical Manual V1.0.4... -
Page 16: Installation And Hardware
Installation and hardware This chapter describes the components required for your vision system including configuring the host computer, frame grabber settings, and connecting your Bonito PRO camera. Bonito PRO Technical Manual V1.0.4... -
Page 17: Precautions
Specifications chapter of this document. Special care must be taken to maintain a reasonable operating temperature. NOTICE Verify all external connections in terms of voltage levels, power requirements, voltage polarity, and signal integrity prior to powering the device. Bonito PRO Technical Manual V1.0.4... -
Page 18: Optical Components
The Bonito PRO camera can be damaged by some volatile cleaning agents. Avoid cleaning the image sensor unless absolutely necessary. See the Cleaning optical components chapter in this document. Allied Vision can clean your camera as a service for you, if necessary. For more information, contact Allied Vision support. NOTICE... -
Page 19: Planarity Mounts
Cameras and lens load We tested one Bonito PRO X-1250B with an EF-Mount PA and one Bonito PRO X-1250B NIR with an F-Mount (non-PA). Lens simulators Lens simulators were used to simulate lenses. -
Page 20: Recommended Frame Grabbers
For a complete list of supported frame grabbers including limitations, see the Hardware Selection for Bonito PRO Cameras application note. www.alliedvision.com/en/support/technical-papers-knowledge-base.html Contact your Allied Vision Sales representative or your local Allied Vision distribution partner for lens recommendations: www.alliedvision.com/en/meta-header/contact/contact-sales The Euresys Coaxlink Quad G3 frame grabber and GenICam browser were used to create the screenshots in this document. -
Page 21: Powering The Camera
• For all power connections use only shielded cables to avoid electromagnetic interference. • Bonito PRO cameras can be powered from either the Hirose I/O port or via PoCXP. Power supplied via Hirose I/O takes priority over power supplied via PoCXP. -
Page 22: Connecting Your Camera
2. Connect your Bonito PRO camera to your frame grabber via four 75Ω coaxial cables. 3. The camera can by powered via the Hirose I/O port using a compatible power supply or it can be powered via a PoCXP frame grabber. -
Page 23: Optics
F-Mount (default mount), F-Mount PA, M42-Mount, M42-Mount PA, M58-Mount, M58-Mount PA, and Canon EF-Mount PA. Lenses can be purchased directly from Allied Vision or from an Allied Vision distribution partner. Users need to select the desired focal length and appropriate optical format for the target camera model. -
Page 24: Accessories
Installation and hardware Accessories Allied Vision offers a wide range of accessories for the use of Bonito PRO CXP-6 cameras and the easy integration in already existing applications including: • CXP-6 cables • Lenses for corresponding sensor sizes and resolutions Contact your Allied Vision Sales team or your local Allied Vision distribution partner for information on accessories and lens recommendations. -
Page 25: Specifications
Specifications This chapter provides: • Applied standards • Technical specifications • Absolute QE plots • ROI height versus frame rate plots • Feature availability in Bonito PRO camera models Bonito PRO Technical Manual V1.0.4... -
Page 26: Applied Standards
The GenICam standard consists of multiple modules that specify tasks to be solved. Allied Vision cameras and software make use of these modules, like the SFNC that standardizes feature names and types via an XML file or the transport layer interface (GenTL) that is used to grab images. -
Page 27: Resolution And Roi Frame Rate
Manufacturing tolerance of the sensor increases overall uncertainty. ON Semiconductor sensors The curve in the absolute QE plots shown in this chapter is taken from the sensor manufacturer data sheet. The information was correct at the time of publishing. Bonito PRO Technical Manual V1.0.4... -
Page 28: Specifications Common To All Models
Specifications Specifications common to all models The following table provides specifications common to all Bonito PRO models. Feature Specification Shutter mode Global shutter Default lens mount F-Mount Optional lens mounts • EF-Mount PA • F-Mount PA • M42-Mount • M42-Mount PA •... -
Page 29: Trigger Jitter, Delay, And Propagation Delay
Specifications Trigger jitter, delay, and propagation delay The following table provides trigger jitter, trigger delay, and propagation delay values for Bonito PRO cameras. External trigger input Trigger delay Trigger jitter 200.5 ns ± 6.5 ns Non-isolated trigger input 234.5 ns ±... -
Page 30: Bonito Pro X-1250 Series
Specifications Bonito PRO X-1250 series The following table provides model series specifications. The values are valid for Bonito PRO X-1250B, X-1250B NIR, and X-1250C models. For specifications common to all models, see Specifications common to all models. Specification Feature Bonito PRO X-1250B, X-1250B NIR... -
Page 31: Absolute Qe
ROI frame rate Mono8, BayerRG8 Mono10, BayerRG10 2900 2610 2320 2030 1740 1450 1160 1240 1550 1860 2170 2480 2790 3100 ROI height [pixels] Figure 4: Bonito PRO X-1250 frame rate as a function of ROI height Bonito PRO Technical Manual V1.0.4... -
Page 32: 8-Bit Pixel Formats (Mono8, Bayerrg8)
503.2 2881.8 2048 209.2 699.7 1792 236.9 1149.4 Table 10: Bonito PRO X-1250 frame rate as a function of ROI height (Width=4096 pixels) 10-bit pixel formats (Mono10, BayerRG10) Height Frame rate (fps) Height Frame rate (fps) Height Frame rate (fps) 3072 136.6... -
Page 33: Bonito Pro X-2620 Series
Specifications Bonito PRO X-2620 series The following table provides model series specifications. The values are valid for Bonito PRO X-2620B, X-2620B NIR, and X-2620C models. For specifications common to all models, see Specifications common to all models. Specification Feature Bonito PRO X-2620B, X-2620B NIR... -
Page 34: Absolute Qe
2750 2500 2250 2000 1750 1500 1250 1000 1200 1600 2000 2400 2800 3200 3600 4000 4400 4800 5200 ROI height [pixels] Figure 6: Bonito PRO X-2620 frame rate as a function of ROI height Bonito PRO Technical Manual V1.0.4... -
Page 35: 8-Bit Pixel Formats (Mono8, Bayerrg8)
1536 251.1 2570.6 3328 121.0 1280 296.7 2857.1 Table 13: Bonito PRO X-2620 frame rate as a function of ROI height (Width=5120 pixels) 10-bit pixel formats (Mono10, BayerRG10) Height Frame rate (fps) Height Frame rate (fps) Height Frame rate (fps) 5120 70.1... -
Page 36: Camera Features
Specifications Camera features Bonito PRO cameras support a number of standard and extended features. The following table identifies a selection of capabilities and compares the availability of features in Bonito PRO camera models. For a complete description of individual features, see the Bonito PRO Features Reference. -
Page 37: Mechanical Dimensions
Mechanical dimensions This chapter includes: • Mechanical drawings and dimensions of Bonito PRO housing and mounts • Flange focal distance • Sensor position accuracy Bonito PRO Technical Manual V1.0.4... -
Page 38: Bonito Pro Housing And Mounts
Mechanical dimensions Bonito PRO cameras are available with different lens mount options. For more information, see the Modular Concept. Bonito PRO housing and mounts F-Mount (default mount) 32.9 70.0 56.0 36.7 42.1 73.9 NOMINAL 48.0 M3x3 (8x) 26.0 70.0 27.0 21.5... -
Page 39: F-Mount Pa
Figure 8: Bonito PRO camera with F-Mount PA, mechanical dimensions F-Mount PA order code Contact the Allied Vision Sales team to purchase the Bonito PRO series camera with F-Mount PA option (order code Bonito PRO...-03). Bonito PRO Technical Manual V1.0.4... -
Page 40: Ef-Mount Pa
Figure 9: Bonito PRO camera with EF-Mount PA, mechanical dimensions EF-Mount PA order code Contact the Allied Vision Sales team to purchase the Bonito PRO series camera with EF-Mount PA option (order code Bonito PRO...-18). Bonito PRO Technical Manual V1.0.4... -
Page 41: M42-Mount
M3x3 (4x) 2 SIDES 62.2 Figure 10: Bonito PRO camera with M42-Mount, mechanical dimensions M42-Mount order code Contact the Allied Vision Sales team to purchase the Bonito PRO series camera with M42-Mount option (order code Bonito PRO...-31). Bonito PRO Technical Manual V1.0.4... -
Page 42: M42-Mount Pa
Figure 11: Bonito PRO camera with M42-Mount PA, mechanical dimensions M42-Mount PA order code Contact the Allied Vision Sales team to purchase the Bonito PRO series camera with M42-Mount PA option (order code Bonito PRO...-25). Bonito PRO Technical Manual V1.0.4... -
Page 43: M58-Mount
M3x3 (4x) 2 SIDES 62.2 Figure 12: Bonito PRO camera with M58-Mount, mechanical dimensions M58-Mount order code Contact the Allied Vision Sales team to purchase the Bonito PRO series camera with M58-Mount option (order code Bonito PRO...-12). Bonito PRO Technical Manual V1.0.4... -
Page 44: M58-Mount Pa
Figure 13: Bonito PRO camera with M58-Mount PA, mechanical dimensions M58-Mount PA order code Contact the Allied Vision Sales team to purchase the Bonito PRO series camera with M58-Mount PA option (order code Bonito PRO...-13). Bonito PRO Technical Manual V1.0.4... -
Page 45: Flange Focal Distance
Mechanical dimensions Flange focal distance F-Mount Flange focal distance is the optical distance from the mounting flange to image sensor die. Bonito PRO F-Mount cameras are calibrated to a standard 46.50 mm flange focal distance. 46.50 mm FLANGE DISTANCE SECTION A-A... -
Page 46: Ef-Mount Pa
Mechanical dimensions EF-Mount PA Bonito PRO M58-Mount cameras are calibrated to a standard 44.00 mm flange focal distance. 44.00 mm FLANGE DISTANCE SECTION D-D Figure 16: EF-Mount PA flange distance cross section M42-Mount Bonito PRO M42-Mount cameras are calibrated to a standard 45.46 mm flange focal distance. -
Page 47: M42-Mount Pa
Mechanical dimensions M42-Mount PA Bonito PRO M42-Mount PA cameras are calibrated to a standard 45.46 mm flange focal distance. 45.46 mm FLANGE DISTANCE SECTION E-E Figure 18: M42-Mount PA flange distance cross section M58-Mount Bonito PRO M58-Mount cameras are calibrated to a standard 12.71 mm flange focal distance. -
Page 48: M58-Mount Pa
Mechanical dimensions M58-Mount PA Bonito PRO M58-Mount cameras are calibrated to a standard 46.50 mm flange focal distance. 46.50 mm FLANGE DISTANCE SECTION C-C Figure 20: M58-Mount PA flange distance cross section Adjustment of F-Mount The F-Mount is adjusted at the factory and should not require adjusting. If for some reason the lens mount requires adjustment, use the following method. -
Page 49: Planarity Adjustable Mounts
4. Gently move the F-Mount front assembly until focused and lock it in place. Planarity adjustable mounts Bonito PRO cameras allow planarity adjustment of the mount relative to the camera sensor. Adjustment can be made for overall flange focal distance (Z distance), and planarity (Z-tilt). -
Page 50: Sensor Position Accuracy
±10 µm (optical back focal length) α < 1° (sensor rotation) Alignment Optical alignment of photo sensitive sensor area method into camera front module (lens mount front flange). Table 17: Sensor position accuracy criteria Bonito PRO Technical Manual V1.0.4... -
Page 51: Ir Cut Filter
Mechanical dimensions IR cut filter All Bonito PRO color models are equipped with an infrared block filter (IR cut filter). This filter prevents infrared light from passing to the sensor. In the absence of an IR cut filter, images are dominated by red and incapable of being properly color balanced. -
Page 52: Camera Interfaces
This chapter includes: • A general description of the inputs and outputs (including trigger features) • I/O connector pin assignments • I/O block diagrams • A general description of trigger rules such as timing diagram and definitions Bonito PRO Technical Manual V1.0.4... -
Page 53: Back Panel
Camera interfaces Back panel This section provides information on CoaXPress connectors, Hirose IO port, status LEDs, and trigger features. Figure 25: Bonito PRO ports and LEDs Status LEDs 4 × 1.0, 2.3 DIN type connectors Hirose I/O port, HR10A-10R-12PB connector... -
Page 54: Status Leds
Slow flash (0.5 Hz) alternate green and orange sent Compliance test mode Slow flash (0.5 Hz) alternate red then green then enabled orange System error (for example Fast flash (12.5 Hz) red internal error) Table 18: Status of LEDs Bonito PRO Technical Manual V1.0.4... -
Page 55: Coaxpress Interface
Camera interfaces CoaXPress interface The Bonito PRO is powered through the 12-pin Hirose I/O port, or the CXP-6 four DIN 1.0, 2.3 connections by using any standard PoCXP supported frame grabber. The PoCXP interface supports power up to 13 watts per cable. - Page 56 Both the up connection and down connection use 8B/10B code. 8B/10B is an industry-standard code that maps 8-bit data to 10-bit data to achieve DC balance on the connection, while also allowing clock recovery by ensuring regular transitions. Discovery bit rate The discovery bit rate is CXP-1. Bonito PRO Technical Manual V1.0.4...
-
Page 57: Camera I/O Connector Pin Assignment
Reserved for future use Black Isolated Out Common VCC for Power input Orange Power outputs 5 to 24 VDC for opto-isolated outputs Table 19: Camera I/O connector pin assignment and cable color coding (sheet 1 of Bonito PRO Technical Manual V1.0.4... - Page 58 SHIELD TRANSPARENT Hirose HR10A Open End Figure 28: Bonito PRO cable color coding The General Purpose I/O port uses a Hirose HR10A-10R-12PB connector on the camera side. The mating cable connector is Hirose HR10A-10P-12S. Hirose connector The cable side Hirose 12-pin female connector is available for purchase from Allied Vision.
-
Page 59: I/O Definition
I/O definition Camera Power The Bonito PRO camera can be powered through the Hirose I/O port, via Pin 1 Camera GND and Pin 2 Camera Power, or through the CoaXPress interface if using a Power over CoaXPress (PoCXP) supported frame grabber. - Page 60 5.1 V, 150 mW Camera GND SN74LVC2G34DCKR Figure 29: Bonito PRO internal circuit diagram for non-isolated input trigger In 2 (Opto-isolated) In 2 is optically isolated and can be used in electrically noisy environments to prevent false trigger events. Tie trigger ground to Isolated IO GND to complete the trigger circuit.
-
Page 61: Output Signals
TTL, maximum 3.3 VDC. It is not suitable for driving loads in excess of 50 µA. Camera Internal External 3.3 V 3.3 V Out 1 / Out2 3.3 V Camera Logic Figure 31: Bonito PRO Out 1 or Out 2 trigger circuit Bonito PRO Technical Manual V1.0.4... - Page 62 V Load TCMT1107 R Load Isolated IO Ground Figure 32: Bonito PRO Out 3 and Out 4 trigger circuit Camera Logic Signal Out 3 / Out 4 Figure 33: Bonito PRO Out 3 and Out 4 timing diagram The influence of various Isolated Out Power values and load values on the timing response of the trigger is indicated in the following table.
-
Page 63: Ef Lens Control
Table 20: Bonito PRO trigger circuit values (sheet 2 of 2) EF lens control EF lens control is available for Bonito PRO cameras. EF lens control allows focus and aperture control via host software. See the Modular Concept for information on lens mount options available with... -
Page 64: Camera Trigger
Trigger ji er Readout N+ 1 Trigger ready Imaging Idle Figure 34: Bonito PRO internal signal timing waveforms Trigger definitions Term Definition User trigger Trigger signal applied by the user (hardware trigger, software trigger). Logic trigger Trigger signal seen by the camera internal logic (not visible to the user). - Page 65 Exposure must always begin on an Interline boundary. For a more detailed description of the trigger concept for advanced users and special scenarios, see the Triggering Concept application note: www.alliedvision.com/en/support/technical-papers-knowledge-base.html Bonito PRO Technical Manual V1.0.4...
-
Page 66: Image Data Flow
Image data flow This chapter presents diagrams that illustrate data flow and bit resolution of the image data. Bonito PRO Technical Manual V1.0.4... -
Page 67: Bonito Pro Image Data Flow
Image data flow For a complete description of individual features, see the Bonito PRO Features Reference. Bonito PRO image data flow Calibrated Calibrated Sensor Vertical ROI Horizontal ROI Offset Gain Analog Analog Analog Analog Internal sensor components Defect Pixel Black Level... -
Page 68: Cleaning Optical Components
Cleaning optical components This chapter describes safety instructions and cautions for cleaning lenses, optical filters, or sensors. Bonito PRO Technical Manual V1.0.4... -
Page 69: Keep Optical Components Clean
Identifying impurities If you observe any image artifacts in your video preview of your Bonito PRO camera you may have impurities either on the lens, optical filter, or on the sensor protection glass. Every Bonito PRO camera is cleaned prior to sealing and shipment;... -
Page 70: Locating Impurities
If the impurity is neither on the lens nor the IR cut filter or protection glass, it is probably on the sensor. NOTICE Removing the optical filter Do not attempt to remove the camera optical filter for Bonito PRO cameras. Contact support@alliedvision.com for assistance. -
Page 71: Cleaning Instructions
5. When you have finished cleaning, examine the surface in a strong light. Take an out-of-focus picture of a flat, illuminated surface to see if any dirt or dust remains. 6. If dust spots remain, repeat this procedure using new clean lens tissue. Bonito PRO Technical Manual V1.0.4... -
Page 72: Cleaning Issues
Allied Vision distribution partner. Cleaning with compressed air Allied Vision does not recommend cleaning Bonito PRO cameras with compressed air. NOTICE • Compressed air at high pressure and/or shorter operating distances may push dust into the camera or lens and physically damage the camera, sensor, or optical components. -
Page 73: Firmware Update
Firmware update This chapter includes instructions on updating the firmware on your Allied Vision Bonito PRO camera. Bonito PRO Technical Manual V1.0.4... -
Page 74: Firmware Upgrade Overview
Do not unplug the CoaXPress cables or camera power supply during the update procedure. We recommend using auxiliary power instead of PoCXP for firmware updates. Allied Vision does not provide a firmware loader tool, you should perform firmware updates via the frame grabber SDK. Firmware upgrade overview 1. -
Page 75: Get Remote Port And Device Node Map
= m_RemoteDeviceMap->_GetNode("FileAccessBuffer"); m_FileSelector = m_RemoteDeviceMap->_GetNode("FileSelector"); m_FileOpenMode = m_RemoteDeviceMap->_GetNode("FileOpenMode"); m_FileOperationSelector = m_RemoteDeviceMap->_GetNode("FileOperationSelector"); m_FileAccessLength = m_RemoteDeviceMap->_GetNode("FileAccessLength"); m_FileOperationExecute = m_RemoteDeviceMap->_GetNode("FileOperationExecute"); m_FileOperationResult = m_RemoteDeviceMap->_GetNode("FileOperationResult"); m_FileOperationStatus = m_RemoteDeviceMap->_GetNode("FileOperationStatus"); m_FileStatus = m_RemoteDeviceMap->_GetNode("FileStatus"); Code listing 2: Active Silicon code snippet example Bonito PRO Technical Manual V1.0.4... -
Page 76: Firmware Upload Via Fileaccess
FileStatus() != "Closed") close( fileName ); m_FileSelector->FromString( fileName.c_str() ); m_FileOperationSelector->FromString("Open"); m_FileOpenMode->FromString( toString(mode) ); m_FileOperationExecute->Execute(); if( FileStatus() != "Open") throw RUNTIME_EXCEPTION( fileName + " could not be opened"); Code listing 4: Active Silicon code snippet example Bonito PRO Technical Manual V1.0.4... - Page 77 != writeSize frameGrabber.getString<RemoteModule>("FileOperationStatus") != "Success" ) return false; double percentWritten = (100.0* bytesWritten )/ dataToWrite; std::cout<<"\r"<<std::fixed<<std::setprecision(2)<<percentWritten<<" % "; bytesWritten +=writeSize; dataPos +=writeSize; return true; Code listing 5: Euresys code snippet example Bonito PRO Technical Manual V1.0.4...
- Page 78 CloseCameraFile(EGrabber<T> &frameGrabber, const std::string &fileName) // basically fopen( fileName,"w") frameGrabber.setString<RemoteModule>("FileSelector", fileName); frameGrabber.setString<RemoteModule>("FileOperationSelector", "Close"); frameGrabber.execute<RemoteModule>("FileOperationExecute"); if (frameGrabber.getString<RemoteModule>("FileOperationStatus") == "Success" && frameGrabber.getString<RemoteModule>("FileStatus") == "Closed") return true; return false; Code listing 7: Euresys code snippet example Bonito PRO Technical Manual V1.0.4...
- Page 79 FileStatus() != "Closed") throw RUNTIME_EXCEPTION(fileName + " could not be closed"); Code listing 8: Active Silicon code snippet example Step 6: Reboot the camera You must always power cycle the camera after a firmware upgrade or downgrade. Bonito PRO Technical Manual V1.0.4...
-
Page 80: Index
9 Environmental specifications ......17 ESD ............9 Power DC ............21 Flange focal distance F-Mount ......45 Frame rate ..........27 CCD sensors ........27 Resolution and ROI frame rates Model comparison ......36 RS232 .............57 GenICam ..........26 Bonito PRO Technical Manual V1.0.4... - Page 81 Rules..........65 Registered exposure time .....65 Time delay .........64 Sensor row readout cycles ....65 Timing diagram........64 Specifications...........25 Tpd...........64 Spectral transmission Trigger jitter ........64 IRC30 filter.........51 Trigger latency........64 Status LEDs..........54 Trigger ready........65 User trigger........64 Tripod adapter .........45 Bonito PRO Technical Manual V1.0.4...
