  • Page 1 FHD PTZ Camera Saber IP20X NDI NDI|HX User Manual v2.0 EN...
  • Page 2 Saber IP20x...
  • Page 3 Saber °C °C...
  • Page 4 Saber...
  • Page 5 Saber 1/2.8 inch 2.1MP CMOS sensor, 1080p Video High end 20x optical zoom, 2x digital zoom lens with 60 degree field of view. NDI H|X IP streaming protocol...
  • Page 6 Saber 1920*1080 @ 3~60fps; 1280*720 @ 3~60fps; 1024*576 @ 3~60fps; 640*360 @ 30fps (lowbroadbandmode) HDMI (V1.4), SDI, NDI|HX, USB3.0 (Compatible with USB2.0) 1/2.8 inch 2.1MP CMOS sensor f4.9〜98mm(20x), F1.5 – 3.0, ViewAngle: 60°(Far)-3.2°(Near)
  • Page 7 Saber RS232, RS485 (Serial Visca, Pelco-P/D), RJ45 (VISCA over IP), USB3.0 (UVC1.5), USB2.0 (UVC1.1) TCP/IP, HTTP, DHCP, RTSP, RTMP, Onvif 2.4, VISCA over IP (TCP&UDP), NDI (H|X), SRT Compatible...
  • Page 8 Saber (NDI|HX)
  • Page 9 Saber Video mute Short press Video mute button to turn o ffthe camera and short press again to turn it on. Set Presets: Set+(0~9)to set preset. Recall Presets: Short press the(0~9)number key to recall presets.
  • Page 10 Saber...
  • Page 11 Saber...
  • Page 12 Saber...
  • Page 13 Saber...
  • Page 14 Saber...
  • Page 15 Saber...
  • Page 16 Saber...
  • Page 17 Saber...
  • Page 18 Saber...
  • Page 19 Saber...
  • Page 20 Saber...
  • Page 21 Saber...
  • Page 22 Saber...
  • Page 23 Saber...
  • Page 24 Saber mode LANGUA Optional Item: Chinese / English Default English PROTOCOL Optional i tem VISCA / PELCO -P / PELCO -D Default VISCA SYSTEM ADD RES S VISCA :1~7 PELCO -P/D:1~255 Default 1 BAUD RA TE Optional i tem: 2400 / 4800 / 9600 / 115200 Default 9600 RETURN Return to previous menu...
  • Page 25 Saber EXPOSURE AUTO / MANUA L/ BR IGHT / SHU TTER / IRIS Default MODE AUTO Shutter speed:1/8~1/10000, only valid under Default SHU TTER manual mode AUTO IRIS Iris s ettin g:0~13 , only valid under manual mode Default AUTO GAIN Gain setti ng: 0~15, only vali d under manual Default...
  • Page 26 Saber IP20x 2D noise reduction: t he bigger value, the less 2D NR Default OFF noise on image, the lower resolution 0~4, the bigger Default value, the less motion noise on image , high value 3D NR AUTO will cause image smear. SHARPNESS Sharpness setting: 0~ 15, the higher value, edge Default 3...
  • Page 27 Saber IP20x CAM RESET Reset camera parameter to default RESET PTZ RESET Reset pan/tilt parameter to default ALL RESET Reset all parameter to default RETURN Return to the previous menu CONTROL Camera control firmware version CONTROL Camera control firmware releasing date DATE FORMAT Current video output formate...
