D-Link DFE-528TX Quick Installation Manual

Contents of Package:

•
DFE-528TX Fast Ethernet Adapter
•
Quick Install Guide
•
CD-ROM, which includes driver software
If any of the above items are missing, please contact your reseller.
TURN OFF the computer and
unplug the power cord.
Installing the DFE-528TX into the
computer's PCI slot
Note: To avoid static electric charges, please touch an unpainted screw on the
outside of the power supply before installing or working with the DFE-528TX.
•
Turn off your computer and unplug the power cord.
•
Remove the back cover of your computer. (Refer to your computer's
manual if needed.)
•
Locate an available PCI slot. PCI slots are usually white or cream
colored.
•
Remove the backplate (the small piece of metal that covers the opening
for the PCI card on the back cover that you just removed.)
•
Insert the DFE-528TX carefully and firmly into the PCI slot.
•
Secure the DFE-528TX with the screw from the backplate.
•
Replace your computer's cover.
