Olympus SZX-AR1 Instruction Manual

English
This simplified safety manual describes only the items necessary for
using this product safely. You can obtain the SZX-AR1 system
instruction manual that describes the details of setup procedures or
specifications, etc. from the "Instruction Manual Downloads" website
shown below. Before using this product, download the instruction
manual from the website and read it carefully.
To read the instruction manual, it is necessary to install software for
browsing the PDF file on the terminal you use in advance. In addition, if
you cannot browse the instruction manual, do not use the product.
Instruction Manual Downloads
https://www.olympus-
ims.com/service-and-
support/instruction-manual-
downloads/
Our Website
https://www.olympus-ims.com
The following symbol is used in this manual.
WARNING:
Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION:
Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury. It may also be used to alert against
unsafe practices or potential material damage.
NOTE:
Indicates a potential situation which, if not avoided, may result in failure of
this instrument.
WARNING: Prevention of electric shock
Never disassemble any part of this product.
It could cause electric shock or failure of the product.
Do not touch the product with wet hands.
In particular, if you touch the main switch of the power unit or the power
cord with wet hands, electric shock, ignition or failure of the product may
be caused.
Do not bend, pull or tie the power cord/cables in a bundle.
Otherwise they could be damaged, causing a fire or an electric shock.
Keep the power cord and cables well away from the lamp
housing.
If the power cord and cables contact a hot area of the lamp housing, they
could melt and cause electric shock.
CAUTION: Electric safety
AM5183 03
SZX-AR1
Instruction manual (Safety)
Optical Microscope Accessory
Service Center
https://www.olympus-
ims.com/service-and-support/service-
centers/
Issued in February, 2022
Always use the power cord specified by us.
If the proper AC adapter and the power cord are not used, the electric
safety and the EMC (Electromagnetic Compatibility) performance of the
product can not be assured. If no power cord is provided, please select
AR Microscope
the proper power cord by referring to the section "Proper selection of the
power cord" at the end of the instruction manual (Hardware).
Always connect the ground terminal.
Connect the ground terminal of the power cord and that of the power
outlet.
If the product is not grounded, our intended electric safety and EMC
performance of the product can not be assured.
Do not use the product in close proximity to the sources of strong
electromagnetic radiation.
Proper operation may be interfered. The electromagnetic environment
should be evaluated prior to operation of the product.
Disconnect the power cord in case of emergency.
In case of emergency, disconnect the power cord from the power cord
connector on the product or from the power outlet.
Install the product at the location where you can reach the power cord
connector or the power outlet at hand to disconnect the power cord
quickly.
Do not connect or disconnect the power cord, cables and units
while the power is on.
Safety symbols
The following symbols are placed on this product.
Study the meaning of the symbol and always use the product in the
safest possible manner.
Symbol
Indicates a non-specific general hazard. Follow the description given after this
symbol or in the instruction manual
Indicates that the seesaw type main switch is ON.
(Seesaw type is the type of switch where ON or OFF is selected by pressing it
to ON or OFF side.)
Indicates that the seesaw type main switch is OFF.
Caution engraving/label
Safety labels are placed on the portions which particularly require special
cautions when using or operating this product. Be sure to follow these
instructions.
Label position
(A)
If a caution engraving or label is dirty or peeled off, contact us for the
replacement or other inquiry.
Maintenance and Storage
Cleaning of each part
Lens and filter
Do not leave stains or fingerprints on the lenses or filters. If they get dirty,
blow away dust with a commercially available blower and gently wipe the
lens or filter with a piece of cleaning paper (or washed-out clean gauze).
Only when cleaning fingerprints and oil stains, slightly moisten a piece of
cleaning paper with commercially available absolute alcohol and wipe
them off with it.
- 1 / 8 -
Meaning
Safety label Instructions in the instruction manual
[Caution for electric safety]
[Caution for prevention of electric shock]
