Avalue Technology RSC-3568J User Manual

3.5” single board computers (sbc) with rockchip rk3568j, feature wide temperature support

Advertisement

Quick Links

RSC-3568J
3.5" single board computers (SBC)
with Rockchip RK3568J, feature wide temperature support
User's Manual
Ed – 11 November 2024
nd
2
Copyright Notice
Copyright © 2024 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No: E2047R68J01R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RSC-3568J and is the answer not in the manual?

Questions and answers

Summary of Contents for Avalue Technology RSC-3568J

  • Page 1 RSC-3568J 3.5” single board computers (SBC) with Rockchip RK3568J, feature wide temperature support User’s Manual Ed – 11 November 2024 Copyright Notice Copyright © 2024 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No: E2047R68J01R...
  • Page 2: Document Amendment History

    RSC-3568J User’s Manual Document Amendment History Revision Date Comment July 2024 Avalue Initial Release November 2024 Avalue Update System Specifications 2 RSC-3568J User’s Manual...
  • Page 3: Declaration Of Conformity

    For detailed information, please always refer to the electronic user's manual. Copyright Notice © 2024 by Avalue Technology Inc. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Avalue Technology Inc.
  • Page 4 ㆍDescription of your software (operating system, version, application software, etc.) ㆍA complete description of the problem ㆍThe exact wording of any error messages To receive the latest version of the user’s manual; please visit our Web site at: www.avalue.com 4 RSC-3568J User’s Manual...
  • Page 5 On the other hand, if the new product defect is resulting from incorrect configuration or erroneous use by the user instead of any problem of the hardware itself, the customer will also be requested to pay for relevant handling RSC-3568J User’s Manual...
  • Page 6 “does not work” or “problematic”. Without a substantial description of the problem, it is hard to start the repair and will cause prolonged repair time. Lacking detailed statement of fault steps also makes the problem 6 RSC-3568J User’s Manual...
  • Page 7 3.3 Maintenance Charge Avalue will charge a moderate repair fee for the following conditions: • The warranty period has expired. • Product has been altered or its label of the serial number has been torn off. RSC-3568J User’s Manual...
  • Page 8 On completion of repair of a defective product, a Maintenance Report indicating the maintenance result and part(s) replaced (if any) will be sent to the customer together with the product. If the customer demands an additional maintenance analysis report, a service 8 RSC-3568J User’s Manual...
  • Page 9: Safety Instructions

    The voltage and current rating of the cord must be greater than the voltage and current rating marked on the product. 9. Position the power cord so that people cannot step on it. Do not place anything over the RSC-3568J User’s Manual...
  • Page 10 The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. 15. Equipment intended only for use in a RESTRICTED ACCESS AREA. 10 RSC-3568J User’s Manual...
  • Page 11: Explanation Of Graphical Symbols

    A NOTE provides additional information intended to avoid Note inconveniences during operation. Direct current. Alternating current Stand-by, Power on FCC Certification CE Certification Follow the national requirements for disposal of equipment. Stacking layer limit This side up RSC-3568J User’s Manual 11...
  • Page 12 RSC-3568J User’s Manual Fragile Packaging Beware of water damage, moisture-proof Carton recyclable Handle with care Follow operating instructions of consult instructions for use. 12 RSC-3568J User’s Manual...
  • Page 13: Disposing Of Your Old Product

    EXPLOSION ou une fuite de liquide ou de gaz inflammable. - UNE BATTERIE soumise à une pression d'air extrêmement basse pouvant entraî ner une EXPLOSION ou une fuite de liquide ou de gaz inflammable. RSC-3568J User’s Manual 13...
  • Page 14: Table Of Contents

    JDCIN connector (JDCIN2) ......................32 2.3.18 JRS connector (JRS2) ....................... 33 2.3.19 JRS connector (JRS3) ....................... 33 2.3.20 JSENSE connector (JSENSE) ....................34 2.3.21 JTB connector (JTB1) ........................ 34 3. Mechanical Drawing ....................35 4. Maintenance & Troubleshooting ................37 14 RSC-3568J User’s Manual...
  • Page 15: Getting Started

    1.2 Packing List Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty RSC-3568J RSC-3568J User’s Manual 15...
  • Page 16: Manual Objectives

    We strongly recommend that you study this manual carefully before attempting to set up RSC-3568J or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance.
  • Page 17: System Specifications

    JSPK1 : 1x4P, pitch 2.0 pin header ; 180D (2W*2/ 4ohm) Audio JAMIC1 : 2x3P, pitch 2.0 pin header ; 180D (Headphone out stereo / MIC in mono) JDBG1:1x3P, pitch 2.0 pin header ; 180D (Tx/Rx/GND) – 2wires RSC-3568J User’s Manual 17...
  • Page 18 Size (L x W) 146mm x 101mm Weight 0.1kg Vibration Test IEC 60068-2-64, 1.5 ~ 3.0 Grm, random, 5 ~ 500Hz, 30mins/axis Drop Test ISTA 2A, IEC-60068-2-32 Test:Ed  Support 4 LVDS wide-temperature LCD panels. Others 18 RSC-3568J User’s Manual...
  • Page 19  Support M.2 LTE Module Quetel EM060K -25°C ~ 75°C Note: Specifications are subject to change without notice. User condition suggestion: User should consider overall power consumption including CPU and devices add-on, to choose suitable power adapter. RSC-3568J User’s Manual 19...
  • Page 20: Architecture Overview-Block Diagram

    RSC-3568J User’s Manual 1.5 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of RSC-3568J. 20 RSC-3568J User’s Manual...
  • Page 21: Hardware Configuration

    User’s Manual 2. Hardware Configuration RSC-3568J User’s Manual 21...
  • Page 22: Product Overview

    RSC-3568J User’s Manual 2.1 Product Overview 22 RSC-3568J User’s Manual...
  • Page 23: Jumper And Connector List

    4 x 2 header, pitch 2.00mm Connectors Label Function Note JLVBL Backlight control interface 5 x 1 wafer, pitch 2.00mm JDIO1 General purpose I/O connector 10 x 2 wafer, pitch 1.00mm JNGFF2 M.2 KEY-E 2230 connector JNGFF3 M.2 KEY-B 3042/2242 connector RSC-3568J User’s Manual 23...
  • Page 24 2 x 1 wafer, pitch 1.25mm JDBG1/2 JDBG connector 3 x 1 header, pitch 2.00mm JSIM1 Nano SIM card slot JSD1 Micro SD card slot SWRST SWRST connector JSPK1 Speaker connector 4 x 1 header, pitch 2.00mm 24 RSC-3568J User’s Manual...
  • Page 25: Setting Jumpers & Connectors

    User’s Manual 2.3 Setting Jumpers & Connectors 2.3.1 AT/ATX Input power select (JATATX1) * Default 2.3.2 JUSBID connector (JUSBID) Client Mode HOST * * Default RSC-3568J User’s Manual 25...
  • Page 26: Jpvdd Connector (Jpvdd1)

    RSC-3568J User’s Manual 2.3.3 JPVDD connector (JPVDD1) +3VALW* +5VALW * Default 2.3.4 JRS4 connector (JRS4) RS-232 RS-485 RS-422 Mode (1-2) (1-2) COMA JDB1 (3-4) (3-4) (5-6) (5-6) COMB JRS3 (7-8) (7-8) 26 RSC-3568J User’s Manual...
  • Page 27: Battery Connector (Jrtc)

    User’s Manual 2.3.5 Battery connector (JRTC) Signal +RTCBATT * Default 2.3.6 Backlight control interface connector (JLVBL) Signal +12V_BL +12V_BL EN_BL PWM_BL RSC-3568J User’s Manual 27...
  • Page 28: Usb2.0 Connector (Jusb2)

    RSC-3568J User’s Manual 2.3.7 USB2.0 connector (JUSB2) Signal PIN PIN Signal +USB_5V_TS +USB_5V_TS USB2_HUB3_DM_R USB2_HUB4_DM_R USB2_HUB3_DP_R USB2_HUB4_DP_R 2.3.8 JAMIC connector (JAMIC1) Signal PIN PIN Signal HP_RIGHT_R HEAD_DET#_R HP_LEFT_R MIC1_INP MIC_JD# 28 RSC-3568J User’s Manual...
  • Page 29: J9505 Connector (J9505)

    User’s Manual 2.3.9 J9505 connector (J9505) Signal CAN1_VSS CAN1_L CAN1_H 2.3.10 J9506 connector (J9506) Signal CAN_VSS CANL CANH 2.3.11 Speaker connector (JSPK1) Signal SPK_L+ SPK_L- SPK_R+ SPK_R- RSC-3568J User’s Manual 29...
  • Page 30: General Purpose I/O Connector (Jdio1)

    2.3.12 General purpose I/O connector (JDIO1) Signal PIN PIN Signal +V5S_DIO I2C_3_LV_SCL I2C_3_LV_SDA DIO_GP27 DIO_GP17 DIO_GP26 DIO_GP16 DIO_GP25 DIO_GP15 DIO_GP24 DIO_GP14 DIO_GP23 DIO_GP13 DIO_GP22 DIO_GP12 DIO_GP21 DIO_GP11 DIO_GP20 DIO_GP10 2.3.13 JDBG connector (JDBG1) Signal DEBUG_RX2_CON DEBUG_TX2_CON 30 RSC-3568J User’s Manual...
  • Page 31: Jdbg Connector (Jdbg2)

    User’s Manual 2.3.14 JDBG connector (JDBG2) Signal RS232_RX3 RS232_TX3 2.3.15 eDP interface connector (JEDP1) Signal PIN PIN Signal +12V_BL +12V_BL +12V_BL +12V_BL +PANEL_VDD EDP_TX_D0P +PANEL_VDD EDP_TX_D0N EDP_TX_D1P EDP_TX_AUXN EDP_TX_D1N EDP_TX_AUXP EDP_HPD LCM_BL_EN_33V 25 CPU_eDP_PWM_33V RSC-3568J User’s Manual 31...
  • Page 32: Lvds Connector (Jlvds1)

    +PANEL_LEDK- +PANEL_LEDA MIPI_DSI_TX1_D0N MIPI_DSI_TX0_D0N MIPI_DSI_TX1_D0P MIPI_DSI_TX0_D0P MIPI_DSI_TX1_D1N MIPI_DSI_TX0_D1N MIPI_DSI_TX1_D1P MIPI_DSI_TX0_D1P MIPI_DSI_TX1_CLKN 26 25 MIPI_DSI_TX0_CLKN MIPI_DSI_TX1_CLKP 28 27 MIPI_DSI_TX0_CLKP MIPI_DSI_TX1_D2N MIPI_DSI_TX0_D2N MIPI_DSI_TX1_D2P MIPI_DSI_TX0_D2P MIPI_DSI_TX1_D3N MIPI_DSI_TX0_D3N MIPI_DSI_TX1_D3P MIPI_DSI_TX0_D3P 2.3.17 JDCIN connector (JDCIN2) Signal PIN PIN Signal +24V_ADP +24V_ADP 32 RSC-3568J User’s Manual...
  • Page 33: Jrs Connector (Jrs2)

    User’s Manual 2.3.18 JRS connector (JRS2) Signal PIN PIN Signal COM4_RXD COM3_RXD COM4_TXD COM3_TXD COM4_RTS COM3_RTS COM4_CTS COM3_CTS 2.3.19 JRS connector (JRS3) Signal PIN PIN Signal RXD_B DCD#_B TXD_B DTR#_B RTS#_B CTS#_B RSC-3568J User’s Manual 33...
  • Page 34: Jsense Connector (Jsense)

    2.3.20 JSENSE connector (JSENSE) Signal PIN PIN Signal +3VS_SEN_CONN +3VS_SEN_CONN I2C3_SCL_3.3V_CONN I2C5_SCL_3.3V_CONN I2C3_SDA_3.3V_CONN I2C5_SDA_3.3V_CONN SENSE0_IRQ_R SENSE2_IRQ_R 2.3.21 JTB connector (JTB1) Signal PIN PIN Signal +PWR_JTB1 (+5VALW) BU1_TV_3V LINUX_SW VOL_DOWN_3V VOL_UP_3V BU_BR+_3V PWRBTN_3V BU7_3V BU_BR-_3V LED_ORANGE_R LED_GREEN_R 34 RSC-3568J User’s Manual...
  • Page 35: Mechanical Drawing

    User’s Manual 3. Mechanical Drawing RSC-3568J User’s Manual 35...
  • Page 36 RSC-3568J User’s Manual Unit: mm 36 RSC-3568J User’s Manual...
  • Page 37: Maintenance & Troubleshooting

    System Maintenance Introduction If the components of the product fail they must be replaced. Please contact the system reseller or vendor to purchase the replacement parts. Please follow the safety precautions outlined in the sections that follow RSC-3568J User’s Manual 37...
  • Page 38: General Safety Precautions

    This equipment is not suitable for use in locations where children are likely to be present. DO NOT: ⚫ Drop the device. ⚫ In a site where the ambient temperature exceeds the rated temperature. 38 RSC-3568J User’s Manual...
  • Page 39: Anti - Static Precautions

    This reduces the possibility of ESD damage. ⚫ Only handle the edges of the electrical component. When handling the electrical component, hold the electrical component by its edges. Please ensure the following safety precautions are adhered to at all times. RSC-3568J User’s Manual 39...
  • Page 40: Maintenance And Cleaning

    Never drop any objects or liquids through the openings of the device. ⚫ Be cautious of any possible allergic reactions to solvents or chemicals used when cleaning the device. ⚫ Avoid eating, drinking and smoking within vicinity of the device. 40 RSC-3568J User’s Manual...
  • Page 41: Basic Troubleshooting

    No Console Input Devices are found Flash update is failed Typically for development use. The beep code is generated when platform cannot be reset because reset protocol is not available. Platform PCI resource requirements cannot be met RSC-3568J User’s Manual 41...
  • Page 42 RSC-3568J User’s Manual 42 RSC-3568J User’s Manual...
