Avalue Technology EAX-Q170KP-B1 User Manual

Intel core processors with intel q170 atx motherboard
Table of Contents

Advertisement

Quick Links

EAX-Q170KP-B1
Intel® Core™ Processors with Intel® Q170 ATX Motherboard
User's Manual
Ed – 04 March 2022
st
1
Part No. E2047AK1700R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EAX-Q170KP-B1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Avalue Technology EAX-Q170KP-B1

  • Page 1 EAX-Q170KP-B1 Intel® Core™ Processors with Intel® Q170 ATX Motherboard User’s Manual Ed – 04 March 2022 Part No. E2047AK1700R...
  • Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
  • Page 3 Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
  • Page 4 A product returned without proof of the purchase date is not eligible for warranty service. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. 4 EAX-Q170KP-B1 User’s Manual...
  • Page 5: Table Of Contents

    2.3.19 SPI connector (JSPI1) ........................29 2.3.20 Speaker connector (JSPK1) ......................29 2.3.21 Miscellaneous setting connector (JFP1) ..................30 2.3.22 CPU fan connector (CPUFAN1) ....................30 2.3.23 System fan connector 1 (SYSFAN1) ..................... 31 2.3.24 System fan connector 2 (SYSFAN3) ..................... 31 EAX-Q170KP-B1 User’s Manual...
  • Page 6 3.6.2.7.7 Parallel Port Configuration ..................... 53 3.6.2.8 NCT6106D H/W Monitor ......................54 3.6.2.8.1 Smart Fan Configuration ....................... 54 3.6.2.9 Serial Port Console Redirection .................... 55 3.6.2.9.1 Legacy Console Redirection Settings ................... 55 3.6.2.10 Intel TXT Configuration ......................56 6 EAX-Q170KP-B1 User’s Manual...
  • Page 7 Install Chipset Driver ....................80 Install VGA Driver ....................81 Install SOL Driver ....................82 Install Audio Driver (For Realtek ALC892 HD Audio) ..........83 Install LAN Driver ....................84 Install RST Driver ....................86 5. Mechanical Drawing ....................88 EAX-Q170KP-B1 User’s Manual...
  • Page 8: Getting Started

    1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EAX-Q170KP motherboard  2 x SATA cable  1 x I/O Shield  8 EAX-Q170KP-B1 User’s Manual...
  • Page 9: Document Amendment History

    User’s Manual 1.3 Document Amendment History Revision Date Comment March 2022 Avalue Initial Release EAX-Q170KP-B1 User’s Manual...
  • Page 10: Manual Objectives

    EAX-Q170KP-B1 User’s Manual 1.4 Manual Objectives This manual describes in details Avalue Technology EAX-Q170KP-B1 Single Board. We have tried to include as much information as possible but we have not duplicated information that is provided in the standard IBM Technical References, unless it proved to be necessary to aid in the understanding of this board.
  • Page 11: System Specifications

    Triple Display Audio AC97 Codec ALC888S(co-lay ALC897) Audio Amp 2 x 6W Amplifier Ethernet 1 x Intel® I219LM Gigabit Ethernet PHY LAN Chip 1 x Intel® I211AT PCI-e Gigabit Ethernet Ethernet Gigabit Ethernet Interface Internal I/O Connectors EAX-Q170KP-B1 User’s Manual 11...
  • Page 12 1 x 2 x 10 pin, pitch 2.54mm connector for Auxiliary panel 1 x 4 pin, pitch 2.54mm connector for Speaker Buzzer 1 x 2 x 5 pin, pitch 2.54mm connector for front Audio 1 x 4 pin, pitch wafer 2.00mm connector for 6W x 2 Speaker 12 EAX-Q170KP-B1 User’s Manual...
  • Page 13 Power on Type AT/ATX mode Operating Temp. 0 ~ 60°C (32~140°F) Storage Temp. -40 ~ 75°C Operating 0% ~ 90% relative humidity, non-condensing Humidity Size (L x W) 12" x 9.6" (304.8mm x 243.84mm) Weight 0.60 kg EAX-Q170KP-B1 User’s Manual 13...
  • Page 14 EAX-Q170KP-B1 User’s Manual Note: Specifications are subject to change without notice. 14 EAX-Q170KP-B1 User’s Manual...
  • Page 15: Architecture Overview-Block Diagram

    User’s Manual 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of EAX-Q170KP-B1. EAX-Q170KP-B1 User’s Manual 15...
  • Page 16: Hardware Configuration

    EAX-Q170KP-B1 User’s Manual 2. Hardware Configuration 16 EAX-Q170KP-B1 User’s Manual...
  • Page 17: Product Overview

    User’s Manual 2.1 Product Overview EAX-Q170KP-B1 User’s Manual 17...
  • Page 18: Jumper And Connector List

    4 x 1 wafer, pitch 2.54mm function supported) SYSFAN3 System fan connector 2 3 x 1 wafer, pitch 2.54mm JFP1 Miscellaneous setting connector 5 x 2 header, pitch 2.54 mm DIMM1/2/3/4 288-pin DDR4 DIMM socket AUDIO1 Audio connector 18 EAX-Q170KP-B1 User’s Manual...
  • Page 19 VGA1 VGA connector NGFF1 M.2 2230 KeyA Slot support WiFi module 13 x 2 header, pitch 2.54mm LPT1 LPT connector JSIM1 SIM card slot JSPDIF1 S/PDIF connector 5 x 1 header, pitch 2.54mm JSMB1 SMBus connector EAX-Q170KP-B1 User’s Manual 19...
  • Page 20: Setting Jumpers & Connectors

    EAX-Q170KP-B1 User’s Manual 2.3 Setting Jumpers & Connectors 2.3.1 Serial port 1 pin9 signal select (JRI1) Ring* +12V * Default 2.3.2 Serial port 2 pin9 signal select (JRI2) Ring* +12V * Default 20 EAX-Q170KP-B1 User’s Manual...
  • Page 21: At/Atx Power Mode Select (Jatatx1)

    User’s Manual 2.3.3 AT/ATX Power Mode Select (JATATX1) * Default 2.3.4 Clear CMOS (JCMOS1) Protect* Clear CMOS * Default EAX-Q170KP-B1 User’s Manual 21...
  • Page 22: Serial Port 2 Connector (Jcom2A)

    EAX-Q170KP-B1 User’s Manual 2.3.5 Serial port 2 connector (JCOM2A) Signal PIN PIN Signal NRXD NDCD# NDTR# NTXD NDSR# NCTS# NRTS# JNRI# 2.3.6 COM2 RS485/422 connector (JCOM2B) Signal PIN PIN Signal 485TX- 422RX- 485TX+ 422RX+ 22 EAX-Q170KP-B1 User’s Manual...
  • Page 23: Serial Port 3/4/5/6 Connector (Jcom3/4/5/6)

    User’s Manual 2.3.7 Serial port 3/4/5/6 connector (JCOM3/4/5/6) Signal PIN PIN Signal NRXD NDCD# NDTR# NTXD NDSR# NCTS# NRTS# NRI# 2.3.8 General purpose I/O connector (JDIO1) Signal PIN PIN Signal SMB_CLK_9555 10 SMB_DATA_9555 EAX-Q170KP-B1 User’s Manual 23...
  • Page 24: Sgpio Connector (Jsgpio1)

    EAX-Q170KP-B1 User’s Manual 2.3.9 SGPIO connector (JSGPIO1) Signal PIN PIN Signal SGIO_LOAD SGIO_DATOUT0 SGIO_CLK SGIO_DATOUT1 2.3.10 ATX Power connector (ATXPWR1) Signal Signal +3.3V +12V +12V +V5SB ATX_PWRGD ATX_PSON# +3.3V -12V +3.3V +3.3V 24 EAX-Q170KP-B1 User’s Manual...
  • Page 25: Power Connector (Atx12V1)

    User’s Manual 2.3.11 Power connector (ATX12V1) Signal PIN PIN Signal +12V +12V +12V +12V 2.3.12 SMBus connector (JSMB1) Signal SMB_CLK_MAIN SMB_DATA_MAIN SMB_ALERT#_MAIN +3.3V EAX-Q170KP-B1 User’s Manual 25...
  • Page 26: Usb Connector 1 (Jusb1)

    EAX-Q170KP-B1 User’s Manual 2.3.13 USB connector 1 (JUSB1) Signal PIN PIN Signal USB_R_DP14 USB_R_DP13 USB_R_DN14 USB_R_DN13 SS_USB_TXP_C_6 SS_USB_TXP_C_5 15 SS_USB_TXN_C_6 SS_USB_TXN_C_5 17 SS_USB_RXP_C_6 SS_USB_RXP_C_5 18 SS_USB_RXN_C_6 SS_USB_RXN_C_5 USBVCC_DE USBVCC_DE 2.3.14 USB connector 2 (JUSB2) Signal USBVCC56 USB_R_DN5 USB_R_DP5 26 EAX-Q170KP-B1 User’s Manual...
  • Page 27: Usb Connector 4 (Jusb4)

    User’s Manual 2.3.15 USB connector 4 (JUSB4) Signal Signal USBVCC_BC USBVCC_BC USB_R_DN12 USB_R_DN11 USB_R_DP12 USB_R_DP11 2.3.16 Battery connector (JBAT1) Signal RTC_VBAT_1 EAX-Q170KP-B1 User’s Manual 27...
  • Page 28: Audio Connector (Jaudio1)

    2.3.17.1 Signal Description –Audio connector (JAUDIO1) Signal Signal Description LINE2_JD AUDIO IN (LINE_RIN/LIN)sense pin MIC2_JD MIC IN (MIC_RIN/LIN) sense pin 2.3.18 LPC connector (JLPC1) Signal PIN PIN Signal LPC_AD0_R +3.3V LPC_AD1_R BUF_PLT_RST# LPC_AD2_R LPC_FRAME#_R LPC_AD3_R LPC_CLK LPC_SERIRQ_R 28 EAX-Q170KP-B1 User’s Manual...
  • Page 29: Spi Connector (Jspi1)

    User’s Manual 2.3.19 SPI connector (JSPI1) Signal PIN PIN Signal +3.3V SSPI_CS0#_R SSPI_SCLK_R SSPI_SO_R SSPI_SI_R SSPI_HOLD#0 2.3.20 Speaker connector (JSPK1) Signal SPK_L+ SPK_L- SPK_R+ SPK_R- EAX-Q170KP-B1 User’s Manual 29...
  • Page 30: Miscellaneous Setting Connector (Jfp1)

    EAX-Q170KP-B1 User’s Manual 2.3.21 Miscellaneous setting connector (JFP1) Signal PIN PIN Signal HDD_LED+ PWR_LED+ HDD_LED- PWE_LED- RSET_BTN# PWRBTN# 2.3.22 CPU fan connector (CPUFAN1) Signal +12V CPUFANIN CPUFANOUT 30 EAX-Q170KP-B1 User’s Manual...
  • Page 31: System Fan Connector 1 (Sysfan1)

    User’s Manual 2.3.23 System fan connector 1 (SYSFAN1) Signal +12V SYSFANIN1 SYSFANOUT1 2.3.24 System fan connector 2 (SYSFAN3) Signal +12V SYS_FAN_IN_2 EAX-Q170KP-B1 User’s Manual 31...
  • Page 32: Ps/2 Keyboard & Mouse Connector (Jkbms1)

    EAX-Q170KP-B1 User’s Manual 2.3.25 PS/2 keyboard & mouse connector (JKBMS1) Signal MSCK MSDT KBDT KBCK 2.3.26 S/PDIF connector (JSPDIF1) Signal SPDIF_O 32 EAX-Q170KP-B1 User’s Manual...
  • Page 33: External Speaker Connector (Jbz1)

    User’s Manual 2.3.27 External Speaker connector (JBZ1) Signal SIO_BEEP 2.3.28 LPT connector (LPT1) Signal PIN PIN Signal PT-STB- PT_AFD# PTD0 ERR# PTD1 PT_PAR_INIT# PTD2 PT_SLIN# PTD3 PTD4 PTD5 PTD6 PTD7 ACK# BUSY SLCT EAX-Q170KP-B1 User’s Manual 33...
  • Page 34: Auxiliary Panel Connector (Jauxp1)

    EAX-Q170KP-B1 User’s Manual 2.3.29 Auxiliary Panel connector (JAUXP1) Signal PIN PIN Signal SMB_CLK_MAIN CASEOPEN# ERROR_LED SMB_DATA_MAIN ERROR_LED# FRONT_LAN1_ACT 13 FRONT_LAN1_LINK100# 16 FRONT_LAN1_LINK1000# FRONT_LAN2_ACT 17 FRONT_LAN2_LINK100# 20 FRONT_LAN2_LINK1000# 34 EAX-Q170KP-B1 User’s Manual...
  • Page 35: Bios Setup

    User’s Manual 3.BIOS Setup EAX-Q170KP-B1 User’s Manual 35...
  • Page 36: Introduction

    If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 36 EAX-Q170KP-B1 User’s Manual...
  • Page 37: Using Setup

    Note: Some of the navigation keys differ from one screen to another.  To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. EAX-Q170KP-B1 User’s Manual 37...
  • Page 38: Getting Help

    BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 38 EAX-Q170KP-B1 User’s Manual...
  • Page 39: Bios Setup

    <Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. EAX-Q170KP-B1 User’s Manual 39...
  • Page 40: System Language

    Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 40 EAX-Q170KP-B1 User’s Manual...
  • Page 41: Advanced Menu

    This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 3.6.2.1 Intel RC ACPI Settings Item Options Description Auto[Default], Enabled - OS Controlled ASPM, Disabled - Native ASPM Disabled BIOS Controlled ASPM Enabled EAX-Q170KP-B1 User’s Manual 41...
  • Page 42: Cpu Configuration

    Number of cores to enable in each processor Active Processor Cores package. Enabled for Windows XP and Linux (OS Disabled optimized for Hyper-Threading Technology) Hyper-Threading Enabled[Default], and Disabled for other OS (OS not optimized for Hyper-Threading Technology). 42 EAX-Q170KP-B1 User’s Manual...
  • Page 43: Cpu - Power Management Control

    Disabled C-State Auto Demotion Configure C-State Auto Demotion. C1 and C3[Default] Disabled C-State Un-demotion Configure C-State Un-demotion. C1 and C3[Default] Disabled, Package C-State Demotion Package C-State Demotion. Enabled[Default] Disabled, Package C-State Un-demotion Package C-State Un-demotion. Enabled[Default] EAX-Q170KP-B1 User’s Manual 43...
  • Page 44: View/Configure Turbo Options

    Disabled Mode. When disabled AMT BIOS Features are no longer Disabled, supported and user is no longer able to access MEBx AMT BIOS Features Enabled[Default] Setup. Note: This option does not disable Manageability Features in FW. 44 EAX-Q170KP-B1 User’s Manual...
  • Page 45: Oem Flags Settings

    Option Description Disabled[Default], OEMFlag Bit 15: Unconfigure ME with resetting Unconfigure ME Enabled MEBx password to default. 3.6.2.3.2 Firmware Update Configuration Item Option Description Disabled[Default], Me FW Image Re-Flash Enable/Disable Me FW Image Re-Flash function. Enabled EAX-Q170KP-B1 User’s Manual 45...
  • Page 46: Trusted Computing

    3.6.2.4 Trusted Computing Item Options Description Enables or Disables BIOS support for security Disable, Security Device Support device. O.S. will not show Security Device. TCG EFI Enable[Default] protocol and INT1Ainterface will not be available. 3.6.2.5 ACPI Settings 46 EAX-Q170KP-B1 User’s Manual...
  • Page 47 Enable/Disable system waked up by Ring Disabled Wake Up by Ring signal from S3(Sleep). S4(Hibernate) and Enabled[Default], S5(Soft Off) States. Enable/Disable USB Power delivery in S3 USB Standby Power Disabled (Sleep), S4 (Hibernate) and S5 (Soft Off) Delivery Enabled[Default], States. EAX-Q170KP-B1 User’s Manual 47...
  • Page 48: S5 Rtc Wake Settings

    Enable or disable System wake on RTC larm event. Disabled[Default], Fixed Time: System will wake on the hr::min::sec Wake system from S5 Fixed Time specified. Dynamic_Time: System will wake on the Dynamic Time current time + Increase minute(s). 48 EAX-Q170KP-B1 User’s Manual...
  • Page 49: Super Io Configuration

    Set Parameters of Serial Port 4 (COMD). Serial Port 5 Configuration Set Parameters of Serial Port 5 (COME). Serial Port 6 Configuration Set Parameters of Serial Port 6 (COMF). Parallel Port Configuration Set Parameters of Parallel Port (LPT/LPTE). EAX-Q170KP-B1 User’s Manual 49...
  • Page 50: Serial Port 1 Configuration

    3.6.2.7.1 Serial Port 1 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.7.2 Serial Port 2 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 50 EAX-Q170KP-B1 User’s Manual...
  • Page 51: Serial Port 3 Configuration

    UART 232 422 485 RS422 Set COM Port as RS232, RS422 or RS485 mode. RS485 3.6.2.7.3 Serial Port 3 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.7.4 Serial Port 4 Configuration EAX-Q170KP-B1 User’s Manual 51...
  • Page 52: Serial Port 5 Configuration

    Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.7.5 Serial Port 5 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 3.6.2.7.6 Serial Port 6 Configuration 52 EAX-Q170KP-B1 User’s Manual...
  • Page 53: Parallel Port Configuration

    3.6.2.7.7 Parallel Port Configuration Item Option Description Enabled[Default], Parallel Port Enable or Disable Parallel Port (LPT/LPTE). Disabled STD Printer Mode[Default] SPP Mode Device Mode Change the Printer Port mode. EPP-1.9 and SPP Mode EPP-1.7 and SPP Mode EAX-Q170KP-B1 User’s Manual 53...
  • Page 54: Nct6106D H/W Monitor

    SmartFan IV Smart Fan), SmartFan IV™ Mode. CPU Fan Manual Duty 0-255 CPU Fan manual output duty: 0 to 255. Manual Smart Fan Mode Selection: Manual Mode (No SYSFAN1 Mode SmartFan IV[Default], Smart Fan), SmartFan IV™ Mode. 54 EAX-Q170KP-B1 User’s Manual...
  • Page 55: Serial Port Console Redirection

    User’s Manual 3.6.2.9 Serial Port Console Redirection Item Options Description Disabled[Default], Console Redirection Console Redirection Enable or Disable. Enabled 3.6.2.9.1 Legacy Console Redirection Settings EAX-Q170KP-B1 User’s Manual 55...
  • Page 56: Intel Txt Configuration

    Select a COM port to display redirection of Legacy Serial Redirection Port COM1 Legacy OS and Legacy OPROM Messages 3.6.2.10 Intel TXT Configuration 3.6.2.11 Network Stack Configuration Item Options Description Disabled[Default] Network Stack Enable/Disable UEFI Network Stack. Enabled 56 EAX-Q170KP-B1 User’s Manual...
  • Page 57: Csm Configuration

    User’s Manual 3.6.2.12 CSM Configuration Item Options Description Disabled[Default] CSM Support Enable/Disable CSM Support. Enabled 3.6.2.13 USB Configuration The USB Configuration menu helps read USB information and configures USB settings. EAX-Q170KP-B1 User’s Manual 57...
  • Page 58: Chipset

    Floppy enumerates devices according to their media format. Optical drives are emulated as ‘CDROM’, Mass Storage Devices Forced FDD Hard Disk drives with no media will be emulated according CD-ROM to a drive type. 3.6.3 Chipset 58 EAX-Q170KP-B1 User’s Manual...
  • Page 59: System Agent (Sa) Configuration

    User’s Manual 3.6.3.1 System Agent (SA) Configuration Item Option Description Disabled VT-d VT-d capability. Enabled[Default] 3.6.3.1.1 Memory Configuration EAX-Q170KP-B1 User’s Manual 59...
  • Page 60: Graphics Configuration

    EAX-Q170KP-B1 User’s Manual 3.6.3.1.2 Graphics Configuration Item Option Description Auto[Default] IGFX Select which of IGFX/PEG/PCI Graphics device should Primary Display be Primary Display Or select SG for Switchable Gfx. PCIE 3.6.3.1.3 DMI/OPI Configuration 60 EAX-Q170KP-B1 User’s Manual...
  • Page 61: Peg Port Configuration

    Select PCI Express Max Transaction Layer Max TLP payload size 256TLP[Default] Packet payload size. Enabled: PCIe ASPM will be programmed Disabled[Default] Program PCIe ASPM after OpROM after OpROM. Disabled: PCIe ASPM will be Enabled programmed before OpROM. EAX-Q170KP-B1 User’s Manual 61...
  • Page 62: Peg Port Feature Configuration

    EAX-Q170KP-B1 User’s Manual 3.6.3.1.4.1 PEG Port Feature Configuration Item Option Description Disabled[Default] Detect Non-Compliance PCI Express Device Detect Non-Compliance Device Enabled in PEG 3.6.3.2 PCH-IO Configuration 62 EAX-Q170KP-B1 User’s Manual...
  • Page 63: Pci Express Configuration

    User’s Manual Item Option Description Disabled Enable or disable OnBoard PCH LAN PHY LAN PHY Controller Enabled[Default] Controller. 3.6.3.2.1 PCI Express Configuration 3.6.3.2.1.1 PCI-E x4 Slot (PCI-E Port 1) EAX-Q170KP-B1 User’s Manual 63...
  • Page 64 3.6.3.2.1.1.1 Extra options Item Option Description Detect Non-Compliance Disabled[Default] Detect Non-Compliance PCI Express Device. If Device Enabled enable, it will take more time at POST time 64 EAX-Q170KP-B1 User’s Manual...
  • Page 65 L0s State AUTO – BIOS auto ASPM configure DISABLE – Disables ASPM. Disabled Disabled[Default] L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2 Auto[Default] Gen1 PCIe Speed Configure PCIe Speed. Gen2 Gen3 EAX-Q170KP-B1 User’s Manual 65...
  • Page 66 POST time Prefetchable Memory Prefetchable Memory Range for this Root Bridge. Reseved Memory Alignment Reseved Memory Alignment (0 - 31 bits) Prefetchable Memory Reseved Memory Alignment (0 - 31 bits) Alignment 66 EAX-Q170KP-B1 User’s Manual...
  • Page 67 User’s Manual 3.6.3.2.1.3 PCI-E to PCI Bridge (PCI-E Port 6) Item Option Description Disabled[Default] PCI-E to PCI Bridge (PCI-E Port 6) Control the PCI Express Root Port. Enabled 3.6.3.2.1.4 PCI-E x1 Slot (PCI-E Port 7) EAX-Q170KP-B1 User’s Manual 67...
  • Page 68 3.6.3.2.1.4.1 Extra options Item Option Description Detect Non-Compliance Disabled[Default] Detect Non-Compliance PCI Express Device. If Device Enabled enable, it will take more time at POST time 68 EAX-Q170KP-B1 User’s Manual...
  • Page 69 Prefetchable Memory Reseved Memory Alignment (0 - 31 bits) Alignment 3.6.3.2.1.5 Intel I211 LAN Chip (PCI-E Port 8) Item Option Description Disabled Intel I211 LAN Chip (PCI-E Port 8) Control the PCI Express Root Port. Enabled[Default] EAX-Q170KP-B1 User’s Manual 69...
  • Page 70 PCIe Speed Configure PCIe Speed. Gen2 Gen3 The number of milliseconds reference code will wait for link to exit Detect state for Detect Timeout enabled ports before assuming there is no device and potentially disabling the port. 70 EAX-Q170KP-B1 User’s Manual...
  • Page 71 POST time Prefetchable Memory Prefetchable Memory Range for this Root Bridge. Reseved Memory Alignment Reseved Memory Alignment (0 - 31 bits) Prefetchable Memory Reseved Memory Alignment (0 - 31 bits) Alignment EAX-Q170KP-B1 User’s Manual 71...
  • Page 72: Sata And Rst Configuration

    Gen3 Enabled[Default], SATA Port Enable or Disable SATA Port. Disabled Hard Disk Drive[Default] Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive. 72 EAX-Q170KP-B1 User’s Manual...
  • Page 73: Hd Audio Configuration

    Disabled HDA will be unconditionally disabled Enabled = HDA will HD Audio Enabled, be unconditionally enabled Auto = HDA will be enabled if Auto[Default] present, disabled otherwise. 20 dB Amplifier Gain Select Amplifier Gain(dB). 26 dB[Default], EAX-Q170KP-B1 User’s Manual 73...
  • Page 74: Security

    EAX-Q170KP-B1 User’s Manual 3.6.4 Security  Administrator Password Set setup Administrator Password  User Password Set User Password 74 EAX-Q170KP-B1 User’s Manual...
  • Page 75: Secure Boot Menu

    Attempt Secure Boot enrolled, System mode is User/Deployed, and CSM Enabled function is disabled. Secure Boot mode selector. ‘Custom’ Mode enables Standard Secure Boot Mode users to change Image Execution policy and manage Custom[Default] Secure Boot Keys. EAX-Q170KP-B1 User’s Manual 75...
  • Page 76: Key Management

    EAX-Q170KP-B1 User’s Manual 3.6.4.1.1 Key Management Item Option Description Enabled, Allow to provision factory default Secure Provision Factory Defaults Disabled[Default] Boot keys when System is in Setup Mode. 3.6.5 Boot 76 EAX-Q170KP-B1 User’s Manual...
  • Page 77: Save And Exit

    Reset the system after saving the changes. 3.6.6.2 Discard Changes and Reset Any changes made to BIOS settings during this session of the BIOS setup program are discarded. The setup program then exits and reboots the controller. EAX-Q170KP-B1 User’s Manual 77...
  • Page 78: Restore Defaults

    This option restores all BIOS settings to the factory default. This option is useful if the controller exhibits unpredictable behavior due to an incorrect or inappropriate BIOS setting. 3.6.6.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices. 78 EAX-Q170KP-B1 User’s Manual...
  • Page 79: Drivers Installation

    User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. EAX-Q170KP-B1 User’s Manual 79...
  • Page 80: Install Chipset Driver

    All drivers can be found on the Avalue Official Website: http://www.avalue.com.tw. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Install. Step 4. Complete setup. Step1. Click Next. Step 2. Click Accept. 80 EAX-Q170KP-B1 User’s Manual...
  • Page 81: Install Vga Driver

    Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Step 5. Click Finish to complete setup. Click Yes to accept license agreement. EAX-Q170KP-B1 User’s Manual 81...
  • Page 82: Install Sol Driver

    Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Next Step 4. Click Finish to complete the setup Step 1. Click Next to continue setup. Step 2. Click Next. 82 EAX-Q170KP-B1 User’s Manual...
  • Page 83: Install Audio Driver (For Realtek Alc892 Hd Audio)

    All drivers can be found on the Avalue Official Website: http://www.avalue.com.tw. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step1. Click Next to Install. Step 2. Select Finish to complete Installation. EAX-Q170KP-B1 User’s Manual 83...
  • Page 84: Install Lan Driver

    Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Next. Step 1. Click Install Drivers and Step 4. Click Next. Software. Step 2. Click Next. Step 5. Click Install. 84 EAX-Q170KP-B1 User’s Manual...
  • Page 85 User’s Manual Step 6. Click Install. Step 7. Click Finish to complete setup. EAX-Q170KP-B1 User’s Manual 85...
  • Page 86: Install Rst Driver

    Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Click Next. Step 5. Click Next. 86 EAX-Q170KP-B1 User’s Manual...
  • Page 87 User’s Manual Step 6. Click Finish to complete setup. EAX-Q170KP-B1 User’s Manual 87...
  • Page 88: Mechanical Drawing

    EAX-Q170KP-B1 User’s Manual 5. Mechanical Drawing 88 EAX-Q170KP-B1 User’s Manual...
  • Page 89 User’s Manual Unit: mm EAX-Q170KP-B1 User’s Manual 89...
  • Page 90 EAX-Q170KP-B1 User’s Manual Unit: mm 90 EAX-Q170KP-B1 User’s Manual...
