- Page 1 EQM-EHL Intel® Atom® x6000E Series/Pentium® /Celeron® SoC processor Qseven Module User’s Manual Ed – 01 October 2023 Copyright Notice Copyright © 2023 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No.E2047400100R...
-
Page 2: Table Of Contents
3.6.2.2.1 CPU - Power Management Control ..............26 3.6.2.3 PCH-FW Configuration ..................27 3.6.2.3.1 Firmware Update Configuration ................27 3.6.2.3.2 PTT Configuration ....................28 3.6.2.4 Trusted Computing ....................28 3.6.2.5 ACPI Settings ....................... 29 3.6.2.6 IT5571 Super IO Configuration ................30 2 EQM-EHL User’s Manual... - Page 3 Launch EFI Shell from filesystem device ............. 51 4. Drivers Installation....................... 52 Install Chipset Driver ................... 53 Install ME Driver ....................54 Install VGA Driver ....................55 Install Audio Driver ....................57 Install Ethernet Driver ..................58 5. Mechanical Drawing ....................60 EQM-EHL User’s Manual 3...
-
Page 4: Getting Started
Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. 1.2 Packing List 1 x EQM-EHL Qseven Module ⚫ 1 x Desiccant (5g) ⚫... -
Page 5: Document Amendment History
User’s Manual 1.3 Document Amendment History Revision Date Comment October 2023 Avalue Initial Release EQM-EHL User’s Manual 5... -
Page 6: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to set up EQM-EHL QSeven Module or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 7: System Specifications
B2: LVDS Max resolution 1920 x 1080@60Hz Dual channel 18/24-bits LVDS (Chrontel CH7511A-BF eDP to LVDS) Note: By BOM Option via HW/BIOS, refer to the block diagram for detail. Multiple Display Up to 2 independent displays EQM-EHL User’s Manual 7... - Page 8 1 Test PSD : 0.026G²/Hz , 2.16 Grms 2 Test frequency : 5~500 Hz 3 Test axis : X,Y and Z axis 4 Test time : 30 minutes per each axis 5 IEC 60068-2-64 Test Fh 8 EQM-EHL User’s Manual...
- Page 9 * Elkhart Lake platform doesn’t support Win11. The current message is OS Information that Microsoft expects to support Win11 in 2024. Please confirm if crrent Carrier board for EQM-APL can use in EQM-EHL. ⚫ Carrier Board The Carrier Board for EQM-APL: REV-Q703-B1-00R / E9697Q70304R DIP REV-Q703 Rev.B1 W/Q7 VER:2.1...
-
Page 10: Architecture Overview-Block Diagram
EQM-EHL 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of EQM-EHL QSeven Module. 10 EQM-EHL User’s Manual... -
Page 11: Hardware Configuration
User’s Manual 2. Hardware Configuration EQM-EHL User’s Manual 11... -
Page 12: Product Overview
EQM-EHL 2.1 Product Overview 12 EQM-EHL User’s Manual... -
Page 13: Connector List
The following tables list the function of each of the board's jumpers and connectors. Connectors Label Function Note BIOS_SPI1 (Reserved for BIOS programming) 10P wafer, pitch 1.00mm (ACES 83217) AT/ATX mode selector QSeven connector EQM-EHL User’s Manual 13... -
Page 14: Setting Connectors
ATX mode *Default 2.3.1.1 Signal Description –AT/ATX mode selection AT/ATX mode Description AT mode Auto-power on, no need to press Power button to enable power on/off ATX mode Press the power button to enable power on/off 14 EQM-EHL User’s Manual... -
Page 15: Qseven Connector (Gf1)
USB_VBUS USB_ID GND3 GND4 USB_P1- USB_P0- GND5 PWGIN USB_P1+ USB_P0+ BATLOW# RSTBTN# GND13 GND14 SATA0_TX+ SATA1_TX+ LVDS_A0+ 99 100 LVDS_B0+ SATA0_TX- SATA1_TX- LVDS_A0- 101 102 LVDS_B0- SATA_ACT# GND6 LVDS_A1+ 103 104 LVDS_B1+ SATA0_RX+ SATA1_RX+ SATA0_RX- SATA1_RX- EQM-EHL User’s Manual 15... - Page 16 VCC_7 225 226 VCC_8 GND23 159 160 GND24 VCC_9 227 228 VCC_10 PCIE3_TX+ 161 162 PCIE3_RX+ VCC_11 229 230 VCC_12 PCIE3_TX- 163 164 PCIE3_RX- GND25 165 166 GND26 PCIE2_TX+ 167 168 PCIE2_RX+ PCIE2_TX- 169 170 PCIE2_RX- 16 EQM-EHL User’s Manual...
-
Page 17: Installing Heatsink
User’s Manual 2.4 Installing Heatsink Standard Temperature Step1. Using 4 screws to lock the Heatsink from PCB backside. EQM-EHL User’s Manual 17... - Page 18 EQM-EHL Wide Temperature Step1. Using 4 screws to lock the Heatsink from PCB backside. 18 EQM-EHL User’s Manual...
-
Page 19: Bios Setup
User’s Manual 3.BIOS Setup EQM-EHL User’s Manual 19... -
Page 20: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 20 EQM-EHL User’s Manual... -
Page 21: Using Setup
Note: Some of the navigation keys differ from one screen to another. • To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “➢” pointer marks all sub menus. EQM-EHL User’s Manual 21... -
Page 22: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 22 EQM-EHL User’s Manual... -
Page 23: Bios Setup
<Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. EQM-EHL User’s Manual 23... -
Page 24: System Language
Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 24 EQM-EHL User’s Manual... -
Page 25: Cpu Configuration
When enabled, a VMM can utilize the additional Intel (VMX) Virtualization Disabled hardware capabilities provided by Vanderpool Technology Enabled[Default], Technology. All[Default], Number of cores to enable in each processor Active Processor Cores package. 3.6.2.2 Power & Performance EQM-EHL User’s Manual 25... -
Page 26: Cpu - Power Management Control
Enable/Disable processor Turbo Mode (requires Disabled Turbo Mode Enabled[Default], EMTTM enabled too). AUTO means enabled. Disabled[Default] Enable/Disable CPU Power Management. Allows C states Enabled CPU to go to C states when it's not 100% utilized. 3.6.2.2.1.1 View/Configure Turbo Options 26 EQM-EHL User’s Manual... -
Page 27: Pch-Fw Configuration
Options Description Disabled When Disabled ME will be put into ME Me State Enabled[Default], Temporarily Disabled Mode. 3.6.2.3.1 Firmware Update Configuration Item Options Description Disabled[Default], Enable/Disable Me FW Image Re-Flash Me FW Image Re-Flash Enabled function. EQM-EHL User’s Manual 27... -
Page 28: Ptt Configuration
3.6.2.4 Trusted Computing Item Options Description Enables or Disables BIOS support for security Disable device. O.S. will not show Security Device. Security Device Support Enable[Default], TCG EFI protocol and INT1A interface will not be available. 28 EQM-EHL User’s Manual... -
Page 29: Acpi Settings
Hibernate (OS/S4 Sleep State). This Enable Hibernation Enabled[Default], option may be not effective with some Select the highest ACPI sleep state the Suspend Disabled, ACPI Sleep State system will enter when the SUSPEDN S3 (Suspend to RAM)[Default] button is pressed. EQM-EHL User’s Manual 29... -
Page 30: It5571 Super Io Configuration
Please refer to 3.6.2.6.1 for more information. Item Description Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). 3.6.2.6.1 Serial Port 1 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], 30 EQM-EHL User’s Manual... -
Page 31: Ec 5571 H/W Monitor
Enable or disable System wake on alarm event. Disabled[Default], Select FixedTime, system will wake on the Wake system from S5 Fixed Time hr::min::sec specified. Select DynamicTime, Dynamic Time System will wake on the current time + Increase minutes(s). EQM-EHL User’s Manual 31... -
Page 32: Serial Port Console Redirection
Options Description Disabled[Default], Console Redirection Console Redirection Enable or Disable. Enabled Disabled[Default], Console Redirection EMS Console Redirection Enable or Disable. Enabled 3.6.2.10 USB Configuration The USB Configuration menu helps read USB information and configures USB settings. 32 EQM-EHL User’s Manual... -
Page 33: Network Stack Configuration
Optical drives are emulated as ‘CDROM’, Mass Storage Devices Forced FDD Hard Disk drives with no media will be emulated according CD-ROM to a drive type. 3.6.2.11 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default] EQM-EHL User’s Manual 33... -
Page 34: Nvme Configuration
EQM-EHL 3.6.2.12 NVMe Configuration 3.6.3 Chipset 34 EQM-EHL User’s Manual... -
Page 35: System Agent (Sa) Configuration
Item Option Description Disabled VT-d VT-d capability. Enabled[Default] Enable/Disable above 4GB Above 4GB MMIO BIOS Enabled MemoryMapped IO BIOS assignment. This assignment Disabled[Default] is disabled automatically when Aperture Size is set to 2048MB. 3.6.3.1.1 Memory Configuration EQM-EHL User’s Manual 35... -
Page 36: Graphics Configuration
Select the GTT Size. 8MB[Default] Select the Aperture Size. Note: Above 4GB 128MB MMIO BIOS assignment is automatically 256MB[Default] Aperture Size enabled when selecting 2048MB aperture. 512MB To use this feature, please disable CSM 1024MB Support. 36 EQM-EHL User’s Manual... -
Page 37: Pch-Io Configuration
User’s Manual 3.6.3.2 PCH-IO Configuration 3.6.3.2.1 PCI Express Configuration EQM-EHL User’s Manual 37... - Page 38 L0s State AUTO – BIOS auto ASPM configure DISABLE – Disables ASPM. L0sL1 Auto Disabled[Default], L1 Substates L1.1 PCI Express L1 Substates settings. L1.1 & L1.2 Disabled[Default], Enable/Disable Precision Time Enabled, Measurement. Auto[Default] Gen1 PCIe Speed Select PCIe speed. Gen2 Gen3 38 EQM-EHL User’s Manual...
- Page 39 L0s State AUTO – BIOS auto ASPM configure DISABLE – Disables ASPM. L0sL1 Auto Disabled[Default], L1 Substates L1.1 PCI Express L1 Substates settings. L1.1 & L1.2 Disabled[Default], Enable/Disable Precision Time Enabled, Measurement. Auto[Default] Gen1 PCIe Speed Select PCIe speed. Gen2 Gen3 EQM-EHL User’s Manual 39...
- Page 40 L0s State AUTO – BIOS auto ASPM configure DISABLE – Disables ASPM. L0sL1 Auto Disabled[Default], L1 Substates L1.1 PCI Express L1 Substates settings. L1.1 & L1.2 Disabled[Default], Enable/Disable Precision Time Enabled, Measurement. Auto[Default] Gen1 PCIe Speed Select PCIe speed. Gen2 Gen3 40 EQM-EHL User’s Manual...
- Page 41 L0s State AUTO – BIOS auto ASPM configure DISABLE – Disables ASPM. L0sL1 Auto Disabled[Default], L1 Substates L1.1 PCI Express L1 Substates settings. L1.1 & L1.2 Disabled[Default], Enable/Disable Precision Time Enabled, Measurement. Auto[Default] Gen1 PCIe Speed Select PCIe speed. Gen2 Gen3 EQM-EHL User’s Manual 41...
- Page 42 L0s State AUTO – BIOS auto ASPM configure DISABLE – Disables ASPM. L0sL1 Auto Disabled[Default], L1 Substates L1.1 PCI Express L1 Substates settings. L1.1 & L1.2 Disabled[Default], Enable/Disable Precision Time Enabled, Measurement. Auto[Default] Gen1 PCIe Speed Select PCIe speed. Gen2 Gen3 42 EQM-EHL User’s Manual...
-
Page 43: Sata And Rst Configuration
3.6.3.2.2 SATA And RST Configuration Item Option Description Disabled SATA Controller(s) Enable/Disable SATA Device. Enabled[Default], Disabled Port 0 Enable or Disable SATA Port Enabled[Default], Disabled Port 1 Enable or Disable SATA Port Enabled[Default], 3.6.3.2.3 USB Configuration EQM-EHL User’s Manual 43... -
Page 44: Hd Audio Configuration
Compliance Mode. Change to enabled for Enabled, Compliance Mode testing. 3.6.3.2.4 HD Audio Configuration Item Option Description Control Detection of the HD-Audio device. Disable Disabled HD Audio = HDA will be unconditionally disabled Enabled = Enabled[Default], HDA will be unconditionally enabled. 44 EQM-EHL User’s Manual... -
Page 45: Scs Configuration
User’s Manual 3.6.3.2.5 SCS Configuration Item Option Description Disabled eMMC 5.1 Controller Enable or Disable SCS eMMC 5.1 Controller. Enabled[Default], Disabled SDCard 3.0 Controller Enable or Disable SCS SDHC 3.0 Controller. Enabled[Default], 3.6.3.3 Board & Panel Configuration EQM-EHL User’s Manual 45... - Page 46 Off[Default], PWR-On After PWR-Fail AC Ioss resume. Last State Disabled[Default], 30 sec 40 sec 50 sec Watch Dog Select WatchDog. 1 min 2 min 10 min 30 min Disabled[Default], SHOW DMI INFO SHOW DMI INFO Enabled 46 EQM-EHL User’s Manual...
-
Page 47: Security
User’s Manual 3.6.4 Security ⚫ Administrator Password Set setup Administrator Password ⚫ User Password Set User Password 3.6.4.1 Secure Boot EQM-EHL User’s Manual 47... -
Page 48: Key Management
Secure Boot mode options: Standard or Custom. Standard In Custom mode, Secure Boot Policy variables Secure Boot Mode Custom[Default] can be configured by a physically present user without full authentication 3.6.4.1.1 Key Management 48 EQM-EHL User’s Manual... -
Page 49: Boot
Number of seconds to wait for setup activation Setup Prompt Timeout key. 65535(0xFFFF) means indefinite waiting. On[Default] Bootup NumLock State Select the Keyboard NumLock state Disabled[Default] Enables or disables Quiet Boot option Quiet Boot Enabled Boot Option #1/2/3 Set the system boot order. EQM-EHL User’s Manual 49... -
Page 50: Save And Exit
EQM-EHL 3.6.6 Save and exit 3.6.6.1 Save Changes and Reset Reset the system after saving the changes. 3.6.6.2 Discard Changes and Reset Reset system setup without saving any changes. 50 EQM-EHL User’s Manual... -
Page 51: Restore Defaults
User’s Manual 3.6.6.3 Restore Defaults Restore/Load Default values for all the setup options. 3.6.6.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shell.efi) from one of the available filesystem devices. EQM-EHL User’s Manual 51... -
Page 52: Drivers Installation
EQM-EHL 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. 52 EQM-EHL User’s Manual... -
Page 53: Install Chipset Driver
All drivers can be found on the Avalue Official Website: http://www.avalue.com.tw. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Install. Step1. Click Next. Step 4. Complete setup. Step 2. Click Accept. EQM-EHL User’s Manual 53... -
Page 54: Install Me Driver
Windows 10 operation system. Step 3. Click Next to continue installation. Step 4. Click Finish to complete setup. Step1. Click Next to start installation. Step 2. Click Next. Step 5. Click Finish to complete setup. 54 EQM-EHL User’s Manual... -
Page 55: Install Vga Driver
Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Yes. Step 1. Click Begin installation. Step 4. Click Start. Step 2. Click Next. Step 5. Click Cancel. EQM-EHL User’s Manual 55... - Page 56 EQM-EHL Step 6. Click Cancel. Step 7. Click Finish to complete setup. 56 EQM-EHL User’s Manual...
-
Page 57: Install Audio Driver
Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Installing. Step 1. Click Next to continue setup. Step 4. Click Finish to complete the setup. Step 2. Click Cancel. EQM-EHL User’s Manual 57... -
Page 58: Install Ethernet Driver
Windows 10 operation system. Step 3. Click Next to continue setup. Step 1. Click Install Drivers and Software. Step 4. Click Next. Step 5. Click Install. Step 2. Click Next. 58 EQM-EHL User’s Manual... - Page 59 User’s Manual Step 6. Installing. Step 7. Click Finish to complete the setup. EQM-EHL User’s Manual 59...
-
Page 60: Mechanical Drawing
EQM-EHL 5. Mechanical Drawing 60 EQM-EHL User’s Manual... - Page 61 User’s Manual Unit: mm EQM-EHL User’s Manual 61...
