4 Specifications and Dimensions

4.2 Hyperfold

4.2.1 Key features

• High power density in a compact footprint
• Exceptional upper bass speed and articulation
• Four high power 15" low frequency drivers
• Distinctive aluminium cabinet bracing
• 18 mm birch plywood construction
• Textured 'TourCoat' polyurea finish

4.2.2 Hyperfold specifications

Frequency response
Efficiency
1
Crossover points
Nominal impedance
Power handling 2
Maximum output 3
Configuration
Dispersion
Connectors
Height
Width
Depth
Weight
Enclosure
Finish
1 Measured in half space 2 AES2 - 1984 compliant
UG10570-2.0 - Incubus System User Guide V2.0
60 Hz - 190 Hz ±3 dB
109.5 dB 1W/1m
Preset via dedicated processor
2 x 4 Ω
4000 W AES
142 dB cont, 145 dB peak
4 x 15" low frequency drivers
Array dependent
2 x 4-pole speakON™ NL4
748 mm (29.4")
738 mm (29.1")
1218 mm (47.9")
150 kg (330.7 lbs)
18 mm birch plywood
Textured 'TourCoat' polyurea, smooth cellulose
3 Calculated
Page 9
