Coway Air Purifier
Airmega 240(W) / Airmega 240(I)
This product is for the domestic market only. Product voltage does not work overseas.
Please read this user manual before use for your safety and proper product use.
A warranty card is included in this user manual.
This paper can be recycled.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Airmega 240 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Coway Airmega 240

Summary of Contents for Coway Airmega 240

  • Page 1 Coway Air Purifier Airmega 240(W) / Airmega 240(I) This product is for the domestic market only. Product voltage does not work overseas. Please read this user manual before use for your safety and proper product use. A warranty card is included in this user manual.
  • Page 2 The air quality sensor allows you to check the "Indoor Air Quality (IAQ)" in real-time through the four-level color display. Superior Air Cleaning Coway Airmega 240 is equipped with a powerful Green True HEPA™ filter and smartly optimizes filter system to remove contaminants according to the room’s current air quality.

  • Page 3: Table Of Contents

    DEAR CUSTOMERS COWAY Coway air purifier. Thank you for purchasing the Please read this user manual carefully for correct use and maintenance. You can refer to the user manual to troubleshoot product issues while using it. Please keep this user manual in a safe place as it includes the product warranty.
  • Page 4 SAFETY INFORMATION The following information is for user safety that should be observed. It is to ensure user safety and prevent property damage. Please read the precautions carefully and use the product correctly. 120 V~, 60 Hz only DANGER : Failing to follow the precautions below may result in serious injury or even death.

  • Page 5: For Information

    For Information Do not install in places with a lot of humidity or dust or places where water (rainwater) splashes. Do not use or store combustible gases or flammable materials near this product. If there is a strange sound, burning smell, or smoke from the device, immediately unplug the power plug and contact a service center.

  • Page 6: Safety Information

    SAFETY INFORMATION WARNING : Failing to follow the precautions below may result in considerable physical injury or property damage. Do not unplug by pulling on the power cord. Plug into a power socket connected to an earth leakage circuit breaker (current sensitivity 30 mA or less).
  • Page 7 For Information Do not block the vent with laundry or curtains. Remove dust from the pre-filter with a vacuum cleaner or water. Periodically wash the pre-filter and dry it well in a shady place with good ventilation. People with physical, sensory, or mental impairment as well as children must be supervised or guided while using the device.

  • Page 8: Part Names

    PART NAMES Front / Rear Air outlet Air quality sensor Air inlet Front cover Power cord Air outlet grille Control panel...
  • Page 9 For Information Accessories MANUAL-PRODUCT USER MANUAL CARD-FILTER REPLACEMENT REGISTRATION ENGLISH / 08...

  • Page 10: Air Purification

    AIR PURIFICATION PROCESS For Information Pre-filter Removes large dust particles, mold, hair, and pet hair. Max2 filter (Activated Carbon + Green True HEPA™) Captures and reduces more than 99 % of VOCs and odors such as NH3, CH3CHO, CH3COOH. It also captures and reduces up to 99.97 % of airborne particles, allergens, and contaminants down to 0.3 microns in size.
  • Page 11 BEFORE USE How to Use Please check before use! This product is for 120 V~, 60 Hz only. Make sure to connect the power plug to a grounded 120 V~, 60 Hz outlet. How to Install Filter - Be sure to remove the packaging plastic wrapping before installing the filter. - Use the filter indoors only.
  • Page 12 INDICATORS AND BUTTONS Indicators SMART Mode Indicator Speed Indicator Sleep Mode Indicator Filter replacement Indicator Timer Indicator Air Quality Indicator SMART Mode Indicator Speed Indicator It turns on when the SMART mode is It shows the current fan speed. activated. Each indicator is turned on as per its airflow speed.
  • Page 13 How to Use Buttons Power Button Mode Button Light / Filter reset Button Timer Button Child lock Button Power Button Mode Button Use this button to turn the air Use this button to adjust the fan purifier on or off. speed.
  • Page 14 HOW TO USE - Plug the air purifier into an outlet before operating the product. Tips - The product operates in SMART mode by default when turned on. Manual & SMART Mode Press the Power button and then select the speed of the fan by pressing the Speed button.
  • Page 15 ADJUST PARTICLE SENSOR How to Use How to adjust the sensitivity of the air quality sensor The air quality sensor is set to standard sensitivity when the product is shipped out. If the pollution level stays at the highest level after 2 hours of operation or remains at the lowest level for more than 1 hour when the air does not seem clean.

  • Page 16: How To Clean

    HOW TO CLEAN - Always unplug the air purifier before cleaning. - Do not use detergents that contain organic solvents (solvent, thinner, etc), bleach, Tips chlorine, or abrasives. - Do not put the air purifier in water or spray water directly on it. Cleaning the Air Quality sensor (every 2 months) 1.
  • Page 17 Maintenance - Always unplug the air purifier before cleaning the filter. - The pre-filter can be restored by removing dust or washing with water. - Failure to clean the pre-filter for a long time may result in poor product Tips performance.

  • Page 18: Filter

    - Refer to the filter installation method on page 10 to replace the filter. - Be sure to check the front side when installing the filter. - Use a genuine Coway filter to maintain the optimal performance of the product. - Always unplug the power cord before replacing the filter.
  • Page 19 Maintenance - The cover with the filter attached may damage if it is dropped while moving, so do not move it upside down. Tips - Max2 filters are consumables. How to Replace Max2 filter (Replace every 12 months) PRE LED: Pre-filter MAX2 LED: Max2 filter 1.
  • Page 20 TROUBLESHOOTING The air purifier may operate abnormally not because of the product malfunction but because of minor causes or because the user is not familiar with the product use. In such a case, problems can be solved easily even without help from the service center just by checking the following. If the problem persists after checking the following, contact the service center.
  • Page 21 SPECIFICATION Others Air Purifier Product name Model name Airmega 240(W) , Airmega 240(I) Rated voltage 120 V~, 60 Hz Power consumption 60 W Washable Pre-Filter + Max2 filter set Filter (Activated Carbon + Green True HEPA™) Installation location Indoor 403 ft2 (43 ㎡)*...
  • Page 22 MEMO...
  • Page 23 MEMO ENGLISH / 22...
  • Page 24 MEMO...
  • Page 25 Coway will at its option repair or replace correction of wiring or plumbing, or correction of the part and/or the product. This limited warranty is unauthorized repairs/installation.
  • Page 26 Coway. notify Coway in writing at least 30 days in advance of Damage resulting from misuse, abuse, improper initiating the arbitration by sending a letter to Coway at installation, repair, or maintenance.
  • Page 27 Arbitration Rules and Procedures. To begin the federal judicial district in which you reside unless arbitration of a claim, either you or Coway must make we both agree to another location or we agree to a a written demand for arbitration. The arbitration will be telephonic arbitration.
  • Page 28 9239962 www.cowaymega.com...
