Summary of Contents for Coway Airmega 160
- Page 1 Coway Air Purifier Airmega 160(W), Airmega 160(N) • This product is for domestic market only. Product voltage does not work overseas. • For your safety and proper use of the product, please read this user manual before use. • Warranty card is included in this user manual.
- Page 2 (IAQ)” in real time through the four-level color display. Superior Air Cleaning Coway Airmega 160 is equipped with a powerful Green True HEPA™ filter and smartly optimizes the filter system to remove contaminants according to the room’s current air quality.
-
Page 3: Table Of Contents
DEAR CUSTOMERS Coway air purifier. Thank you for purchasing the Please read this user manual carefully for correct use and maintenance of the product. You can refer to the user manual to troubleshoot product issues while using it. Please keep this user manual in a safe place as it includes the product warranty. -
Page 4: Safety Information
SAFETY INFORMATION The following information is for user safety that should be observed. It is to ensure user safety and prevent property damage. Please read the precautions carefully and use the product accordingly. 120 V~, 60 Hz only DANGER : failure to follow the precautions below may result in serious injury or even death. - Page 5 • Do not use or store combustible gases or flammable materials near this product. • If there is a strange sound, burning smell, or smoke from the device, immediately unplug the power plug and contact a service center. • Never immerse the product in water. •...
-
Page 6: Warning
SAFETY INFORMATION WARNING : failure to follow the precautions below may result in considerable physical injury or property damage. • Do not unplug by pulling on the power cord. • Plug into a power socket connected to an earth leakage circuit breaker (current sensitivity 30 mA or less). - Page 7 • Do not use for a long time in places that are sealed or where children, the elderly, or sick people are. • Do not block the vent with laundry or curtains. • Remove dust from the pre-filter with a vacuum cleaner or water. •...
-
Page 8: Part Names
PART NAMES Front / Rear Air outlet Air quality sensor Air Inlet Front cover Power cord Air outlet grille Control panel... - Page 9 Accessories User Manual Product Registration...
-
Page 10: Air Purification Process
AIR PURIFICATION PROCESS ■ Pre-filter Removes large dust particles, mold, hair, and pet hair. ■ Deodorization filter Deodorization Filter is particularly effective at trapping odor and harmful gas to keep your place fresh and odor-free. ■ Green True HEPA™ filter It captures and reduces airborne particles in the air such as pollen, pollution, and other allergens. - Page 11 BEFORE USE Please check before use! This product is for 120 V~, 60 Hz only. Make sure to connect the power plug to a grounded 120 V~, 60 Hz outlet. How to Install Filter - Be sure to remove the packaging plastic wrapping before installing the filter. - Use the filter indoors only.
- Page 12 INDICATORS AND BUTTONS Indicators Auto Mode Speed Filter replacement Indicator Indicator indicator Air quality indicator Speed Indicator Auto Mode Indicator It shows the current fan speed. It turns on when Auto mode is Each indicator is activated base on activated. the airflow speed.
- Page 13 Buttons Power Button Speed Button Air Quality Indicator Light On/Off / Filter Replacement Button Power Button Speed Button Use this button to turn the air purifier Use this button to adjust the fan on or off. speed. Available settings for the fan ∗...
- Page 14 HOW TO USE - Plug the air purifier into an outlet before operating the product. - The product operates in auto mode by default when turned on. Tips ■ Manual & Auto Mode Press the power button and then select the speed of the fan by pressing the speed ▶...
- Page 15 ADJUST PARTICLE SENSOR How to adjust the sensitivity of the air quality sensor When the product is shipped out, the air quality sensor is set to standard sensitivity. Users can change the sensitivity of the air quality sensor as follows if the pollution level remains at the highest level after 2 hours of operation or stays at the lowest level for more than 1 hour when the air does not appear clean.
-
Page 16: How To Clean
HOW TO CLEAN - Always unplug the air purifier before cleaning. - Do not use detergents that contain organic solvents (solvent, thinner, etc), bleach, chlorine, or abrasives. Tips - Do not put the air purifier in water or spray water directly on it. ■... - Page 17 - Always unplug the air purifier before cleaning the filter. - The Pre-filter can be restored by removing dust or by washing with water. - Failure to clean the pre-filter for a long time may result in poor product performance. Tips - Cleaning will not restore the Green True HEPA™...
- Page 18 - Refer to the filter installation method on page 10 to replace the filter. - Be sure to check the front side when installing the filter. - Use a genuine Coway filter to maintain the optimal performance of the product. - Always unplug the power cord before replacing the filter.
- Page 19 ■ How to Replace Deodorization / Green True HEPA™ filter (Replace every 6 months / 12 months) Odor LED: Deodorization filter HEPA LED: Green True HEPA™ filter 1. Open the front cover and remove the filter set entirely. ∗ It prevents dust generation inside the space. 2.
- Page 20 TROUBLESHOOTING The air purifier may operate abnormally not due to a product malfunction but due to minor factors or because the user is unfamiliar with the device's operation. In such cases, problems may be resolved even without the assistance of a service center by verifying the following. Contact the service center if the problem remains after you have checked the following.
-
Page 21: Product
SPECIFICATION Product name Air Purifier Model name Airmega 160(W), Airmega 160(N) Rated voltage 120 V~, 60 Hz Phase Single phase Power consumption 35 W Product insulation class Class 2 equipment Dust collection method Mechanical dust collection (Green True HEPA™ filter)
