Trouble Shooting
NEED HELP?
If your LapStacker problem is not listed below OR you are having trouble fixing the
®
issue and need help, please contact Adaptdefy
you to get your LapStacker
1. Webbing folds over itself and jams the Retractor Unit
I. Remove the Retractor Unit from the wheelchair by unscrewing it from the
Bracket using the 3mm Allen Key supplied.
II. Carefully undo the two fasteners holding the Retractor housings together.
III. Remove the Top Housing to reveal the webbing spool.
IV. Locate the Locking Tab and pull this back to release the lock and allow the
spool to turn freely.
V. Pull on the end of the webbing until the folded section is revealed and the
fold is removed.
VI. Release the Locking Tab.
VII. Carefully let the webbing retract back onto the spool. Make sure the webbing
remains flat and level with the Retractor Unit to avoid it folding back onto
itself.
VIII. Fasten the Top Housing back in place and reinstall on your chair.
2. Webbing retracts completely inside the Retractor Housing
I. Remove the Retractor Unit from the wheelchair by unscrewing it from the
Bracket.
II. Using the 3mm Allen Key supplied, carefully undo the two fasteners holding
the Retractor enclosure together.
III. Remove the Top Housing to reveal the webbing spool.
IV. Locate the end of the webbing and pull it through the slot in the Base
Housing.
V. Attach the Buckle to prevent the webbing retracting.
VI. Fasten the Top Housing back in place and reinstall on your chair.
®
working correctly.
®
directly and our staff will work with
