Mounting
1.
8 mm
1. Unscrew the securing screw using an open-ended wrench.
2. Rotate the housing in the desired direction.
3. Tighten the securing screw (1.5 Nm for plastic housing; 2.5 Nm for aluminum or
stainless steel housing).
4.2.5 Turning the display
Opening the cover
1. Loosen the screw of the securing clamp of the electronics compartment cover using an
Allen key (3 mm) and turn the clamp 90 ° counterclockwise.
2. Unscrew the electronics compartment cover and check the cover seal; replace it if
necessary.
Turning the display module
14
2.
2.
2.
1.
Levelflex FMP56, FMP57 HART
3.
max. 350°
1.
3 mm
8 mm
A0032242
A0021430
A0036401
