Valcourt AC04352 Manual

Birch wood logs with black glowing wool for use on fg00004, fg00040 & fg00007 (s42) fireplace

Advertisement

Quick Links

WITH BLACK GLOWING WOOL
FOR USE ON FG00004, FG00040 & FG00007 (S42) FIREPLACE
INSTALLATION INSTRUCTIONS
WARNING
If the information in these instructions are not
followed exactly, a fire or explosion may result
causing property damage, personal injury or
loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch;
do not use any phone in your
building.
Leave the building immediately.
Immediately call your gas supplier
from a neighbor's phone.
Follow the gas supplier's
instructions.
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
INSTALLER: LEAVE THIS MANUAL WITH THE COMPLIANCE.
CONSUMER: READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
BIRCH WOOD LOGS
AC04352
WARNING
If not installed, operated and maintained
in accordance with the manufacturer's
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
NOTICE: Ceramic fiber logs
may differ in appearance from
those shown in this manual.
Safety tested
according to ANSI Z21.88-2017
and CSA 2.33-2017 standards
by an accredited laboratory.
46291A
2021-11-11

Advertisement

loading

Summary of Contents for Valcourt AC04352

  • Page 1 BIRCH WOOD LOGS WITH BLACK GLOWING WOOL AC04352 FOR USE ON FG00004, FG00040 & FG00007 (S42) FIREPLACE INSTALLATION INSTRUCTIONS WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
  • Page 2 AC04352 LOG SET IDENTIFICATION INDEX LETTER PART FRONT VIEW TOP VIEW & DESCRIPTION NUMBER (A) FRONT LEFT LOG 22438 (B) FRONT RIGHT LOG 22439 (C) REAR CROSSOVER 22440 (D) REAR LOG 22441 (E) SMALL LEFT LOG 22442 (F) LEFT CROSSOVER...
  • Page 3: Log Placement

    LOG SET INSTALLATION PREPARATION The colors of the logs in the following images may differ from the birch logs but the positioning of the logs remains the same. LOG PLACEMENT The positioning of logs is critical to safe and clean operation of this fireplace. Sooting and other problems may result if the logs are not properly and firmly positioned in the fireplace.
  • Page 4 LOG SET INSTALLATION PREPARATION Figure 2: Pins and tabs location Figure 3: Allowed area for glowing wool Figure 4: Picture of the glowing wool placed placement on the burner WARNING Apply loose material (glowing wool) per instruction manual. DO NOT apply extra material not supplied with this kit.
  • Page 5: Log Set Placement

    LOG SET PLACEMENT STEP 1: Lift the tabs 6, 7 and 8 located on the burner cover as shown in figure 2. STEP 2: Put the log A on the pins 1 and 2 located on the burner. Installation instructions - Log Set Page 5...
  • Page 6 LOG SET PLACEMENT STEP 3: Put the log B on the pin 3 located on the burner and on the pin on top of log A. STEP 4: Put the log C on the pin on top of log B and on the left side of the pilot. Page 6 Installation Instructions - Log Set...
  • Page 7 LOG SET PLACEMENT STEP 5: Put the log D on the pins 4 and 5 located on the log support. Installation instructions - Log Set Page 7...
  • Page 8 LOG SET PLACEMENT STEP 6: Put the log E on tab 6 located on the burner cover. Page 8 Installation Instructions - Log Set...
  • Page 9 LOG SET PLACEMENT STEP 7: Put the log G on the pin on the top right of log D and on tab 8 located on the burner cover. Installation instructions - Log Set Page 9...
  • Page 10 LOG SET PLACEMENT STEP 8: Put the log F on the pin on the top left of log D and on tab 7 located on the burner cover. STEP 9: This completes the log set installation. Display the glowing wool in the designated areas as shown in figure 3 all around the circular ports.
  • Page 11 Installation instructions - Log Set Page 11...
  • Page 12 This document is available for free download on the manufacturer’s website. It is a copyrighted document. Stove Builder International inc. Resale is strictly prohibited. The manufacturer may update 250, De Copenhague street, this document from time to time and cannot be responsible St-Augustin-de-Desmaures (Québec), Canada for problems, injuries, or damages arising out of the use G3A 2H3...
