Valcourt AC04347 Installation Instructions Manual

Driftwood logs with ember and black glowing wool for use on fg00002 and fg00020 (srf40) fireplace

Advertisement

Quick Links

DRIFTWOOD LOGS WITH EMBER AND BLACK
FOR USE ON FG00002 AND FG00020 (SRF40) FIREPLACE
INSTALLATION INSTRUCTIONS
WARNING
If the information in these instructions are not
followed exactly, a fire or explosion may result
causing property damage, personal injury or
loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch;
do not use any phone in your
building.
Leave the building immediately.
Immediately call your gas supplier
from a neighbor's phone.
Follow the gas supplier's
instructions.
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
INSTALLER: LEAVE THIS MANUAL WITH THE COMPLIANCE.
CONSUMER: READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
GLOWING WOOL
AC04347
If not installed, operated and maintained
in accordance with the manufacturer's
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
NOTICE: Ceramic fiber logs
may differ in appearance from
We suggest that our
those shown in this manual.
gas hearth products be
installed and serviced
by professionals who
are certified in the U.S.
according to ANSI Z21.88-2017
by the National Fireplace
Institute
®
(NFI) as NFI
and CSA 2.33-2017 standards
Gas Specialists.
by an accredited laboratory.
WARNING
Safety tested
46273A
2021-12-08

Advertisement

loading

Summary of Contents for Valcourt AC04347

  • Page 1 DRIFTWOOD LOGS WITH EMBER AND BLACK GLOWING WOOL AC04347 FOR USE ON FG00002 AND FG00020 (SRF40) FIREPLACE INSTALLATION INSTRUCTIONS WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
  • Page 2 AC04347 LOG SET IDENTIFICATION INDEX LETTER PART FRONT VIEW TOP VIEW & DESCRIPTION NUMBER (1) REAR RIGHT 22454 BOTTOM LOG (2) CENTER BOTTOM 22452 (3) REAR LEFT BOTTOM 22453 (4) FRONT RIGHT 22459 CROSSOVER LOG (5) TOP LEFT 22461 CROSSOVER LOG...
  • Page 3: Log Placement

    LOG INSTALLATION PREPARATION The colors of the logs in the following images may differ from the driftwood logs but the positioning of the logs remains the same. LOG PLACEMENT The positioning of logs is critical to safe and clean operation of this fireplace. Sooting and other problems may result if the logs are not properly and firmly positioned in the fireplace.
  • Page 4 Figure 2: Pin Locations Figure 3: Glowing embers placement WARNING Apply loose material (embers) per instruction manual. DO NOT apply extra material not supplied with this appliance. All previously applied loose material (embers) must be removed prior to reapplication. Do not cover large portswith loose material (embers). Page 4 Installation Instructions - Driftwood Log Set...
  • Page 5: Log Set Placement

    LOG SET PLACEMENT STEP 1. Place LOG 2 onto burner base pins (4) and (5) located between the front and rear burner tubes. STEP 2. Place LOG 3 onto burner base pins (1) located to the left behind the rear burner. Installation instructions - Driftwood Log Set Page 5...
  • Page 6 LOG SET PLACEMENT STEP 3. Place Log 1 to the right behind the rear burner onto burner base pins (2) and (3). STEP 4. Place the glowing embers (A) on the top of the burner tubes, covering all ports. Then place decorative rocks (B) alongside the front burner tube on the burner base.
  • Page 7 LOG SET PLACEMENT STEP 5. Place LOG 10 and 11 to the left across the front burner tube. STEP 6. Place Log 8 onto the lower left pin of Log 2. Installation instructions - Driftwood Log Set Page 7...
  • Page 8 LOG SET PLACEMENT STEP 7. Place Log 7 onto the pin located on top left of the Log 2. Page 8 Installation Instructions - Driftwood Log Set...
  • Page 9 LOG SET PLACEMENT STEP 8. Place log 4 on top right of Log 1 and Log 2. Secure the bottom part of the log onto pin (7). STEP 9. Place Log 5 on top of Log 7 and onto the pin of the Log 8. Secure the bottom part of the log onto pin (6).
  • Page 10 LOG SET PLACEMENT STEP 10. Place Log 6 onto the pin on top right of Log 1. Page 10 Installation Instructions - Driftwood Log Set...
  • Page 11 LOG SET PLACEMENT STEP 11. Place Log 9 into the front recess of Log 2. Installation instructions - Driftwood Log Set Page 11...
  • Page 12 This document is available for free download on the manufacturer’s website. It is a copyrighted document. Stove Builder International inc. Resale is strictly prohibited. The manufacturer may update 250, De Copenhague street, this document from time to time and cannot be responsible St-Augustin-de-Desmaures (Québec), Canada for problems, injuries, or damages arising out of the use G3A 2H3...
