CATEYE STRADA
Quick Start Manual
Install the speed sensor
Install the magnet
Adjust the positions of the
speed sensor and magnet
Adjust the clearance between
the speed sensor and magnet
Fixing the wire
Winding the wire
(Installation is completed)
Adjust the positions of the speed sensor
and magnet
Adjust the position so that the magnet passes
through the SENSOR LINE of the speed sensor.
After adjusting, tighten firmly the magnet.
Return
Return to Contents
How to install the speed sensor
Speed sensor
(inside the front fork)
Magnet
SENSOR LINE
Next
