Install the speed sensor
Install the magnet
Adjust the positions of the
speed sensor and magnet
Adjust the clearance between
the speed sensor and magnet
Fixing the wire
Winding the wire
(Installation is completed)
Install the magnet
Temporarily secure the magnet to the right side
spoke of the front wheel spoke.
Tighten the magnet to such an extent that it can be
moved.
Return
Return to Contents
How to install the speed sensor
Right side spoke
Magnet
To the SENSOR ZONE
