USER GUIDE
ADVANCED 1-PORT
SECURE KVM ISOLATOR
USM-2S0-MM1
K/M
CONSOLE
CAC
12VDC2.0A
DP IN
MODELS:
• KVS4-8001DX
• KVS4-8001HX
• KVS4-8001VX
REV: 2.0B
AUDIO
1-Port SH Secure DVI-I KVM w/audio and CAC
1-Port SH Secure HDMI KVM w/audio and CAC
1-Port SH Secure DP KVM w/audio and CAC
DP OUT
AUDIO
PW
SL
DATE: 10/25/2021
K/M
CAC
INPUT
1
Advertisement
Table of Contents
Related Manuals for Black Box KVS4-8001DX
Summary of Contents for Black Box KVS4-8001DX
- Page 1 CONSOLE AUDIO DP OUT 12VDC2.0A INPUT AUDIO DP IN MODELS: • KVS4-8001DX 1-Port SH Secure DVI-I KVM w/audio and CAC • KVS4-8001HX 1-Port SH Secure HDMI KVM w/audio and CAC • KVS4-8001VX 1-Port SH Secure DP KVM w/audio and CAC...
-
Page 2: Table Of Contents
USER GUIDE TABLE OF CONTENTS TECHNICAL SPECIFICATIONS WHAT’S IN THE BOX? SECURITY FEATURES FRONT AND REAR INSTALLATION CAC INSTALLATION: COMMON ACCESS CARD, SMART CARD READER CAC PORT CONFIGURATION AUDITING: Dumping the Event Log via User Menu Options RESET: Restore Factory Default LED’s BEHAVIOR SYSTEM OPERATION TROUBLESHOOTING... -
Page 3: Technical Specifications
USER GUIDE TECHNICAL SPECIFICATIONS VIDEO Format DisplayPort, HDMI, DVI-I Dual Link KVS4-8001DX (1) DVI-I 23-pin (female) KVS4-8001HX (1) HDMI 19-pin (female) Host Interface (1) DisplayPort 20-pin (female) KVS4-8001VX KVS4-8001DX (1) DVI-I 23-pin (female) (1) HDMI 19-pin (female) KVS4-8001HX User Console Interface... -
Page 4: What's In The Box
Check if the button is jammed. In this case, release the jammed button and recycle the power. Video LED CONSOLE AUDIO DVI-I OUT CAC LED CONSOLE AUDIO 12VDC2.0A DVI-I OUT INPUT AUDIO DVI IN Figure 4-1: KVS4-8001DX Front panel 12VDC2.0A INPUT AUDIO DVI IN Figure 4-2: KVS4-8001DX Rear panel... -
Page 5: Installation
INSTALLATION SYSTEM REQUIREMENTS 1. Black Box Secure PSS is compatible with standard personal/portable computers, servers or thin-clients, running operating systems such as Windows or Linux. 2. The peripheral devices that are supported by the Secure KVM Isolator are listed in the following table:... - Page 6 USB OUT CAC OUT DVI-I OUT AUDIO IN Figure 6-1: KVS4-8001DX IMPORTANT WARNINGS - FOR SECURITY REASONS: • This product does not support wireless devices. Do not attempt to use a wireless keyboard or a wireless mouse with this product.
- Page 7 USER GUIDE INSTALLATION (Continued) KVS4-8001HX: 1. Ensure that power is turned off or disconnected from the unit and the computers. 2. Use a HDMI cable to connect the HDMI output port from the computer to the corresponding HDMI IN port of the unit.
- Page 8 USER GUIDE INSTALLATION (Continued) KVS4-8001VX: 1. Ensure that power is turned off or disconnected from the unit and the computers. 2. Use a DisplayPort cable to connect the DisplayPort output port from the computer to the corresponding DP IN port of the unit.
- Page 9 At the end of the boot-up, ensure all computers are con-nected to the Secure KVM Isolator through each port to verify that all are properly presenting video on the connected display. For additional assistance or information, please refer to the Black Box Secure KVM Isolator EDID Configuration Guide available at ftp://ftp.blackbox.com/Secure%20KVM%20Switches/.
-
Page 10: Cac Installation: Common Access Card, Smart Card Reader
USER GUIDE CAC (COMMON ACCESS CARD, SMART CARD READER) INSTALLATION INSTALLATION The following steps are intended for the system administrator or IT manager only. CAC connection to the computer requires a USB cable connection separate from the keyboard and mouse. This allows the CAC to be connected independently from the keyboard and mouse. -
Page 11: Auditing: Dumping The Event Log Via User Menu Options
USER GUIDE AUDITING: Dumping the Event Log via User Menu Options The following steps are intended for the system administrator. The Event Log is a detailed report of critical activities stored in the Secure KVM Isolator memory. A comprehensive feature list and guidance for Administration and Security Management Tools can be found in the Administrator’s Guide available for download from: https://www.blackbox.com/NIAP4/documentation. -
Page 12: Led's Behavior
Secure KVM Isolator has been TAMPERED with and all functions are Flashing EDID problem – Learn EDID to fix the problem permanently disabled. Please contact Black Box User Console Interface – CAC LED: technical support at info@blackbox.com... -
Page 13: System Operation
USER GUIDE SYSTEM OPERATION Front Panel Control No controls are required beyond ensuring the product is powered on and all peripheral/computer ports are connected. TROUBLESHOOTING No Power • Make sure that the power adapter is securely connected to the power connector of the unit. •... -
Page 14: Limited Warranty Statement
18 months, which duration begins on the date of purchase by the customer. Customer is responsible for maintaining proof of date of purchase. Black Box limited warranty covers only those defects which arise as a result of normal use of the product, and do not apply to any: a. - Page 15 USER GUIDE NOTICE The information contained in this document is subject to change without notice. Black Box makes no warranty of any kind with regard to this material, including but not limited to, implied warranties of merchantability and fitness for particular purpose.
