AJAX KeyPad User Manual page 8

1. Switch on the hub and check its Internet connection (the logo glows white
or green).
2. Install the Ajax app
at least one room.
3. Make sure that the hub is not armed, and it does not update by checking its
status in the Ajax app.
Only users with administrator rights can add a device to the app
How to connect KeyPad to the hub:
1. Select the Add Device option in the Ajax app.
2. Name the device, scan/write manually the QR Code (located on the body
and packaging), and select the location room.
3. Select Add — the countdown will begin.
4. Switch on KeyPad by holding power button for 3 seconds — it will blink once
with the keyboard backlight.
For detection and pairing to occur, KeyPad should be located within the
coverage of the wireless network of the hub (at the same protected object).
A request for connection to the hub is transmitted for a short time at the
moment of switching on the device.
If KeyPad failed to connect to the hub, switch it off for 5 seconds and retry.
The connected device will appear in the app device list. Update of the device
statuses in the list depends on the detector ping interval in the hub settings (the
default value is 36 seconds).
There are no pre-set passwords for KeyPad. Before using a KeyPad, set all necessary
passwords: common, personal, and duress code if you are forced to disarm the system.
. Create the account, add the hub to the app, and create
