- Page 1 U S E R M A N U A L I N A L T O . H O U S E 7kg/4kg Combo Washer Dryer MODEL CODE/S I F L W 7 D 4 0 F O R A L L A U S T R A L I A N H O M E S V 1 .
-
Page 2: Welcome
Again, thank you for choosing an InAlto appliance and we look forward to being of service to you. Scan to Register your InAlto Appliance or go to: →... -
Page 3: Table Of Contents
24 Warranty Information Customer Care InAlto recommends the use of original spare parts. When contacting our customer service team on 1300 11 4357, please ensure that you have the following information at hand (which can be found on your appliances’ rating plate). -
Page 4: Safety Instructions
Safety Instructions IMPORTANT! CAUTION: RISK TO CHILDREN! Please read the following safety information thoroughly • This appliance is not intended for use by persons and follow it strictly to minimise the risk of fire or (including children) with reduced physical, sensory explosion, electric shock and to prevent property or mental capabilities, or lack of experience and damage, personal injury or loss of life. - Page 5 OPERATION AND MAINTENANCE ELECTRICAL CONNECTION • Never use any flammable, explosive or toxic solvents. • Make sure the supply cable is not trapped by the machine, as it could get damaged. Do not use gasoline and alcohol etc. as detergents. •...
- Page 6 Safety Instructions (Cont.) BEFORE TRANSPORT: • Transport bolts shall be reinstalled to the machine by a specialised person. • Accumulated water shall be drained out of the machine. • This appliance is heavy. Transport with care. Never hold any protruding part of the machine when lifting. The machine door cannot be used as a handle.
-
Page 7: Your Combo Washer Dryer
Product Description Top cover Your Combo Washer Dryer Water supply hose INSTALLATION Control panel Product Description IFLW7D40 Power supply cord Detergent dispenser Top Cover Top cover Water Drum Supply Hose Water supply hose Control Panel Control panel Detergent Power Cord... - Page 8 Installation IMPORTANT! If the power cord is damaged, it must be replaced by Residentia Group or one of it’s authorised service representatives. Please contact 1300 11 HELP (4357) and ensure the appliance is completely disconnected from the power supply. TRANSPORT Move cautiously.
- Page 9 e the transport bolts from the backside before using the product. • You must remove the transport bolts from the backside before using the product. INSTALLATION INSTALLATION Remove transport bolts Remove transport bolts Warning! Warning! REMOVING TRANSPORT BOLTS • You must remove the transport bolts from the backside before using the product. Loosen the 4 transport Remove the bolts Remove the bolts...
-
Page 11: Operating Instructions
Operating Instructions OPERATION BEFORE FIRST USE Leave your unit to stand for 2 hours after transporting. Before Each Washing CAUTION! • The ambient temperature of the washer dryer should be 5-40°C. If used under • Before washing, please make sure the washer dryer is installed properly. •... - Page 12 Quick Start Quick Start Quick Start Quick Start Quick Start Caution! Caution! Caution! Caution! Caution! Caution! Caution! Caution! • Before washing, please make sure the washer dryer is installed properly. • Before washing, please make sure the washer dryer is installed properly. •...
- Page 13 * 1 Hour Wash & Dry WASHING/DRYING PROGRAMS A shorter 1 hour cycle for washing and drying a small amount of lightly soiled clothing. Intensive For especially dirty clothes the washing intensity is * Cotton increased for a more thorough wash. Suitable for washing cotton or similar heart-resistant textiles made of cotton and synthetics.
- Page 14 Operating Instructions (Cont.) USING THE ADDITIONAL FUNCTIONS DELAY FUNCTION This function is used for delaying the start of the drying program up to 24 hours. When the delayed program starts, the time starts to countdown on the display and the delay icon blinks. Load your laundry and make sure the machine door is closed.
- Page 15 USING THE ADDITIONAL FUNCTIONS (CONT.) CHILD LOCK This machine incorporates a special child safety lock, which can prevent children from carelessly pressing buttons and doing damage to themselves or the appliance. • Press the Temp and Dry button at the same time for 3 seconds to activate the child lock. CAUTION! When the Child Lock is activated, the display will alternately show “CL”...
- Page 16 Operating Instructions (Cont.) WASHING/DRYING PROGRAMS TABLE DEFAULT TEMP. DEFAULT SPIN ADDITIONAL PROGRAM LOAD (KG) DISPLAY TIME (°C) SPEED (RPM) FUNCTIONS Intensive 3:48 Delay Sportswear 0:45 Delay Quick 15' 0:15 Cold Delay Jeans 1:32 Delay Delicate 0:49 Delay 20˚C 1:01 1000 Delay Cotton ECO 0:59...
-
Page 17: Cleaning & Maintenance
Cleaning & Maintenance CLEANING AND CARE WARNING! Always unplug the appliance and close the water tap before cleaning and maintenance. CLEANING THE CABINET Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary. - Page 18 Cleaning the Drain Pump Filter Warning! • Make sure that the machine has finished the washing cycle and is empty. Switch it off Cleaning & Maintenance (Cont.) and unplug it before cleaning the drain pump filter. • Be careful of hot water. Allow the water to cool down. Risk of scalding! •...
-
Page 19: Technical Specifications
Technical Specifications Below outlines the technical specifications for your InAlto Combo Washer Dryer. IFLW7D40 Model Size 595W � 565D � 850H (mm) 74kg Net Weight 2050W Rated Power 1350W Drying Power 7.0kg Washing Capacity 4.0kg Drying Capacity 50Hz Rated Frequency... -
Page 20: Troubleshooting
Troubleshooting OPERATION IN CASE OF EMERGENCY In the event of an emergency you should: • Switch off all controls. • Switch the appliance off at the power point or at the fuse box. • Call the Residentia Support Team on 1300 11 HELP (4357). Some minor faults can be fixed by referring to the instructions given in the Troubleshooting section below. - Page 21 CUSTOMER SERVICE Spare part for your appliance are available for a minimum of 10 years. In case of questions please contact the Residentia Group Support Team on 1300 11 HELP (4357) WARNING! Risk of electric shock • Never try repair an appliance which is defective of presumed to be defective. You may put your own and future users' lives in danger.
-
Page 22: Purchase Details
Purchase Details For future reference, please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. STORE DETAIL S STORE NAME ADDRESS TELEPHONE PURCHASE DATE PRODUCT DETAIL S MODEL NO. - Page 23 Attach your receipt to this page...
-
Page 24: Warranty Information
Warranty Information AUSTRALIAN WARRANTY TERMS & CONDITIONS (h) ‘you’ means the purchaser of the Appliance not LAUNDRY APPLIANCES having purchased the Appliance for re-sale, and ‘your’ has a corresponding meaning. This document sets out the terms and conditions of the This warranty only applies to Appliances purchased product warranties for Residentia Group Appliances. - Page 25 (a) the Appliance is damaged by: if the Appliance fails to be of acceptable quality accident and the failure does not amount to a major failure. (ii) misuse or abuse, including failure to properly The benefits to you given by this warranty are in maintain or service addition to your other rights and remedies under (iii)
- Page 26 Simply visit the below website, or ask your retailer 24 months on the microwave magnetron; Waste for help: www.inalto.house/nz/registration disposers have a 12 month warranty. The provision of service under this warranty is...
- Page 27 THIS PAGE IS INTENTIONALLY LEFT BL ANK...
- Page 28 D E S I G N E D I N M E L B O U R N E F O R A L L A U S T R A L I A N H O M E S —...
