- Page 1 U S E R M A N U A L I N A L T O . H O U S E 8kg/5kg Combo Washer Dryer MODEL CODE/S I F L 8 0 D 5 0 W F O R A L L A U S T R A L I A N H O M E S V 1 .
-
Page 2: Welcome
Again, thank you for choosing an InAlto appliance and we look forward to being of service to you. Scan to Register your InAlto Appliance or go to: →... -
Page 3: Table Of Contents
24 Warranty Information Customer Care InAlto recommends the use of original spare parts. When contacting our customer service team on 1300 11 4357, please ensure that you have the following information at hand (which can be found on your appliances’ rating plate). -
Page 4: Safety Instructions
Safety Information Intended Use Important Safety Instructions • The product is intended only for domestic home use and • Please read the following safety information thoroughly for textiles in household amounts suitable for washing. and follow it strictly to minimize the risk of fire or explosion, electric shock and to prevent property damage, •... - Page 5 Installation Location and Surrounding Electrical Connection • All washing and additional substances are to be kept • Make sure the supply cable is not trapped by the in a safe place out of the reach of children. machine, or it can get damaged. •...
- Page 6 Safety Information (Cont.) Operation and Maintenance Transport • Before Transport: • WARNING: Never stop the machine before the end of the drying cycle unless all items are quickly removed and • Bolts shall be reinstalled to the machine spread out so that the heat can dissipate. by a specialised person;...
-
Page 7: Your Combi Washer Dryer
F. Drain Hose G. Power Supply Cord Product Specifications Parts and Accessories Your Combi Washer Dryer comes Model IFL80D50W with the following accessories: Washing Capacity 8.0 kg • 4 × Cover caps (for transport bolt holes) Drying Capacity 5.0 kg •... -
Page 8: Installation Instructions
Installation Instructions Prior to Installing the Combi Washer Dryer Unpacking the Appliance IMPORTANT: If the power cord is damaged, it must be WARNING: Risk of suffocation replaced by Residentia Group or one of it’s authorised Packaging material (e.g. Films, Styrofoam) can be service representatives. - Page 9 Removing the Transport Bolts Connect the Water Supply Hose WARNING: You must remove the transport bolts from the • WARNING: To prevent leakage or water damage, follow backside before using the product. the instructions in this chapter. • WARNING: Do not kink, crush or modify water inlet hose.
-
Page 10: Quick Start Guide
Quick Start Guide Prior to Operating the Combi Washer Dryer Operating your Combi Washer Dryer • CAUTION: Before washing, please make sure the 1. Power on 2. Select program machine is installed properly. • CAUTION: Clean your appliance before first use. Your appliance was thoroughly checked before it left the factory. -
Page 11: Operating Instructions
Operating Instructions Before Each Washing Cycle The Detergent Dispenser • The ambient temperature of the machine should be Prewash 5°C-40°C. If used under 0°C, the inlet valve and draining system may be damaged. If the machine is installed Main Wash under freezing conditions, it should be transferred to normal ambient temperature to ensure the water supply Softener... - Page 12 Operating Instructions (Cont.) Control Panel A. Program selection dial C. Power button E. Start/Pause button B. LED Display: Showing settings, D. Extra Options: Press these buttons to estimated remaining time, options change the program parameters and status messages. or select additional functions. LED Display A.
- Page 13 Program Functions Personalised Quick 15' / 1h WD To save your most frequently used program and settings. This procedure defaults to Quick 15' , press the “Dry” to After selecting the settings and any additional options, switch to 1h WD. press the Spin Speed and Stain Target buttons for Quick 15' is suitable for washing few and not very dirty 3 seconds before beginning the cycle.
- Page 14 Operating Instructions (Cont.) Extra Options Pre Wash Dry Level Extra washing function before the main washing cycle Press the Dry button continuously to choose the dry level: starts to increase the washing performance. Standard Dry → Extra Dry → Light Dry → Time Dry. NOTE: Detergent needs to be added to the compartment I.
- Page 15 Washing Temperature Child Lock When required, the washing temperature can be adjusted Use this function to avoid any misuse of the controls. by pressing the temperature button in the following steps: To activate, press the Extra Option & Speed Wash buttons Cold →...
- Page 16 Operating Instructions (Cont.) Washing Program Table Default Default Wash/Dry Temp. Main Fabric Additional Program Speed Time Load (kg) (°C) Wash Wash Softener Functions (RPM) (h:min) Quick 15'/1h WD 2.0/1.0 — 800 / 1400 0:15 / 0:58 — Required Optional Steam Shield 4.0/2.5 1000 2:28...
- Page 17 Testing Methods Model: IFL80D50W ADDITIONAL INFORMATION FOR Standard performance TESTING: (AS/NZS 2040.1:2005+Amdt1-2007+Amdt2-2009) 1. Water connections: Cold & hot water connection 2. Water supply pressure: 320 kPa 3. Energy Wash Program: Cotton ECO, 1400rpm,60°C, Display: 6:32 Energy Dry program: Auto Dry, 1400rpm, D-3, Display: 4:39 4.
-
Page 18: Cleaning & Maintenance
Cleaning & Maintenance Cleaning & Care Cleaning the Inlet Filter WARNING: Always unplug the appliance and close the NOTE: Diminishing water flow is a sign that the filter needs water tap before cleaning and maintenance. to be cleaned. 1. Close the tap and remove 2. - Page 19 Cleaning the Detergent Dispenser Cleaning the Drain Pump Filter (Removing foreign objects) 1. Press down the release on the softener cover and pull the dispenser drawer out of the recess. Clean the inside of WARNING: the recess with a brush. •...
-
Page 20: Troubleshooting
Troubleshooting Whenever there is a problem with the appliance, check if you can solve it following the tables below. If the problem persists, please contact After Sales Support. Description Possible Cause Solution Appliance does not start Door may not be closed properly. Close the door properly and restart. - Page 21 Operation in case of emergency In the event of an emergency you should: • Switch off all Combi Washer Dryer controls. • Switch the Combi Washer Dryer off at the power outlet and immediately unplug. • Call the Customer Service team on 1300 11 4357 or email support@residentiagroup.com.au Some minor faults can be fixed by referring to the instructions given in this Troubleshooting section.
- Page 22 Attach your receipt to this page...
-
Page 23: Purchase Details
Purchase Details For future reference, please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. STORE DETAIL S STORE NAME ADDRESS TELEPHONE PURCHASE DATE PRODUCT DETAIL S MODEL NO. -
Page 24: Warranty Information
Warranty Information AUSTRALIAN WARRANTY TERMS & CONDITIONS (h) ‘you’ means the purchaser of the Appliance not LAUNDRY APPLIANCES having purchased the Appliance for re-sale, and ‘your’ has a corresponding meaning. This document sets out the terms and conditions of the This warranty only applies to Appliances purchased product warranties for Residentia Group Appliances. - Page 25 (a) the Appliance is damaged by: the failure does not amount to a major failure. The accident benefits to you given by this warranty are in addition (ii) misuse or abuse, including failure to properly to your other rights and remedies under a law in maintain or service relation to the Appliances or services to which the (iii)
- Page 26 24 months on the microwave magnetron; Waste Simply visit the below website, or ask your retailer disposers have a 12 month warranty. for help: www.inalto.house/nz/registration The provision of service under this warranty is limited by a 25km boundary from the retailer...
- Page 27 THIS PAGE IS INTENTIONALLY LEFT BL ANK...
- Page 28 D E S I G N E D I N M E L B O U R N E F O R A L L A U S T R A L I A N H O M E S —...
