Thank you for selecting our product to protect your electrical equipment.
The Modbus adaptor has been designed with the utmost care. We recommend that you take the time to read this
manual to take full advantage of the many features of your new equipment.
Environment
Our staff pays great attention to the environmental impact of its products during the design and manufacture
stages, through to the end of its life cycle.
 This product complies with the most strict regulations.
 It does not contain CFCs or HCFCs
Recycling of packing materials
Packing materials were selected to facilitate recycling. Please make sure they are correctly recycled in
compliance with all applicable regulations.
Special precautions
 If the adaptor must be stored prior to installation, storage must be in a dry place
 The admissible storage temperature range is -10 C to +70 C.
1. Introduction ..................................................................................................... 1
1.1 Unpacking and Checking Contents ........................................................... 1
1.2 Overview .................................................................................................. 1
1.3 Functions .................................................................................................. 1
1.4 Technical Specifications ........................................................................... 1
2. Installation ....................................................................................................... 2
2.1 Configuration Of The Modbus Communication Parameters ...................... 2
2.2 RS232 Connection to UPS ....................................................................... 3
2.3 MDX-NET Network Connection ................................................................ 3
2.4 Installation ................................................................................................ 4
2.5 MDX-NET Configuration using Device Installer...................................4
3. Operation ........................................................................................................ 8
4. Indicator Lamb....................................................................................8
 TX300 Protocol HOLDING REGISTER Table (3 Phase UPS) ......................... 9
 TX301 Protocol HOLDING REGISTER Table (3 Phase UPS) ......................... 11
 TX100 Protocol HOLDING REGISTER Table (3 Phase UPS) ......................... 15
 STS Protocol HOLDING REGISTER Table (Static transfer switch)................17
CONTENTS
