- Page 1 Instructions For Use Gebrauchsanweisung V 1.0 HS720G +1(855) 888-6699 www.holystone.com usa@holystone.com (USA) eu@holystone.com (EU) ca@holystone.com (CA)
- Page 2 English 01-47 Deutsch 48-90...
-
Page 3: Table Of Contents
Contents 1.0 Disclaimer & Warning................2.0 Safety Guidelines..................3.0 Maintenance....................4.0 Package Contents..................5.0 Drone Details....................6.0 Transmitter Details 6.1 Transmitter Functions............... 6.2 LCD Screen Functions............... 6.3 Low Battery Warning................ 6.4 Mode Switch..................7.0 Installation 7.1 Drone Battery..................7.2 Propellers....................7.3 Gimbal Cover.................. - Page 4 10.0 Functions Details 10.1 Camera Angle Adjustment............10.2 Return to Home................. 10.3 Optical Flow Positioning..............11.0 APP Operation Instruction 11.1 Operation Interface................11.2 Beginner Mode................... 11.3 Follow Me..................... 11.4 Point of Interest.................. 11.5 Headless Mode................... 11.6 TapFly....................11.7 Take Photo/Record Video............... 12.0 Drone Status Indicator................
-
Page 5: Disclaimer & Warning
1.0 DISCLAIMER & WARNING 1. Please read this Disclaimer & Warning and Safety Guidelines carefully before using our product. This product is not recommended for people under the age of 16. By using this product, you hereby agree to this disclaimer and signify that you have read it fully. - Page 6 ④ Please perform a thorough check of the product before each use. Inspect the integrity of the parts, any signs of cracks and wear off on the propellers, battery power and effectiveness of the indicator, etc. If there is any problem found after checking the drone, please refrain from using it until the problem is resolved.
- Page 7 2.3 Operation Requirements ① DO NOT use this product to follow any moving vehicles. ② During the flight, turn off the motors only in case of an emergency. ③ When the battery runs low, return the drone back to your starting point. ④...
- Page 8 ⑥ If the device is not going to be used for an extended period of time, please remove batteries to prevent potential damage to the drone from battery leakage. ⑦ Only use the USB charging cable that comes with the drone to charge the battery.
-
Page 9: Maintenance
3.0 MAINTENANCE ① Clean the drone after each use with a clean, soft cloth. ② Avoid prolonged exposure to direct sunlight and avoid buildup of heat on the drone or batteries. ③ This device is not waterproof and must not be submerged or subjected to water under any circumstance. -
Page 10: Package Contents
4.0 PACKAGE CONTENTS ×1 ×1 ×1 Drone Transmitter Drone Battery ×4 ×1 ×1 USB Charging Spare Propellers Screwdriver Cable Instructions For Use Gebrauchsanweisung V 1.0 HS720G www.holystone.com +1(855) 888-6699 usa@holystone.com (USA) eu@holystone.com (EU) ×1 ca@holystone.com (CA) Instructions For Use -06-... -
Page 11: Drone Details
5.0 DRONE DETAILS Propeller A Propeller B Propeller B Propeller A HD Camera - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Vision Positioning Lens Drone Battery - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -... -
Page 12: Transmitter Details
6.0 TRANSMITTER DETAILS 6.1 Transmitter Functions Phone Holder One Key Takeoff/ Landing Return to Home Left Joystick Right Joystick Power Switch Unlocking/Locking LCD Screen Folded Handle - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Camera Angle Adjustment Short-press: Take Photos... - Page 13 •GPS Mode Switch After turning on the transmitter, the GPS Mode is default on. GPS Mode can be turn off by sliding GPS switch. Check the icon “ ” or “ ”on the LCD screen to confirm GPS status. •Return to Home (RTH) Short press the button to start the RTH, the transmitter makes a beep sound and the drone will fly back to the recorded Home Point.
-
Page 14: Lcd Screen Functions
6.2 LCD Screen Functions Return to Home (RTH) Signal Strength Drone Transmitter Battery Level Battery Level Photo/Video Distance from High/Low Home Point Speed Mode Altitude from Transmitter Home Point Throttle Mode GPS Mode Satellite Count - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6.3 Low Battery Warning Pic. -
Page 15: Mode Switch
6.4 Mode Switch 6.4.1 MODE 2 (Left hand throttle MODE 2 will be default setting.) Left Joystick Right Joystick Forward Ascend Down Descend Backward Down Left Right Left Right Fly to Fly to Rotate Left Rotate Right Left Right - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6.4.2 MODE 1 ①... -
Page 16: Installation
7.0 INSTALLATION 7.1 Drone Battery Installation: Push the battery into the battery compartment at the rear of the drone. Make sure that you hear a click sound indicating the battery is firmly installed. Attention: ・Before installing the battery, please remove the insulation gasket from the battery. -
Page 17: Propellers
7.2 Propellers HEAD Installation: The drone will not fly unless the correct propeller is installed on the correct motor shaft. See illustration above. An “A” “B” printed on the back of each propeller. Lock the propeller to the motor shafts with screws. -
Page 18: Gimbal Cover
7.3 Gimbal Cover As shown above, turn the bottom of the drone upwards, press on the gimbal cover to unlock the buckle while pushing it back, and then take it off gently. ・Please remove the gimbal cover gently before flying. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7.4 Arms All arms of the drone are folded before the drone is packaged at the factory. -
Page 19: Tf Card
7.5 TF Card To store your photos and videos, insert the TF card (not included) into the slot as shown above before turning on the drone. The drone supports TF card up to 128 GB. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7.6 Antenna There is a buckle on the antenna, please follow the steps shown above to open the antenna. -
Page 20: Transmitter Battery
7.7 Transmitter Battery ② ① (Not included) ③ Step 1: Unfold the folded handle and open the battery cover. Step 2: Install 2*AA batteries into the battery compartment according to the given polarity. Step 3: Close the battery compartment . ・Insert batteries with correct polarity. -
Page 21: Phone Holder
7.8 Phone Holder 1. Pull out the mobile phone holder upwards completely (Pic. 3). Pic. 3 2. Tilt the holder 30 degrees towards you and then you will hear a click sound (Pic. 4). Pic. 4 3. Rotate and fix the support board in place (Pic. -
Page 22: Charging
8.0 CHARGING USB Adapter (5V/2.0A) Power Bank ① Connect the Battery to the USB Charging Cable. ② Connect the USB Charging Cable with Power Bank or a USB Adapter (5V/2.0A ) for charging. ③ When the battery is charging, the indicator lights on the battery will flash green. -
Page 23: Operation Guide
9.0 OPERATION GUIDE 9.1 Download APP Android APP on Google play Scan the QR code, corresponding to either App Store™ or Google Play™ Store and download the Ophelia FLY app for free. Required Operating Systems: iOS 9.0 or later/Android 5.0 or later. 9.2 Connect to Wi-Fi HolyStoneGIM-****** Connect your phone to the drone. -
Page 24: Pairing
All of the operations shown in this manual are demonstrated using MODE 2. · Pre-Flight Checklist 1. Make sure the transmitter, mobile device, and the drone battery are fully charged. 2. Make sure the drone battery and the propellers are mounted securely. 3. -
Page 25: Initialization Detection
9.4 Initialization Detection First use HEAD Non-first use Place the drone on the level surface and it will enter the Initialization Detection. The yellow, green and red light of the drone will alternate flickering for about 25 seconds to complete the initial detection. When the transmitter sends out “Di Di”, the drone can be divided into two states: ・First use: The indicator light turns yellow and blinks. - Page 26 When the “ ” icon appears on the LCD screen in the state of slow flashing and the yellow light will flash, it indicates that the drone can start compass calibration. Step 2: Hold the drone horizontally and rotate the drone in 3 complete circles.
-
Page 27: Unlocking/Locking
9.6 Unlocking/Locking 9.6.1 Unlocking the Motor Please unlock the motor before take-off. Short press the red button “ ”. The motors rotate and the drone is unlocked. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9.6.2 Locking the Motor Pic. -
Page 28: One Key Takeoff/Landing
9.7 One Key Takeoff/Landing ① ② Landing Take-off ① After unlocking the drone, short press the “ ” button, the drone will automatically take off and hover at 5 feet altitude. ② When the drone is flying, short press the “ ”... -
Page 29: Functions Details
10.0 FUNCTION DETAILS 10.1 Camera Angle Adjustment 90° The gimbal provides a steady platform for the attached camera, allowing you to capture clear, stable images and video. The gimbal can tilt the camera within a 90° range. You can dial the wheel left/right to tilt the camera up/down. -
Page 30: Return To Home
10.2 Return to Home (RTH) ・The Return to Home function brings the drone back to the last record- ed Home Point. ・The Home Point is the location at which the drone takes off or the GPS receives a signal from 7 or more satellites for the first time during the flight. The current position of the drone will be recorded as the Home Point. - Page 31 10.2.3 Low Voltage RTH ① When the drone's red indicator light flashes slowly, the “ ” symbol is displayed on the screen of the transmitter, the First Low Voltage RTH will be triggered. And the drone will return automatically in the following two conditions: (At this time, the drone can only fly within a safe range of the height no more than 98 feet and the distance no more than 328 feet .)
- Page 32 ② If the drone’s red indicator light begins to flash rapidly the “ “ symbol will be displayed on the transmitter screen and the transmitter will emit a “Di..., Di...” alert. The Second Low Voltage RTH is automatically triggered. a. When the flight altitude is higher than or equal to 49 feet, the drone will stay in the current altitude and return above the Home Point then descend vertically.
-
Page 33: Optical Flow Positioning
10.3 Optical Flow Positioning ① The Optical Flow Positioning System consists of a camera ① module, which acquires the position information of the drone through visual images to ensure precise positioning of the drone. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - The Optical Flow Positioning System is typically used in an indoor environ- ment when GPS is weak or unavailable. - Page 34 1. Fly fast at an altitude below 0.5m. 2. Fly over monochrome surfaces (like pure black, pure red, pure red and pure green). 3. Fly over strong light reflective surfaces or surfaces prone to reflection. 4. Fly over water or transparent object surfaces. 5.
-
Page 35: App Operation Instruction
11.0 APP OPERATION INSTRUCTION 11.1 Operation Interface Record Video Homepage General Settings Camera Follow Me GPS Signal Parameters Point of Interest Drone TapFly Battery Level Headless Mode Transmitter Delete Battery Level RTH Switch Transmitter Submit Signal Strength One Key Takeoff/ Wi-Fi Signal Landing Zoom in... -
Page 36: Beginner Mode
11.2 Beginner Mode The Default GPS Mode is Beginner Mode, under Beginner Mode: 1. The default Orbit semi-diameter is 5 m/16 feet. 2. Flight Distance is limited between 0~15 m/0~49 feet. 3. Flight Height is limited between 0~15 m/0~49 feet. 4. -
Page 37: Follow Me
11.3 Follow Me When the Follow Me function is enabled, the drone will follow the GPS in your phone to follow you wherever you go. 1. Ensure the drone's flight range is within 16~98 feet. 2. Click the “ ” icon first, then select the “ ”... -
Page 38: Point Of Interest
11.4 Point of Interest 1. Click the “ ” icon first, then select the “ ” icon, and follow the prompt box to enter the Point of Interest function. 2. The drone will record its flight position the moment you enter this function as the point of interest. -
Page 39: Headless Mode
11.5 Headless Mode ① Click the “ ” icon first, then select the “ ” icon, and follow the prompt box to enter the Headless Mode. ② Exit the Headless Mode by clicking the “ ” icon again. HEAD TAIL TAIL HEAD Please make the pilot stays facing the same direction... -
Page 40: Tapfly
11.6 TapFly It is recommended to enlarge the map if you want to use TapFly. 1. Please click on the Map first, then click the “ ” icon, and follow the prompt box to enter the TapFly function. MODE 1: Click the “ ”... -
Page 41: Take Photo/Record Video
11.7 Take Photo/Record Video 1. Click the “ ” icon to switch between photo and video recording modes. 2. Click the “ ” icon to take a photo, click once to take a photo. 3. Click the “ ” icon to record the video, click once to start recording, and click again to stop recording. -
Page 42: Drone Status Indicator
12.0 DRONE STATUS INDICATOR Indicator Status Indicator Status Meanings The drone is not connected to the The indicator light flashes yellow rapidly. transmitter. The indicator light turns solid yellow. No GPS signal or weak GPS signal. The indicator light turns solid green. Good GPS signal. -
Page 43: Specifications
13.0 SPECIFICATIONS DRONE Model: HS720G Weight: 377g/13.30oz Max Flight Time: 26minutes (per battery) Operating Temperature Range: 32° to 104°F Size: 164 x 90 x 63 mm (Folded) 305 x 230 x 63 mm (Unfolded) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -... - Page 44 CAMERA Operating Frequency: 5GHz Max Photo Resolution: 3840×2160P Max Video Resolution: 3840×2160P@30fps Lens Angle: FOV 120° Max Transmission Distance: 1640feet/500m (outdoor and unobstructed) Photo Formats: JPEG Video Formats: AVI/MP4 Supported TF Cards: Supports a TF Card with a capacity of up to 128 GB (Not included) Controllable Range: Pitch: -90°...
-
Page 45: Trouble Shooting
14.0 TROUBLE SHOOTING Problem Solution 1. Recharge the battery. The propellers spin, but 2. Install the propellers in right the drone cannot take-off. orientation. 3. Replace the propellers. The propeller is damaged. Please The drone vibrated in flight. replace it with the new propeller. The drone could not be unlocked The drone battery voltage is too and the rear light flashed. -
Page 46: General Information
16.0 GENERAL INFORMATION FCC Statement: Any Changes or modifications not expressly approved by the party respon- sible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interfer-... - Page 47 WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. RF Exposure The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with minimum distance 20cm between the radiator &...
- Page 48 2) I'utillsateur de I'appareil doit accepterbrouillage radioélectrique subi meme si le brouillage est susceptible d'encompromettre le fonctionnement. mauvais fonctionnement de I'appareil. Cet appareil numériquie de la classe B est conforme à la norme NMB-003 du Canada. CAN NMB-3 (B) RF Exposure Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.
- Page 49 BATTERY WARNING: 1. Failure to follow all the instructions may result in serious injury, irreparable damage to the battery and may cause a fire, smoke or explosion. 2. Always check the battery’s condition before charging or using it. 3. Replace the battery if it has been dropped, or in case of odor, overheat- ing, discoloration, deformation or leakage.
- Page 50 We, Xiamen Huoshiquan Import & Export CO., LTD hereby, declare that the essential requirements compliance with the Directive 2014/53/EU, the RoHS Directive 2011/65/EU and Safety Directive 2009/48/EC have been fully fulfilled on our product with indication below: Product Name: REMOTE CONTROL MODEL/RADIO CONTROLLED Model/Mark: HS720G/HOLYSTONE -46-...
- Page 51 The Statement of compliance is available at the following address: http://www.holystone.com/Download/CE/HS720G_EU_DOC.pdf This product can be used across EU member states. MANUFACTURER INFORMATION Manufactured by Xiamen Huoshiquan Import & Export CO.,LTD Address: Unit. 33, Room 806, NO. 2 Huming Road, Siming District, Xiamen, China +1(855) 888-6699 FAA REGISTRATION: PLEASE FOLLOW ALL FEDERAL,...
