WARNING!!
Children have died from furniture tipover. Tip restraints have
been included with this product; you must install the tip
restraints according to these instructions in order to
minimize the risk of furniture tipping. If you have any
questions about this product or the tip restraint, please send
us an email at tip_restraint_help@Noblehousefurniture.com
NEVER allow children to climb or hang on furniture, including
drawers or cabinet doors.
In addition to installing the restrains, to help prevent tip-over
1. For use with televisions weighing 20 lbs or fewer. Use with
heavier televisions may result in instability causing tip-over
resulting in death or serius injury. NEVER use with CRT
televisions
2. Do not stand on the product
Page 1 OF 19
Noble house Home Furnishings LLC
Advertisement
Related Manuals for Noble House Home Furnishings TV CABINET
Summary of Contents for Noble House Home Furnishings TV CABINET
- Page 1 1. For use with televisions weighing 20 lbs or fewer. Use with heavier televisions may result in instability causing tip-over resulting in death or serius injury. NEVER use with CRT televisions 2. Do not stand on the product Page 1 OF 19 Noble house Home Furnishings LLC...
- Page 2 Caution : You must read this before you proceed TV CABINET Label Picture Description Drawer Left Side Rail Drawer Right Side Rail Drawer Left Bottom Rail Drawer Right Bottom Rail Page 2 OF 19 Noble house Home Furnishings LLC...
- Page 3 Top Panel Side Panel Left Side Panel Right Center Panel Left Center Panel Right Shelf Panel Middle Panel Right Back Panel Bottom Panel Page 3 OF 19 Noble house Home Furnishings LLC...
- Page 4 Drawer Front Drawer Side Drawer Back Drawer Bottom Handle Leg Support Leg (with pre-fixed PVC Foot) Page 4 OF 19 Noble house Home Furnishings LLC...
- Page 5 Nail ⑧ Screw (M4*45mm) ⑨ Screw (M4*38mm) ⑩ Screw (M3.5*16mm) ⑪ Metal Shelf Support Screwdriver (not ⑫ provided) Hammer (not ⑬ provided) Power Drill (not ⑭ provided) Cabinet Restraint Device Hardware Page 5 OF 19 Noble house Home Furnishings LLC...
- Page 6 Metal Bracket ⑯ Wall Plug ⑰ Wall Plug Screw ⑱ Pan Head Screw Cabinet Restraint ⑲ Strap Before X 13 X 13 X 13 Beginning X 21 Assembly: X 31 X 33 Page 6 OF 19 Noble house Home Furnishings LLC...
- Page 7 Leg (R) FRONT FACING This TV Cabinet has multiple parts and may require up to 60 minutes to assemble. To give you an overview of the TV Cabinet parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 8 Screws(⑩) with Screwdriver(⑫) where indicated. Note: There are pre-existing mounting positions on the Side Panel Right(E) to attach the Drawer Right Side Rail(AR). Tighten the Screws fully in a sequential manner. Page 8 OF 19 Noble house Home Furnishings LLC...
- Page 9 Screws(⑩) with Screwdriver(⑫) where indicated. Note: There are pre-existing mounting positions on the Center Panel Right(G) to attach the Drawer Left Side Rail(AL). Tighten the Screws fully in a sequential manner. Page 9 OF 19 Noble house Home Furnishings LLC...
- Page 10 Insert the Cam Bolt(②) on Side Panel Right(E) and Center Panel Right(G) into mounting position on side of Middle Panel Right(I). Turn the Cam Lock(①) clockwise with the Screwdriver(⑫) until it locks into place. Page 10 OF 19 Noble house Home Furnishings LLC...
- Page 11 Right(E) and Center Panel Left(F), Center Panel Right(G) into mounting positions on Bottom Panel(K). 9.2) Attach Bottom Panel(K) to Side Panel Left(D), Side Panel Right(E), Center Panel Left(F), Center Panel Right(G) using Cap Wood Screws(⑤) with Allen Key(⑥). Page 11 OF 19 Noble house Home Furnishings LLC...
- Page 12 ⑦ ⑦ ⑦ ⑦ Attach Back Panel(J) to TV Cabinet Assembly using Nails(⑦) with Hammer(⑬). Please be extra careful when using Hammer to avoid injury. Note: Hit Nails along all four edges (slightly inwards from sides) on the lines drawn on the Back Panel.
- Page 13 Attach Legs(R) to Leg Supports(Q) by rotating Legs clockwise by hand. Step 13 NOTE ⑪ Put Shelf Panels(H) into place on Shelf Supports(⑪). Note: There are lead mounting positions on Shelf Panels to fit Metal Shelf Supports. Page 13 OF 19 Noble house Home Furnishings LLC...
- Page 14 16.1) Attach Drawer Right Bottom Rail(BR) to Drawer Bottom Panel(O) using Screws(⑦) with Screwdriver(⑫) where indicated. 16.2) Repeat the same process on the Drawer Left Bottom Rail(BL). Tighten the Screws fully in a sequential manner. Page 14 OF 19 Noble house Home Furnishings LLC...
- Page 15 Attach Handle(P) to Drawer Front Panel(L) using Screws(⑧) with Screwdriver(⑫). Tighten the Screws fully in a sequential manner. Step 18 AL/AR BL/BR Put Drawer Assembly in place by aligning the rails. Page 15 OF 19 Noble house Home Furnishings LLC...
- Page 16 19.2 ⑮ ⑮ ⑮ ⑱ ⑫ 19.1) Turn the TV Cabinet so the back side faces you. 19.2) Attach Metal Brackets(⑮) to Back Panel(H),where Labeled using Pan Head Screws(⑱) with Screwdriver(⑫). Page 16 OF 19 Noble house Home Furnishings LLC...
- Page 17 TV Cabinet with Power Drill(⑭). You can mark these points in two ways as below: 1) Move the TV Cabinet back to the wall. Mark two points same height as TV Cabinet on the wall. Note: The Metal Brackets need to be secured to solid, load bearing surface.
- Page 18 ⑲ ⑮ Move TV Cabinet to the wall. Pull the Restraint Straps(⑲) through the Metal Brackets(⑮) on the wall and TV Cabinet one by one, and pull the Restraint Straps(⑲) tight. Step 23 Your TV Cabinet is ready for use.
- Page 19 Page 19 OF 19 Noble house Home Furnishings LLC...
