- Page 1 Assembly Instructions Caution: You must read this before you proceed Chaise Lounge Noble House Home Furnishings LLC Page 1 OF 11...
-
Page 2: Part List
Part List Label Picture Description Backrest Left Armrest Right Armrest Seat Seat Cushion Noble House Home Furnishings LLC Page 2 OF 11... -
Page 3: Assembly Preparation
Hardware Label Picture Description ① Bolt (M8*70 MM) ② Washer ③ Gasket ④ Allen Key ⑤ Spring Washer Assembly Preparation Before Beginning Assembly: Noble House Home Furnishings LLC Page 3 OF 11... -
Page 4: Assembly Steps
Leg (F) FRONT FACING This Chaise Lounge has multiple parts and may require up to 60 minutes to assemble. To give you an overview of the Chaise Lounge parts, the above picture is to help you put the various parts into perspective. - Page 5 During this assembly process you may need to use your hand to press down and or pave away the padded surface to facilitate the 'slip and slide' assembly. Exercise Caution to ensure that your fingers do not get caught or pinched in the assembly process. Noble House Home Furnishings LLC Page 5 OF 11...
- Page 6 Push the Seat(D) downwards until it is fully slotted and locked into position in the Armrests. Fully locked postion: Check and assess that the base of the Armrests(B&C) and Seat(D) are aligned and level. Assistance from an adult partner is needed for this assembly process. Noble House Home Furnishings LLC Page 6 OF 11...
- Page 7 Left Armrest(B) and Right Armrest(C). Fully locked postion: Check and assess that the base of the Armrests(B&C) and Seat(D) are aligned and level. Assistance from an adult partner is needed for this assembly process. Noble House Home Furnishings LLC Page 7 OF 11...
- Page 8 Right Armrest (C) Seat (D Left Armrest (B) Tilt and lay the Chaise Lounge on its Backrest(A) onto a flat surface. Attach Seat(D) to Left Armrest(B) and Right Armrest(C) using Bolts(①), Spring Washers(⑤), and Washers(②) with Allen Key(④). Then attach Seat(D) to Backrest(A) using Bolts(①), Spring Washers(⑤), and Washers(②) with Allen Key(④) as pictured above.
- Page 9 Right Armrest (C) Install the Leg(F) at the bottom of the Chaise by placing one Gasket(③) on the threaded stem. Then insert threaded stem into the threaded mounting postion at the corner of the Chaise Lounge. Tighten by turning the Leg clockwise.
- Page 10 Step 6 Seat Cushion (E) Place the Seat Cushion(E) onto the Chaise Lounge. Your Chaise Lounge is ready for use. This Chaise Lounge can only be used on a flat, level surface. Noble House Home Furnishings LLC Page 10 OF 11...
- Page 11 Noble House Home Furnishings LLC Page 11 OF 11...
