Noble House Home Furnishings CHT1733 Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
TABLE
CAUTION: You must read this before you proceed.
Pleas look in the Leg for hardware packs
CAUTION: This Table is NOT a TOY.
Keep your child/children at bay during the assembly process.
Whenever lifting the Table and to prevent damage to the Table two adults are
needed to execute this action.
1 OF 11

Advertisement

loading
Need help?

Need help?

Do you have a question about the CHT1733 and is the answer not in the manual?

Questions and answers

Related Manuals for Noble House Home Furnishings CHT1733

Summary of Contents for Noble House Home Furnishings CHT1733

  • Page 1 TABLE CAUTION: You must read this before you proceed. Pleas look in the Leg for hardware packs CAUTION: This Table is NOT a TOY. Keep your child/children at bay during the assembly process. Whenever lifting the Table and to prevent damage to the Table two adults are needed to execute this action.
  • Page 2 Picture Description Side Table Top Middle Table Top First Support Bar Second Support First Leg Second Leg Connector Bar Support Leg 2 OF 11...
  • Page 3 Bolt (M6 x 15mm) Bolt (M6 x 32mm) Screw (M6 x 30mm) Screw (M7 x 60mm) Flat Washer (M6/16 x 2mm) Cap Nut (M6/10mm) Allen Wrench Wrench 3 OF 11...
  • Page 4 Assembly Preparation Before Beginning Assembly: x 53 x 17 x 21 x 13 Read instructions, cover to cover. Have 2 adults on hand for assembly. Do not assemble on flooring or carpet. Assemble on a clean non-marring surface (packing foam). Save all packaging until finished.
  • Page 5 Assembly Steps OVERVIEW Second Support Bar (E) Side Table Top (A) Middle Table Top (B) Bar (C) Connector Bar (H) First Support Bar (D) First Leg (F) Support Leg (I) Support Leg (I) Second Leg (G) FRONT FACING This Table has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Table parts, the above picture is to help you put the various parts into perspective.
  • Page 6 Assembly Steps Step 2 Place Bar (C) facing down on a clean, non - marring surface. With the help of your adult partner, position the Middle Table Top (B) to the Bar (C) using Cap Nuts ( 6 ) and Washers ( 5 ) with the Wrench ( 8 ) as shown above. Do not fully tighten the Cap Nut.
  • Page 7 Assembly Steps Step 4 Attach the First Support Bar (D) to the Side Table Top (A) and Middle Table Top (B) using Screws ( 4 ) with the Allen Wrench ( 7 ) as shown above Do not fully tighten the Screws. Step 5 Attach the Second Support Bar (E) to the Side Table Top (A) and Middle Table Top (B) using Bolts ( 2 ) and Washers ( 5 ) with the Allen Wrench ( 7 ) as shown above.
  • Page 8 Assembly Steps Step 6 Attach the First Leg (F) and Second Leg (G) to the Side Table Top (A) (assembly from step 5) using Bolts ( 2 ) and Washers ( 5 ) with the Allen Wrench ( 7 ) as shown above. Do not fully tighten the Bolts.
  • Page 9 Assembly Steps Step 8 Secure the Connector Bar (H) to the Side Table Top (A) and Middle Table Top (B) using Screws ( 3 ) and Washers ( 5 ) with the Allen Wrench ( 7 ) as shown above. Do not fully tighten the Screws.
  • Page 10 Assembly Steps Step 10 Adjust Pre-installed Levellers height for balance With the assistance of your adult partner, stand the Table up. Then EXERT pressure floorwards onto the Table with both hands. This pressure will help the Table reach full alignment at all joints. In a sequential manner, gradually tighten all Bolts and Screws at all joints until evenly secured.
  • Page 11 Prolonged exposure to rain may cause rusting which can stain floors. Do not put hot items directly on furniture surface. Do not clean furniture with harsh cleansers or polish. To obtain the longest lifespan of your outdoor products, minimizing exposure to direct sunlight is recommended. Children should not climb or jump on the furniture.
