dispomed MODUFlex Manual

Veterinary anesthesia machine
Hide thumbs Also See for MODUFlex:
Table of Contents

Advertisement

Quick Links

Download this manual
Printed in Canada

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MODUFlex and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dispomed MODUFlex

Summary of Contents for dispomed MODUFlex

  • Page 1 Printed in Canada...

  • Page 2: Table Of Contents

    Moduflex Optimax . . . . . . . . . . . . . . . . . . .

  • Page 3: User Responsibility

    Dispomed regional service center . • This product, or any of its parts, should not be repaired other than in accordance with written instructions provided by Dispomed and by Dispomed trained personnel . • The product may not be altered without prior written approval from Dispomed .

  • Page 4: Standard Features

    THE MODUFLEX BAIN STANDARD FEATURES Integrated gas evacuation valve with a momentory push feature for a rapid transfer • between spontaneous and controlled ventilation . Integrated gas evacuation exhaust port is built into the mounting bracket, • eliminating the risk of obstruction in the tube .

  • Page 5: Receiving And Assembly Instructions

    RECEIVING AND ASSEMBLY INSTRUCTIONS Your Moduflex Bain requires some assembly before use . RECEIVING In order to reduce the possibility of damage to a minimum during shipping, certain components have been detached from the unit . These components are packed separately within the shipping crate .

  • Page 6: Assembly On

    . Install gas evacuation tube to bottom connection of post mount . On Moduflex Optimax install the Bain circuit Connect fresh gas tube to fresh gas outlet of adaptor as illustrated .

  • Page 7: Wallmount Moduflex Optimax

    . Install gas evacuation tube to bottom connection of post mount . On Wallmount Moduflex Optimax install the Connect fresh gas tube to fresh gas outlet of Bain circuit adaptor as illustrated .

  • Page 8: Moduflex Coaxial And Elite

    . Install gas evacuation tube to bottom connection of post mount . On Moduflex Coaxial and Elite install the Bain Connect fresh gas tube to fresh gas outlet of circuit adaptor as illustrated .

  • Page 9: Moduflex Compact And Compact

    ASSEMBLY ON MODUFLEX COMPACT AND COMPACT + Connect bain tube to front connection of adaptor and breathing bag to bottom connection . Install gas evacuation tube to bottom connection of post mount . On Moduflex Compact and Compact+ install Connect fresh gas tube to fresh gas outlet of the Bain circuit adaptor as illustrated .

  • Page 10: Moduflex Nrb

    . Install gas evacuation tube to bottom connection of post mount . On Moduflex NRB install the Bain circuit Connect fresh gas tube to fresh gas outlet of adaptor as illustrated .

  • Page 11: Moduflex Labvet

    . Install gas evacuation tube to bottom connection of post mount . On Moduflex Labvet install Bain circuit Connect fresh gas tube to fresh gas outlet of adaptor as illustrated . anesthesia machine .

  • Page 12: Moduflex Other Anesthesia Machine

    ASSEMBLY ON OTHER ANESTHESIA MACHINE Connect bain tube to front connection of adaptor and breathing bag to bottom connection . Install gas evacuation tube to bottom connection of post mount . Connect fresh gas tube to fresh gas outlet of anesthesia machine .

  • Page 13: Daily Leak Check Procedure

    DAILY LEAK CHECK PROCEDURE The unit’s integrity should be verified every day, and at each Prerequisites: replacement of patient circuit components such as breathing Oxygen supply of 40 to 60 bags, tubes etc . A properly maintained anesthesia machine psi (3 bar) Breathing circuit reduces gas consumption and operating room pollution .
  • Page 14 DAILY LEAK CHECK PROCEDURE Press the oxygen flush button and hold until Check the manometer . The pressure must not the pressure on the manometer indicates drop (But it can increase) . If the pressure drops, approximately 30 cm H replace the patient circuit and the bag and try again .

  • Page 15: Consumable Materials List

    CONSUMABLE MATERIALS LIST BAIN CIRCUIT REBREATHING BAGS GAS EVACUATION TUBING 0.5 liter: Blue : 5’: # 940-321525 # 940-2490-60B # 985-0060-000 1 liter: Green : # 940-321625 # 940-2490-60V 2 liters: # 940-321725 3 liters: # 940-321825 805-0975-030...

  • Page 16: Warranty

    DISPOMED WARRANTY Dispomed Ltd . guarantees that the Moduflex workmanship or material will, at Dispomed’s Bain is free from manufacturing defects for discretion, either be repaired or replaced . a period of five (5) years from the date of Dispomed Ltd . is not responsible for delivery to the customer, provided that it is deterioration, wear or abuse of this unit .
  • Page 17 REPLACEMENT PART NUMBERS Evacuation Valve 985-6050-000 O-ring 845-S019 Manometer 900-6050-000 O-ring 845-S019 Check Valve 965-0500-015 O-ring 845-S017 O-ring 845-S020 805-0975-030...
  • Page 18 Manufactured by Dispomed ltd 745 Nazaire-Laurin Joliette (QC) Canada J6E 0L6 T : 1-800-363-1746 (Canada and U.S.A only) T : 1-450-759-9395 Fax : 1-450-759-8181 info@dispomed.com www.dispomed.com...
