Troubleshooting
The machine was started without setting of automatic stitch
2C1
type selection.
2C2 Setting for option is incorrect.
2C6
Machine operation was attempted although the bobbin
changer was running.
(*)
2C7 Wrong password was input.
2C8 Sleep mode key was pressed during trace.
2CA The power is not turned "OFF/ON".
2CE Stop by safety device
Air pressure of the regulator has become lower than the
2E2
rated value.
2E3 Power was shut off during operation of embroidery.
Encoder A signal does not change for 5 seconds.
311
Abnormality of motor, motor belt
312 Encoder Z signal status does not change.
316 Abnormality of main shaft driver
322 Abnormality of X-axis driver
323
Abnormality of Y-axis driver
32A The machine cannot memorize excitation of X-axis driver.
32B The machine cannot memorize excitation of Y-axis driver.
331 Bobbin changer error
The needle position signal status during color change does
382
not change for 1 second and more.
383 Bad control of D-axis drive motor
384 Bad control of the motor for looper shaft drive.
385 Z-axis malfunction
387 Color change motor sensor error
3A6 ATH knife retractable position has become nonuniform.
3B5 Communication error
Contact error of the bar switch or start/stop switch,
3C1
breakage of the switch harness, or bad connection of the
connector
There is abnormality in the program or in the CPU card.
3D6
Software is not installed correctly.
3F1 Tension release error (thread tension control error)
JZ07
Perform automatic stitch type selection.
Set correctly.
Do not operate the machine during working of the bobbin
changer.
* Only the model that is equipped with bobbin changer
Input the correct password after pressing the reset key (
Press the reset key ( ).
Turn "OFF/ON" the power.
After removing an obstacle, press the reset key
press the start switch.
then
Check the air compressor. Check the origin of air supply.
Perform operation of power resume after turning ON the
power.
Check the encoder or encoder signal lines.
Check the main shaft driver for excitation.
Check the motor or motor belt.
Check the encoder or encoder signal lines.
Turn "OFF/ON" the power. Or switch from sleep mode to
normal mode (each driver setting will be reset). When it is
not possible to recover from the trouble, replace the card.
• Turn "OFF/ON" the power.
• Check connection of motor of each frame driver and
sensor wire.
• Replace the corresponding frame driver.
• Replace the corresponding frame motor.
Operate the bobbin changer manually to check the place
where movements are bad, and adjust it.
Check the color change motor and power supply circuit.
Check the potentiometer (needle position sensor).
Turn "OFF/ON" the power. When the machine is not
restored even after that, replace the head card of the
corresponding CM head.
Adjust the position of the Z-axis of the corresponding CM
head.
Check the connection of the color change motor sensor
(CN7) on the machine card.
Check the position of ATH movable knife.
• Turn "OFF/ON" the power.
• Install the software again.
• Check the connection of CPU card
hub machine card, main shaft driver and/or X/Y-axis
driver.
Check the connector and the connecting terminal.
Replace the limit switch or switch assembly.
Check the CPU card.
Install software.
Turn "OFF/ON" the power. When the machine is not
restored even after that, adjust/replace the tension release
potentiometer.
13-3
).
