USER 'S MANUAL
TEMX-C series
1. Turn ON the power ......................................................................34
2. To pass thread, to set fabric ........................................................37
5. To decide the design start position ..............................................55
6. Checking items before embroidering ...........................................62
7. Embroidery starts.........................................................................66
Original Instructions
M-EMX22-E
(2014.10)
